Goodrive100-PV Series Solar Pump Inverter
Environment
Humidity
Storage
temperature
Running
environment
Pollution degree
Altitude
Vibration
Installation
direction
Note:
The inverter must be installed in a clean and well-ventilated environment based on the IP
level.
The cooling air must be clean enough and free from corrosive gases and conductive dust.
3.1.2 Installation direction
The inverter may be installed on the wall or in a cabinet.
The inverter needs be installed in the vertical position. Check the installation site according to
the requirements below. See Appendix D Dimension drawings for frame details.
The relative humidity (RH) of the air is less than 90%.
Condensation is not allowed.
-40° C–+70° C, with the air temperature change rate less than
1° C/minute.
Install the inverter in a place:
Away from electromagnetic radiation sources.
Away from oil mist, corrosive gases and combustible gases.
Without the chance for foreign objects such as metal powder,
dust, oil and water to fall into the inverter (do not install the
inverter onto combustible objects such as wood).
Without radioactive substances and combustible objects.
Without hazard gases and liquids.
With low salt content.
Without direct sunlight.
Degree 2
Lower than 1000m;
When the altitude exceeds 1000m, derate 1% for every increase
of 1˚C.
When the altitude exceeds 3000m, consult the local INVT dealer
or office.
Max. vibration acceleration: 5.8m/s
Install the inverter vertically to ensure good heat dissipation
performance.
Conditions
2
(0.6g)
-9-
Installation guidelines
Need help?
Do you have a question about the Goodrive100-PV Series and is the answer not in the manual?
Questions and answers
I want to connect a low water level sensor to GD100-PV invt how it supposed to do
The low water level sensor should be connected to the INVT Goodrive100-PV Series inverter at the designated terminal. Based on the standard wiring diagram:
1. Identify the low water level switch terminals.
2. Connect the common terminal of the sensor to the COM terminal on the inverter.
3. Connect the sensor output to the appropriate input terminal (e.g., S1 or S4) on the inverter.
4. Ensure wiring is secure and correctly configured according to the installation guidelines.
This setup allows the inverter to receive signals from the low water level sensor and respond accordingly.
