Goodrive100-PV Series Solar Pump Inverter
"○" indicates that the value of the parameter can be modified when the inverter is in stopped
or running state.
"◎" indicates that the value of the parameter cannot be modified when the inverter is in
running state.
"●" indicates that the value of the parameter is detected and recorded, and cannot be
modified.
Note: The inverter automatically checks and constrains the modification of parameters, which
helps prevent incorrect modifications.
6.1 Function parameters related to control
P00 group Basic functions
Function
code
Speed control
P00.00
Channel of
P00.01
commands
6 Function parameter list
Name
0: SVC 0
No need to install encoders. Applicable to
scenarios
frequency, great torque, high speed control
accuracy. Relative to SVC mode 1, SVC
mode 0 is more applicable to the scenarios
requiring small power.
1: SVC mode 1
Applicable to high-performance scenarios,
featuring high rotation and torque accuracy,
mode
without the need to install pulse encoders.
2: Space voltage vector control mode
Applicable to scenarios without demanding
requirements on control accuracy, such as
fan and pump. One inverter can drive
multiple motors.
Note: Before using a vector control mode,
enable the inverter to perform motor
parameter autotuning first.
Used to select the channel of running
inverter control commands.
running
The inverter control commands include the
start, stop, forward run, reverse run, jog,
and fault reset commands.
Description
with
requirements
-22-
Function parameter list
Default Modify
for
low
2
1
◎
○
