Goodrive100-PV Series Solar Pump Inverter
Function
code
P07.02
User password
Sequence of
switching
running-command
P07.03
channels by
pressing
QUICK/JOG
Stop function
P07.04
validity of
STOP/RST
Name
0: No function
1: Jogging running. Press QUICK/JOG to
begin the jogging running.
2: Switch the display state by the shifting
key.
displayed function code from right to left.
3: Switch between forward rotations and
reverse rotations. Press QUICK/JOG to
shift
commands. This function is only valid in the
keypad commands channels.
4: Clear UP/DOWN settings. Press
QUICK/JOG to clear the set value of
UP/DOWN.
5: Coast to stop. Press QUICK/JOG to
coast to stop.
6: Switch command channels in sequence.
Press QUICK/JOG key to switch the
running command reference mode in
sequence.
7: Quick commissioning mode (based on
non-factory parameters)
Note: Press QUICK/JOG to shift between
forward rotation and reverse rotation, the
inverter does not record the state after
shifting during powering off. The inverter will
run according to parameter
next powering on.
When P07.02=6, set the sequence of
switching running-command channels by
pressing this key.
0: Keypad→Terminal→Communication
1: Keypad←→Terminal
2: Keypad←→Communication
3: Terminal←→Communication
Used to specify the stop function validity of
STOP/RST. For fault reset, STOP/RST is
valid in any conditions.
Description
Press
QUICK/JOG
the
direction
of
-35-
Function parameter list
Default Modify
to
shift
the
the
frequency
P00.13
during
◎
6
○
1
○
1
