WORKSHOP MANUAL
TRACTOR
L3560,L4060,L4760,
L5060,L5460,L6060
KiSC issued 03, 2016 A

Advertisement

Table of Contents
loading

Related Manuals for Kubota WSM L3560

Summary of Contents for Kubota WSM L3560

  • Page 1 WORKSHOP MANUAL TRACTOR L3560,L4060,L4760, L5060,L5460,L6060 KiSC issued 03, 2016 A...
  • Page 2 TO THE READER This Workshop Manual tells the servicing personnel about the mechanism, servicing and maintenance of the KUBOTA Tractor L3560, L4060, L4760, L5060, L5460 and L6060. It contains 4 parts: "Information", "General", "Mechanism" and "Servicing".  Information This section contains information below.
  • Page 3 Record of Revisions For pdf, use search function {Search word} to find all the revised locations. Last digit Issue Reference of the Main Revised Point and Corrective Measures {Search word} month Page Code No. 2015.11 Correction of Workshop Manual 3. SPECIFICATIONS I-12, I-14 4.
  • Page 4 Last digit Issue Reference of the Main Revised Point and Corrective Measures {Search word} month Page Code No. 2015.11 Overheating Warning 9-M37 2. SERVICING SPECIFICATIONS 9-S9 (3) Mode "B" (Traveling Speed Coefficient Input Mode) Input the 4 Digit 9-S20 Tire Code for Correct Travel Speed to the Electronic Instrument Panel Memory Panel (10) Mode "K"...
  • Page 5 INFORMATION KiSC issued 03, 2016 A...

  • Page 6: Table Of Contents

    INFORMATION CONTENTS 1. SAFETY FIRST ..........................I-1 2. SAFETY DECALS .......................... I-4 3. SPECIFICATIONS........................I-10 [1] MANUAL TRANSMISSION ....................I-10 [2] GST ............................I-11 [3] HST ............................I-12 [4] HST with CABIN TYPE......................I-14 4. TRAVELING SPEEDS........................I-16 [1] MANUAL TRANSMISSION ....................I-16 [2] GST ............................

  • Page 7: Safety First

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. SAFETY FIRST SAFETY FIRST • This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully. •...
  • Page 8 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM OPERATE SAFELY • Do not use the machine after you consume alcohol or medication or when you are tired. • Put on applicable clothing and safety equipment. • Use applicable tools only. Do not use alternative tools or parts.
  • Page 9 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM KEEP A GOOD AIRFLOW IN THE WORK AREA • If the engine is in operation, make sure that the area has good airflow. Do not operate the engine in a closed area. The exhaust gas contains poisonous carbon monoxide.

  • Page 10: Safety Decals

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SAFETY DECALS The following safety decals are installed on the machine. If a decal becomes damaged, illegible or is not on the machine, replace it. The decal part number is listed in the parts list. WSM000001INI0013US0 9Y1210824INI0001US0 KiSC issued 03, 2016 A...
  • Page 11 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 9Y1210824INI0002US0 KiSC issued 03, 2016 A...
  • Page 12 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 9Y1210824INI0003US0 KiSC issued 03, 2016 A...
  • Page 13 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 9Y1210824INI0004US0 KiSC issued 03, 2016 A...
  • Page 14 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 9Y1210824INI0005US0 KiSC issued 03, 2016 A...
  • Page 15 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 9Y1210824INI0006US0 CARE OF DANGER, WARNING AND CAUTION LABELS 1. Keep danger, warning and caution labels clean and free from obstructing material. 2. Clean danger, warning and caution labels with soap and water, dry with a soft cloth. 3.

  • Page 16: Specifications

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. SPECIFICATIONS [1] MANUAL TRANSMISSION L3560 L4060 Model Model D1803-CR-E4 V2403-CR-E4 Type Direct injection vertical, water-cooled, 4-cycle diesel Number of cylinders Total displacement 1.826 L (111.4 cu.in.) 2.434 L (148.5 cu.in.) Bore and stroke 87 ×...

  • Page 17: Gst

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] GST L3560 L4060 L4760 L5060 Model Model D1803-CR-E4 V2403-CR-E4 V2403-CR-TE4 Type Direct injection vertical, water-cooled, 4-cycle diesel Number of cylinders Total displacement 1.826 L (111.4 cu.in.) 2.434 L (148.5 cu.in.) Bore and stroke 87 ×...

  • Page 18: Hst

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HST L3560 L4060 L4760 L5460 L6060 Model Model D1803-CR-E4 V2403-CR-E4 V2403-CR-TE4 Type Direct injection vertical, water-cooled, 4-cycle diesel Number of cylinders 1.826 L Total displacement 2.434 L (148.5 cu.in.) (111.4 cu.in.) Bore and stroke 87 ×...
  • Page 19 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM L3560 L4060 L4760 L5460 L6060 Model Hydraulic control system Position control 30.4 L Pump capacity (8.0 U.S.gals, 35.6 L (9.4 U.S.gals, 7.8 Imp.gals) 6.7 Imp.gals) Three point hitch SAE category 1 SAE category 1, 2 Hydraulic unit 1700 kg At lift points...

