C.4 Parameter setting method
Connect the external PV voltage detection signal to HDI terminal (auto switching by default).
Ensure that the PV voltage detection threshold is 300V for the -4 models and it is 200V for the
-2/-S2/-SS2 models.
After the correct connection, set P15.32 to 0.
Terminal
name
AC input
1PH 220V AC input terminals, connected to the grid
Input terminals of photovoltaic panels.
3PH/1PH AC output terminals, connected to pump motor.
Note: 1PH motors must connect to terminals U and W.
Grounding terminal for safe protection; each machine
Safety
must be properly grounded.
Note: The grounding terminal is located at the bottom of
the chassis.
Power frequency & PV switching solution
Description
-72-
