Goodrive100-PV Series Solar Pump Inverter
A.3 Cable
A.3.1 Power cable
The sizes of the input power cables and motor cables must comply with local regulations.
Note: If the electrical conductivity of the motor cable shield layer does not meet the
requirements, a separate PE conductor must be used.
A.3.2 Control cable
A relay cable needs to carry the metal braided shield layer.
Keypads need to be connected by using network cables. In complicated electromagnetic
environments, shielded network cables are recommended.
A shielded twisted-pair cable is recommended for a communication cable.
Note:
Analog signals and digital signals cannot share a same cable, and their cables must be
routed separately.
Before connecting the input power cable of the inverter, check the insulation conditions of
the cable according to local regulations.
Recommended power cable sizes for standard inverter models:
Model
GD100-0R4G-S2-PV
GD100-0R7G-S2-PV
GD100-0R4G-SS2-PV
GD100-0R7G-4-PV
GD100-1R5G-4-PV
GD100-2R2G-4-PV
GD100-1R5G-S2-PV
GD100-2R2G-S2-PV
GD100-0R7G-SS2-PV
GD100-1R5G-SS2-PV
GD100-2R2G-SS2-PV
GD100-004G-4-PV
GD100-5R5G-4-PV
Recommended cable size
2
(mm
)
(+)/(-), R/S/T, U/V/W
1.5
1.5
1.5
1.5
1.5
1.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
-60-
Terminal
screw
PE
1.5
M4
1.5
M4
1.5
M4
1.5
M4
1.5
M4
1.5
M4
2.5
M4
2.5
M4
2.5
M4
2.5
M4
2.5
M4
2.5
M4
2.5
M4
Options
Tightening
torque
(Nm)
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
1.2–1.5
1.2–1.5