  • Page 20: Hst With Cabin Type

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] HST with CABIN TYPE L3560 L4060 L4760 L5460 L6060 Model Model D1803-CR-E4 V2403-CR-E4 V2403-CR-TE4 Type Direct injection vertical, water-cooled, 4-cycle diesel Number of cylinders 1.826 L Total displacement 2.434 L (148.5 cu.in.) (111.4 cu.in.) Bore and stroke 87 ×...
  • Page 21 (rpm) / 2476 min (rpm) 540 min (rpm) / 2403 min (rpm) 2426 min (rpm) Mid-PTO (if equipped) USA No.5 (KUBOTA 10-tooth) involute spline 2000 min (rpm) PTO/Engine speed / 2451 min 2000 min (rpm) / 2502 min (rpm) 2000 min...

  • Page 22: Traveling Speeds

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. TRAVELING SPEEDS [1] MANUAL TRANSMISSION (At rated engine rpm) Model L3560 L4060 Tire size (Rear) 12.4-24 14.9-24 Shuttle shift Creep gear Range gear Main gear km/h (mph) lever shift lever shift lever shift lever 0.18 (0.11) 0.17 (0.11)

  • Page 23: Gst

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] GST (At rated engine rpm) Model L3560 L4060, L4760 L5060 Tire size (Rear) 12.4-24 14.9-24 14.9-26 Shuttle shift Main gear shift Main gear shift km/h (mph) lever lever lever 0.18 (0.11) 0.17 (0.11) 0.17 (0.11) 0.25 (0.16)
  • Page 24 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM (At rated engine rpm) Model L3560 L4060, L4760 L5060 Tire size (Rear) 12.4-24 14.9-24 14.9-26 Shuttle shift Main gear shift Main gear shift km/h (mph) lever lever lever 0.17 (0.11) 0.16 (0.10) 0.17 (0.11) 0.24 (0.15) 0.23 (0.14)

  • Page 25: Hst

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HST (At rated engine rpm) Model L3560 L4060, L4760 L5460, L6060 Tire size (Rear) 12.4-24 14.9-24 14.9-26 H-DS (Hydro Speed control Range gear Dual Speed) km/h (mph) pedal shift lever lever 3.4 (2.1) 3.4 (2.1) 3.4 (2.1)

  • Page 26: Dimensions

    INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. DIMENSIONS ROPS Type 9Y1210824INI0015US0 I-20 KiSC issued 03, 2016 A...
  • Page 27 INFORMATION L3560, L4060, L4760, L5060, L5460, L6060, WSM CABIN Type 9Y1210824INI0016US0 I-21 KiSC issued 03, 2016 A...
  • Page 28 GENERAL KiSC issued 03, 2016 A...
  • Page 29 GENERAL CONTENTS 1. TRACTOR IDENTIFICATION....................... G-1 [1] MODEL NAME AND SERIAL NUMBERS ................G-1 [2] E4B ENGINE .......................... G-2 [3] CYLINDER NUMBER ......................G-2 2. GENERAL PRECAUTIONS......................G-3 3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING ........G-4 [1] WIRING ..........................G-4 [2] BATTERY ..........................

  • Page 30: Tractor Identification

    L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TRACTOR IDENTIFICATION [1] MODEL NAME AND SERIAL NUMBERS When contacting your local KUBOTA distributor, always specify engine serial number, tractor serial number and hour meter reading. (1) Tractor Identification Plate (4) Tractor Serial Number...

  • Page 31: E4B Engine

    Nonroad Emission Standards continue to change. The timing or applicable date of the specific Nonroad Emission regulations depends on the engine output classification. Over the past several years, KUBOTA has been supplying diesel engines that comply with regulations in the respective countries affected by Nonroad Emission regulations. For KUBOTA Engines, E4B will be the designation that identifies engine models affected by the next emission phase (See the table below).

  • Page 32: General Precautions

    • When it is necessary to use special tools, use KUBOTA special tools. Refer to the drawings when you make special tools that you do not use frequently.

  • Page 33: Handling Precautions For Electrical Parts And Wiring

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING To ensure safety and prevent damage to the machine and surrounding equipment, obey the following precautions in handling electrical parts and wiring. IMPORTANT • Check electrical wiring for damage and loosened connection every year.
  • Page 34 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM • Repair or change torn or aged wiring immediately. (1) Aged (3) Insulating Vinyl Tape (2) Torn WSM000001GEG0065US0 • Securely insert grommet. (1) Grommet (A) Correct (B) Incorrect WSM000001GEG0066US0 • Securely clamp, being careful not to damage wiring. (1) Clamp (3) Clamp (Wind Clamp Spirally)

  • Page 35: Battery

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] BATTERY • Be careful not to confuse positive and negative terminal posts. • When you remove battery cables, disconnect negative cable first. When you install battery cables, check for polarity and connect positive cable first.

  • Page 36: Circuit Tester

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM • Use sandpaper to remove rust from terminals. • Repair deformed terminal. Make sure that there is no terminal being exposed or displaced. (1) Exposed Terminal (3) Sandpaper (2) Deformed Terminal (4) Rust WSM000001GEG0075US0 •...

