INVT Goodrive100-PV Series Operation Manual page 65

Solar pump inverter
Hide thumbs Also See for Goodrive100-PV Series:
Table of Contents

Advertisement

Goodrive100-PV Series Solar Pump Inverter
Model
GD100-1R5G-2-PV
GD100-2R2G-2-PV
GD100-7R5G-4-PV
GD100-004G-2-PV
GD100-011G-4-PV
GD100-5R5G-2-PV
GD100-015G-4-PV
GD100-7R5G-2-PV
GD100-018G-4-PV
GD100-022G-4-PV
GD100-030G-4-PV
GD100-037G-4-PV
GD100-045G-4-PV
GD100-055G-4-PV
GD100-075G-4-PV
GD100-090G-4-PV
GD100-110G-4-PV
GD100-132G-4-PV
GD100-160G-4-PV
GD100-185G-4-PV
GD100-200G-4-PV
Note:
For the cable selection for IP54 models, see the cables applicable to the models with the
same power as model IP54 in this table.
The cables recommended for the main circuit can be used in scenarios where the
ambient temperature is lower than 40° C, the wiring distance is shorter than 100 m, and
the current is the rated current.
If a control cable and power cable must cross each other, ensure that the angle between
them is 90 degrees.
Recommended cable size
2
(mm
)
(+)/(-), R/S/T, U/V/W
2.5
2.5
4
4
6
6
10
10
16
25
25
35
35
50
70
95
120
185
240
120*2P
120*2P
-61-
Terminal
screw
PE
2.5
M4
2.5
M4
4
M5
4
M5
6
M5
6
M5
10
M5
10
M5
16
M5
16
M5
16
M6
16
M6
16
M8
25
M8
35
M8
50
M12
70
M12
95
M12
95
M12
150
M12
150
M12
Options
Tightening
torque
(Nm)
1.2–1.5
1.2–1.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
4–6
4–6
10
10
10
31–40
31–40
31–40
31–40
31–40
31–40
