Goodrive100-PV Series Solar Pump Inverter
Field
Rated
current
Voltage
class
Industry
code
C.1.1.2 Terminal description of QH100-PV switching module
Terminal
Terminal name
PV +
PV –
Switching module
(+)
Voltage detection
S, COM
C.1.1.3 Installation dimensions
Figure C–2 Installation dimensions of the switching module (unit: mm)
Note: To ensure reliable operation of this product, external ventilation and heat dissipation
measures are required.
Sign
Description
Power range for
adaptive inverter
Voltage class
Industry code
PV input
PV input
output
signal
Power frequency & PV switching solution
055A—applies to inverters of ≤ 15kW
110A—applies to inverters of 18.5–
37kW
4: AC 3PH 380V (-15%)–440 (+10%)
2: AC 3PH 220V (-15%)–240 (+10%)
PV: Photovoltaic water pump series
products
Voltage detection board input, connecting to anode of
PV input.
Voltage detection board input, connecting to cathode
of PV input.
Cathode of diode module, connecting to (+) of the
inverter.
ON/OFF
signal,
greater/less than preset threshold, connecting to
terminals HDI and COM of the inverter.
240
231
-67-
Content
Description
corresponding
PV
voltage