  • Page 37: Color Of Wiring

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [6] COLOR OF WIRING • Colors of wire are specified to the color codes. • This symbol of "/" shows color with stripe (s). (An example) Red stripe on white color: W/R Color of wiring Color code Black...

  • Page 38: Lubricants, Fuel And Coolant

    Front axle 6.9 U.S.qts 9.5 U.S.qts fluid or SAE80, 90 gear case 5.7 Imp.qts 7.9 Imp.qts NOTE • KUBOTA UDT or SUPER UDT fluid: KUBOTA original transmission hydraulic fluid. Greasing Type of Place No. of greasing point Capacity grease Front axle –...
  • Page 39 • No.2-D is a distillate fuel of lower volatility for engines in industrial and heavy mobile service. (SAE J313 JUN87). Transmission Oil: *KUBOTA Super UDT-2: For an enhanced ownership experience, we highly recommend Super UDT-2 to be used instead of standard hydraulic/transmission fluid. Super UDT-2 is a proprietary KUBOTA formulation that deliveries superior performance and protection in all operating conditions.

  • Page 40: Tightening Torques

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. TIGHTENING TORQUES [1] GENERAL USE SCREWS, BOLTS AND NUTS Tighten screws, bolts and nuts whose tightening torques are not specified in this Workshop Manual according to the table below. Indication on top of bolt No-grade or 4T Indication on top of nut No-grade or 4T...

  • Page 41: Metric Screws, Bolts And Nuts

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] METRIC SCREWS, BOLTS AND NUTS Grade Property class 8.8 Property class 10.9 Unit N·m kgf·m lbf·ft N·m kgf·m lbf·ft 24 to 27 2.4 to 2.8 18 to 20 30 to 34 3.0 to 3.5 22 to 25 48 to 55...

  • Page 42: Maintenance

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. MAINTENANCE Indication on hour meter Refer- Impor- Item Interval ence tant 100 150 200 250 300 350 400 450 500 550 600 650 700 page every 1 Engine start system Check G-23 ...
  • Page 43 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Indication on hour meter Refer- Impor- Item Interval ence tant 100 150 200 250 300 350 400 450 500 550 600 650 700 page Check every 27 EGR system G-34 Clean 3000 Hr every 28 Supply pump Check...
  • Page 44 However, must be replaced every 4 years regardless of the condition. • The items listed above (@ marked) are registered as emission related critical parts by KUBOTA in U.S.EPA nonroad emission regulation. As the engine owner, you are responsible for the performance of the required maintenance on the engine according to the above instruction.

  • Page 45: Check And Maintenance

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM 7. CHECK AND MAINTENANCE CAUTION • Be sure to check and service the tractor on a flat place with engine shut off and pull the parking brake on and chock the wheels. 9Y1210824GEG0008US0 [1] DAILY CHECK To prevent trouble from occurring, it is important to know the condition of the tractor.
  • Page 46 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Water Separator 1. As water is collected in the water separator, the red float is raised. 2. When the red float has reached the white line, close the fuel valve, loosen the retainer ring, take out the cup, and clean the cup.
  • Page 47 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Coolant Level CAUTION • Do not remove radiator cap while coolant is hot. When cool, slowly rotate cap to the first stop and allow sufficient time for excess pressure to escape before removing the cap completely.
  • Page 48 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Cleaning Grill, Radiator Screen and Oil Cooler CAUTION • Be sure to stop the engine before removing the screen. • Before checking or cleaning the radiator screen, stop the engine and wait long enough until it is cooled down. 1.
  • Page 49 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking DPF Muffler CAUTION • Before checking or cleaning the DPF muffler, stop the engine and wait long enough until it is cooled down. 1. Check the DPF muffler and its surroundings for build-up of anything flammable.

  • Page 50: Check Points Of Initial 50 Hours

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Head Light / Turn Signal / Hazard Light etc. 1. Inspect the light for broken bulbs and lenses. 2. Replace if broken. 9Y1210824GEG0024US0 Checking Seat Belt and ROPS 1. Always check condition of seat belt and ROPS attaching hardware before operating tractor.
  • Page 51 8. Make sure that the transmission fluid does not leak past the seal on the filter. IMPORTANT • To prevent serious damage to the hydraulic system, use only a KUBOTA genuine filter. (1) Drain Plug Oil level is acceptable within this (2) Transmission Oil FIlter (HST) range.

  • Page 52: Check Points Of Every 50 Hours

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] CHECK POINTS OF EVERY 50 HOURS Checking Engine Start System CAUTION To avoid personal injury: • Do not allow anyone near the tractor while testing. • If the tractor does not pass the test, do not operate the tractor.
  • Page 53 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Operator Presence Control CAUTION To avoid personal injury: • Do not allow anyone near the tractor while testing. • If the tractor does not pass the test, do not operate the tractor.
  • Page 54 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Lubricating Grease Fitting 1. Apply a small amount of multipurpose grease to the following points every 50 hours. If you operated the machine in extremely wet and muddy conditions, lubricate grease fittings more often. 2.

