Goodrive100-PV Series Solar Pump Inverter
Function
Name
code
P15 group Functions special for solar inverter
Function
code
Solar inverter
P15.00
selection
Vmpp voltage
P15.01
giving method
Vmpp voltage
P15.02
given through
can maintain the bus voltage to ensure
normal running of the inverter until the
recovery of power.
Voltage class
Name
0: Disable
1: Enable
The value 0 indicates solar control is invalid,
and this function group is not used.
The value 1 indicates solar control is valid,
this function group can be modified.
0: Voltage
1: Max. power tracking
The value 0 indicates using the voltage
giving method, the reference voltage is
P15.02, and it is a fixed value.
The value 1 indicates the reference voltage
is given by tracking the max. power. The
reference voltage keeps changing until the
system becomes stable.
Note: This parameter is invalid when
terminal function 43 is valid.
0.0–6553.5 Vdc
When
determines the reference voltage. (During
testing, the reference voltage value must be
keypad
less than the PV input voltage. Otherwise,
the system runs at the lower limit of
frequency.)
Description
220V
Frequency
decrease
260V
point
Description
P15.01
is
0,
-39-
Function parameter list
400V
460V
this
parameter
Default Modify
Default Modify
◎
1
◎
1
○
250.0V