  • Page 55: Check Points Of Every 100 Hours

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] CHECK POINTS OF EVERY 100 HOURS Adjusting Clutch Pedal Free Travel (GST Manual Transmission) 1. See page G-20. 9Y1210824GEG0037US0 Adjusting Brake Pedal Free Travel 1. See page G-20. 9Y1210824GEG0038US0 Checking Battery Condition DANGER To avoid the possibility of battery explosion: For the refillable type battery, follow the instructions below.
  • Page 56 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Battery Charging CAUTION • When the battery is being activated, hydrogen and oxygen gases in the battery are extremely explosive. Keep open sparks and flames away from the battery at all times, especially when charging the battery.
  • Page 57 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Adjusting Fan Belt Tension CAUTION • Be sure to stop the engine before checking fan belt tension. 1. Stop the engine and remove the key. 2. Apply moderate thumb pressure to belt between pulleys. 3.

  • Page 58: Check Points Of Every 200 Hours

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] CHECK POINTS OF EVERY 200 HOURS Replacing Transmission Oil Filter (HST) • See page G-22. 9Y1210824GEG0044US0 Adjusting Toe-in 1. Park the tractor on the flat place. 2. Turn steering wheel so front wheels are in the straight ahead position.

  • Page 59: Check Points Of Every 400 Hours

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Cleaning Inner Air Filter (Cabin Type) 1. Press the inner air filter in the arrow-marked directions to unlock it and remove the inner filter, and blow air from the direction opposite to the filter's normal air flow. 2.
  • Page 60 6. Quickly tighten the filter until it contacts the mounting surface, then tighten it by hand an additional 1/2 turn only. 7. Fill with the new KUBOTA SUPER UDT fluid up to the upper notch on the dipstick. (Refer to "4. LUBRICANTS, FUEL AND COOLANT"...
  • Page 61 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Changing Front Axle Case Oil 1. To drain the used oil, remove the right and left drain plugs and filling plug at the front axle case and let out the oil completely into the oil pan.

  • Page 62: Check Point Of Every 600 Hours

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Cleaning Water Separator This job should not be done in the field, but in a clean place. 1. Close the fuel valve. 2. Unscrew the retainer ring and remove the cup, and rinse the inside with kerosene.

  • Page 63: Check Points Of Every 1500 Hours

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [9] CHECK POINTS OF EVERY 1500 HOURS Cleaning Fuel Injector Nozzle Tip • See page 1-S57. 9Y1210824GEG0062US0 Replacing Oil Separator Element CAUTION To avoid personal injury: • Be sure to stop the engine before replacing the oil separator element.

  • Page 64: Check Points Of Every 1000 Hours Or 1 Year

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [11] CHECK POINTS OF EVERY 1000 HOURS OR 1 YEAR Replacing Air Cleaner Primary Element and Secondary Element 1. See page G-28. 9Y1210824GEG0070US0 Checking Exhaust Manifold 1. Examine the exhaust manifold for crack, exhaust gas leakage and loose mounting screw.
  • Page 65 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Intake Air Line 1. Check to see that hose and hose clamps are tight and not damaged. 2. If hose and clamps are found worn or damaged, replace or repair them at once. (1) Hose [A] L3560 (2) Hose Clamp...
  • Page 66 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Radiator Hose and Hose Clamp Check to see if radiator hoses are properly fixed every 200 hours of operation or six months, whichever comes first. 1. If hose clamps are loose or water leaks, tighten bands securely. 2.
  • Page 67 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking DPF Differential Pressure Sensor Pipes and Hoses IMPORTANT • Be sure to loosen the differential pressure pipe tightening nut with crowfoot wrench to prevent the damage of the sensor or pipe. If it is still hard to loosen, apply the lubricant spray to threaded portion and soak it with lubricant.
  • Page 68 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Cabin Isolation Cushion 1. Check the isolation cushion (1) for any breakage or fatigue. 2. Replace them if they have deteriorated. (1) Isolation Cushion (F) Front Side (R) Rear Side 9Y1210824GEG0075US0 Checking Antifrost Heater for Oil Separator (If Equipped) 1.

  • Page 69: Check Points Of Every 2000 Hours Or 2 Years

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [13] CHECK POINTS OF EVERY 2000 HOURS OR 2 YEARS Flushing Cooling System and Changing Coolant CAUTION To avoid personal injury: • Do not remove radiator cap while coolant is hot. When cool, slowly rotate cap to the first stop and allow sufficient time for excess pressure to escape before removing the cap completely.
  • Page 70 • Also, observe the relevant environmental protection regulations when disposing of antifreeze. Always use a 50/50 mix of long-life coolant and clean soft water in KUBOTA engines. 1. Long-life coolant (hereafter LLC) comes in several types. Use ethylene glycol (EG) type for this engine.

  • Page 71: Check Points Of Every 2 Years

    The LLC contains anticorrosive agent. If mixed with the cleaning agent, sludge may build up, adversely affecting the engine parts. 7. Kubota's genuine long-life coolant has a service life of 2 years. Be sure to change the coolant every 2 years. NOTE •...

  • Page 72: Check Points Of Every 4 Years

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [15] CHECK POINTS OF EVERY 4 YEARS Replacing Fuel Hose 1. Replace the fuel hoses and clamps. Refer to "Checking Fuel Line". (See page G-35.) 9Y1210824GEG0081US0 Replacing Intake Air Line 1. Replace the intake hoses and clamps. Refer to "Checking Intake Air Line".

  • Page 73: Others

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [16] OTHERS Bleeding Fuel System Air must be removed: 1. When the fuel filter or lines are removed. 2. When water is drained from water separator. 3. When tank is completely empty. 4.
  • Page 74 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Replacing Fuse 1. The tractor electrical system is protected from potential damage by fuses. A blown fuse indicates that there is an overload or short somewhere in the electrical system. 2. If any of the fuses should blow, replace with a new one of the same capacity.
  • Page 75 Replacing Slow-Blow Fuses 1. The slow-blow fuses are intended to protect the electrical cabling. If any of them has blown out, be sure to pinpoint the cause. Never use any substitute, use only a KUBOTA genuine part. Capacity (A) Protected circuit...
  • Page 76 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Replacing Head Lamp NOTE To avoid personal injury: • Be careful not to drop the bulb, hit anything against the lamp, apply excess force, and get the lamp scratched. If broken, glass may cause injury. Pay more attention to halogen lamps in particular, which have high pressure inside.
  • Page 77 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Refrigerant (Gas) WARNING • Liquid contact with eyes or skin may cause frostbite. • In the event of a leakage, wear safety goggles. Escaping refrigerant can cause severe injuries to eyes. •...
  • Page 78 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Replacing Oil Cooler Line [HST Type] 1. Replace if any deterioration (crack, hardening, scar of deformation) or damage occurred. Refer to "Checking HST Oil Line and Power Steering Line". (See page G-37.) 9Y1210824GEG0141US0 Replacing Oil Separator Hose 1.

  • Page 79: Special Tools

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM 8. SPECIAL TOOLS [1] SPECIAL TOOLS FOR ENGINE Special Use Puller Set Code No. • 07916-09032 Application • Use exclusively to pull out bearing, gears and other parts with ease. WSM000001GEG0011US0 Piston Ring Compressor Code No.
  • Page 80 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Oil Pressure Tester Code No. • 07916-32032 Application • Use to measure lubricating oil pressure. (1) Gauge (5) Adaptor 2 (2) Cable (6) Adaptor 3 (3) Threaded Joint (7) Adaptor 4 (4) Adaptor 1 (8) Adaptor 5 WSM000001GEG0015US0 Valve Seat Cutter...
  • Page 81 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Plastigauge Code No. • 07909-30241 Application • Use to check the oil clearance between crankshaft and bearing, etc.. Measuring range • Green: 0.03 to 0.07 mm (0.001 to 0.003 in.) • Red: 0.05 to 0.1 mm (0.002 to 0.006 in.) •...
  • Page 82 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Auxiliary Socket for Fixing Crankshaft Sleeve Application • To fix the crankshaft sleeve of the diesel engine. 80.0 mm (3.15 in.) 60.10 to 60.30 mm (2.367 to 2.374 in.) 80.0 mm dia. (3.15 in. dia.) 85.0 mm dia.
  • Page 83 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Application • To fix the crankshaft sleeve of the diesel engine. 42.0 mm (1.65 in.) 30.50 to 30.60 mm (1.201 to 1.204 in.) 23.0 mm (0.906 in.) 20.0 mm (0.787 in.) 2.0 mm (0.079 in.) 31.911 to 31.950 mm dia.
  • Page 84 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Valve Guide Replacing Tool Application • To press out and press fit the valve guide. 225 mm (8.86 in.) 70 mm (2.8 in.) 45 mm (1.8 in.) 20 mm dia. (0.79 in. dia.) 12.7 to 12.9 mm dia.
  • Page 85 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Crankshaft Bearing 1 Replacing Tool Application • To press out and press fit the crankshaft bearing 1. [1] Extracting tool 135 mm (5.31 in.) 72 mm (2.8 in.) 40 mm radius (1.6 in. radius) 10 mm (0.39 in.) 20 mm (0.79 in.) 20 mm dia.
  • Page 86 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Balancer Metal Replacing Tool (for Removing) Application • To remove the metal bearing. 41 mm (1.6 in.) 41.934 to 41.950 mm dia. (1.6510 to 1.6515 in. dia.) 32.5 mm (1.28 in.) 24.959 to 24.980 mm dia. (0.98264 to 0.98346 in. dia.) Chamfer 0.3 mm (0.01 in.) 21.947 to 21.960 mm dia.
  • Page 87 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Balancer Metal Replacing Tool (for Fitting) Application • To press fit the metal bearing. 182 mm (7.17 in.) 60 mm dia. (2.4 in. dia.) 140 mm (5.51 in.) 46.950 to 46.975 mm dia. (1.8485 to 1.8494 in. dia.) 37 mm (1.5 in.) 43.934 to 43.950 mm dia.
  • Page 88 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Injection Top Correction Jig Application • To detects and position the sensor in top-dead center position. 60 mm (2.4 in.) 45 mm (1.8 in.) 37.3 mm (1.47 in.) 3.5 mm (1.4 in.) 12 mm dia.
  • Page 89 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Bearing Case Cover Oil Seal Replacing Tool Application • To install bearing case cover oil seal. 42 mm dia. (1.7 in. dia.) 129 mm dia. (5.08 in. dia.) 32 to 32.025 mm dia. (1.260 to 1.261 in. dia.) 31.950 to 31.975 mm dia.
  • Page 90 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Engine Hook 1 Application • Use for hooking the V2403 engine. Use this engine hook 1 with the engine hook 2. 17 mm (0.67 in.) 9 mm (0.35 in.) 129 mm (5.08 in.) 10.8 to 11.2 mm (0.426 to 0.440 in.) 40 mm (1.6 in.) 20 mm (0.79 in.)
  • Page 91 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Engine Hook 2 Application • Use for hooking the V2403 engine. Use this engine hook 2 with the engine hook 1. 217 mm (8.54 in.) 140 mm (5.51 in.) 49 mm (1.9 in.) 44 mm (1.7 in.) 20 mm Hole (0.79 in.

  • Page 92: Special Tools For Tractor

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] SPECIAL TOOLS FOR TRACTOR Tie-rod End Lifter Code No. • 07909-39051 Application • Use to remove the tie-rod end with ease. WSM000001GEG0029US0 Steering Wheel Puller Code No. • 07916-51090 Application • Use to remove the steering wheel without damage to the steering shaft.
  • Page 93 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Axle Cover Puller Code No. • 07916-51041 Application • Use to remove a rear axle cover from rear axle. WSM000001GEG0035US0 Relief Valve Pressure Tester Code No. • 07916-50045 Application • This allows easy measurement of relief set pressure. (1) Gauge (07916-50322) (6) Adaptor C (PS3/8) (07916-50371) (2) Cable (07916-50331)
  • Page 94 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Pinion Locking Tool Code No. • 07916-55311 Application • Use to prevent the shaft from turning when you remove or tighten a staking nut of a bevel pinion shaft. WSM000001GEG0039US0 Rear Axle Nut Wrench 71 Code No.
  • Page 95 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Pinion Shaft Remover Application • Use for removing a pinion shaft. NOTE • The special tool is not available, so make it. Refer to the figure. 106 mm (4.17 in.) 350 mm (13.78 in.) 6 mm (0.24 in.) 90 mm (3.54 in.) 10 mm (0.39 in.)
  • Page 96 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Draft Control Test Bar Application • Use for checking the lift range and floating range of hydraulic draft control. NOTE • The special tool is not available, so make it. Refer to the figure.
  • Page 97 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Pump Adaptor Application • Use for examining the main hydraulic pump. NOTE • When you use, attach with following parts. O-ring: 04811-00180 • This adaptor is changed from Adaptor 61 of flowmeter adaptor set (see page G-64). •...
  • Page 98 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Cylinder Safety Valve Setting Pressure Adaptor Application • Use for setting the safety valve to the nozzle tester to measure cracking pressure and check oil tightness of the safety valves. NOTE • This special tool is not provided, so make it referring to the figure. 45 mm (1.77 in.) 10 mm dia.
  • Page 99 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Air-Conditioner Service Tool Code No. • DENSO 95048-00063 Application • Use for charge, test or discharge of the air conditioning system. (1) Manifold Gauge Assembly (95048-10090) (2) Charging Hose (Red: HI) (95948-10270) (3) Charging Hose (Blue: LO) (95948-10280) (4) Charging Hose (Green) (95948-10260) (5) Can Tap Valve (95048-10150)
  • Page 100 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Stopper Magnet Clutch (For A/C Compressor) Application • Use for loosen and tighten the magnet clutch mounting nut. (Use radius C). NOTE • This special tool is not available, so make it. Refer to the figure. 125 mm (4.92 in.) 4.52 rad (120 °) 40 mm dia.
  • Page 101 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Stopper Bolt (for A/C Compressor) Application • Use with the stopper magnet clutch. NOTE • This special tool is not available, so make it. Refer to the figure. 12 mm (0.47 in.) 5.5 mm dia.

  • Page 102: Tires

    • Always maintain the correct tire pressure. Do not inflate tires above the recommended pressure shown in the operator's manual. IMPORTANT • Do not use tires other than those approved by KUBOTA. 9Y1210824GEG0117US0 Inflation Pressure Though the tire pressure is factory-set to the prescribed level, it naturally drops slowly in the course of time.

  • Page 103: Wheel Adjustment

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] WHEEL ADJUSTMENT CAUTION To avoid personal injury: • When working on slopes or when working with trailer, set the wheel tread as wide as practical for maximum stability. • Support tractor securely on stands before removing a wheel. •...

  • Page 104: Rear Wheel

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM NOTE • Wheels with beveled or tapered holes: Use the tapered side of lug nut. Models L3560 7-16, 7.2-16 27 × 8.50-15 27 × 10.50-15 29 × 12.50-15 10-16.5 Tire Farm Turf Turf Turf 1115 mm...
  • Page 105 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Models L3560 1200 mm 1300 mm 1385 mm 1480 mm 12.4-24 Farm (47.2 in.) (51.2 in.) (54.5 in.) (58.3 in.) L4060, L4760 1285 mm 1435 mm 1530 mm – 14.9-24 Farm (50.6 in.) (56.5 in.) (60.2 in.) L3560...

  • Page 106: Tire Liquid Injection

    GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] TIRE LIQUID INJECTION Auxiliary weights can be used to increase traction force for plowing in fields or clayey ground. Another way is to inject water or another liquid, such as a calcium chloride solution in the tires. Water must not be used in winter since it freezes at 0 °C (32 °F).
  • Page 107 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Injection CAUTION • When a calcium chloride solution is used, cool it before pouring it into the tire. • Do not fill tires with water or solution more than 75 % of full capacity (to the valve stem level).
  • Page 108 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Draining Water or Solution 1. Lift the rear tires off the ground. 2. Turn the tire so that the air valve is at the bottom. 3. Remove the air valve, and drain liquid (liquid can only be drained to the level of the valve and liquid under that level remains inside).

  • Page 109: Implement Limitations

    KUBOTA. Use with implements which exceed the maximum specifications listed below, or which are otherwise unfit for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor, damage to other property and injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use with improper implements are not covered by the warranty.]...
  • Page 110 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Implement Remarks L3560 L4060 Max. Load Capacity 2000 kg (4400 lbs) 2500 kg (5500 lbs) Trailer Max. Drawbar Load 650 kg (1430 lbs) Max. Cutting Width 1829 mm (72 in.) Rotary-cutter Max. Weight 350 kg (770 lbs) 420 kg (926 lbs) Max.
  • Page 111 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM NOTE • Implement size may vary depending on soil operating conditions. 9Y1210824GEG0130US0 G-82 KiSC issued 03, 2016 A...
  • Page 112 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM Implement Remarks L4760 L5060, L5460, L6060 Max. Load Capacity 3000 kg (6600 lbs) Trailer Max. Drawbar Load 650 kg (1430 lbs) Max. Cutting Width 1829 mm (72 in.) 2134 mm (84 in.) Rotary-cutter Max.
  • Page 113 GENERAL L3560, L4060, L4760, L5060, L5460, L6060, WSM NOTE • Implement size may vary depending on soil operating conditions. 9Y1210824GEG0131US0 G-84 KiSC issued 03, 2016 A...
  • Page 114 ENGINE KiSC issued 03, 2016 A...
  • Page 115 MECHANISM CONTENTS 1. FEATURES..........................1-M1 2. ENGINE BODY........................... 1-M2 [1] PISTON ..........................1-M2 [2] HALF-FLOATING HEAD COVER ..................1-M2 3. LUBRICATING SYSTEM......................1-M3 [1] OIL COOLER........................1-M3 4. COOLING SYSTEM ........................1-M4 [1] THERMOSTAT ........................1-M4 [2] BOTTOM BYPASS SYSTEM ....................1-M5 5.

  • Page 116: Features

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. FEATURES The engine models shown in the table below are adopted in the L60 series tractor. Tractor Model Engine Model L3560 D1803-CR-E4 L4060 V2403-CR-E4 L4760 V2403-CR-E4 L5060 V2403-CR-TE4 L5460 V2403-CR-TE4 L6060 V2403-CR-TE4 9Y1210824ENM0001US0 1-M1...

  • Page 117: Engine Body

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. ENGINE BODY [1] PISTON The piston skirt has a layer of molybdenum disulfide , which decreases the piston slap noise and thus the all the engine noise.  Molybdenum disulfide (MoS The molybdenum disulfide (1) is a solid lubricant, like Graphite or Teflon.

  • Page 118: Lubricating System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. LUBRICATING SYSTEM [1] OIL COOLER The engine is equipped with a water-cooled oil cooler to keep the temperature of the oil from rising while the engine is operating and provide it with proper lubrication.

  • Page 119: Cooling System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. COOLING SYSTEM [1] THERMOSTAT This thermostat uses a wax-pellet type. When temperature goes up, wax (6) in metal container (pellet (5)) changes to a liquid from a solid. The volume of the wax (6) starts to expand in this process.

  • Page 120: Bottom Bypass System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] BOTTOM BYPASS SYSTEM In addition to improving the cooling performance of the radiator by utilizing a bottom bypass system, the mechanism uses a 3-stage thermostat valve that reduces thermal shock considerably compared to previous radiators.

  • Page 121: Fuel System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. FUEL SYSTEM [1] OVERVIEW OF COMMON RAIL SYSTEM (1) Fuel Tank (2) Water Separator (3) Electromagnetic Pump (4) Check Valve (5) Fuel Sub Tank (6) Fuel Cooler (7) Feed Pump (8) Fuel Filter (9) Supply Pump (10) Pressure Limiter (11) Rail...
  • Page 122 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Separator The separator has a function of separating fuel and water through difference in specific gravity. There is a read float (7) with a specific weight of 0.9 made of a polypropylene material inside that has properties in that it is heavier than diesel and lighter than water.
  • Page 123 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Feed Pump The feed pump (1) is installed after the fuel cooler and has a function of suctioning fuel from the fuel tank and pressure feeding it through a filter and to the supply pump.

  • Page 124: Supply Pump

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] SUPPLY PUMP The supply pump corresponds to conventional injection pumps but pressurizes the fuel to more than 2 times that of conventional pumps for delivery to the rail. The supply pump is made up of an intake adjustment valve (SCV) (3), pressurizing part, overflow valve (4), IO valve (6), and zero delivery drain (5).
  • Page 125 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Suction Control Valve (SCV) (1) Cylinder Part (2) Solenoid (3) Armature (4) Discharge Port (5) Piston (6) Cylinder (7) Suction Port High Suction Volume Low Suction Volume Large Small (A) To pressurizing section (B) From fuel pump [A] Suction Control Valve [B] No delivery (current ON)
  • Page 126 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Overflow Valve When the pressure of fuel delivered from the feed pump rises above a prescribed amount, the overflow valve has a function of returning fuel to the tank and is made up of a valve body (2), valve piston (5), spring (3), and ball (1).

  • Page 127: Rail

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] RAIL The rail (2) stores fuel at the high pressure applied by the supply pump and the injectors of each cylinder. The rail incorporates control parts-a rail pressure sensor (3) and a pressure limiter (1). The pressure of the fuel in the rail is detected by the rail pressure sensor, and optimal feedback control is provided for the engine RPM and load.

  • Page 128: Injector

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] INJECTOR General The injectors inject high-pressure fuel sent from the rail into the combustion chamber of the engine. The injections are controlled by the signal of engine's ECU to produce the ideal timing, amount of fuel, mixture and spray.
  • Page 129 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Injector Structure Injectors consist of nozzle components (nozzle body (6), needle valve (7), nozzle spring (12), nozzle nut (13)) and control components (control chamber (3), solenoid (9), valve spring (8), TWV (Two Way Valve) (10), valve ball (1), valve body (4), command piston (5), suction orifice (11), discharge orifice (2).
  • Page 130 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Injector Operation  No Injection While the solenoid (2) is not electrified, the two way electromagnetic valve (3) is pushed down by the valve spring (1) and the discharge orifice (11) path is closed by the valve ball (4).
  • Page 131 Register the ID codes of all of the injectors into the replacement engine ECU. When replacing an ECU, as it is necessary to write all of the data, including the injector corrections, only KUBOTA can write the data to the ECU. (1) Replacement ECU (2) Injector 9Y1210824ENM0027US0...

  • Page 132: Engine Control System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] ENGINE CONTROL SYSTEM (1) Main Switch ON Signal (14) SCV (Suction Control Valve) (25) Coolant Temperature Sensor (31) Temperature Sensor (2) Starter Switch Signal (15) Rail Pressure Sensor (26) Crankshaft Position Sensor (DPF Inlet Exhaust (3) Hand Throttle Sensor (16) Rail...

  • Page 133: Engine Ecu

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM (1) Engine ECU The engine ECU (1) controls the amount, timing, mixture and pressure of fuel that is injected. The engine ECU (1) operates each kind of control based on the signals from each type of sensor. The actuator for controlling the amount, timing and mixture of fuel injection is the injector, while the actuator for controlling fuel pressure is the supply pump.
  • Page 134 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Camshaft Position Sensor The cam position sensor (1) is mounted near the supply pump gear of the gear case and the sensor functions in the same way as the crank position sensor. This sensor detects the teeth of the pulsar gear (2) and the engine ECU uses this signal to calculate the cam angle.
  • Page 135 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Atmosphere Pressure Sensor An atmosphere pressure sensor is installed in the body of the ECU and detects atmospheric pressure close to the ECU. This is provided to prevent changes to combustion status due to changes in atmospheric pressure. (At high altitudes, air pressure is low and air volume is low making complete combustion difficult etc.) NOTE...

  • Page 136: Egr System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. EGR SYSTEM [1] OVERVIEW (1) Air Cleaner (7) Injector (12) Camshaft Position Sensor Exhaust Gas Flow (2) Turbocharger (8) Glow Plug (13) Exhaust-manifold Intake Air Flow (3) EGR Pipe (9) Boost Sensor (14) Intake-manifold (4) EGR Cooler (10) Coolant Temperature Sensor...

  • Page 137: Egr Cooler

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] EGR COOLER The EGR (Exhaust Gas Recirculation) cooler (1) is used to lower combustion temperature and efficiently cool EGR gas, with the aim of reducing the NOx that is in the exhaust gas of diesel engine. The EGR cooler (1) is set between the cylinder head and the EGR valve and returns the cooled exhaust gases to the engine suction side.

  • Page 138: After Treatment System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 7. AFTER TREATMENT SYSTEM [1] AFTER TREATMENT DEVICES (1) Common Rail System (9) Temperature Sensor (12) Temperature Sensor (a) EGR Valve Opening (2) ECU (DOC Inlet Exhaust (DPF Outlet Exhaust (b) Injection Pattern (3) After Treatment Devices Temperature) (T Temperature) (T...

  • Page 139: Dpf Regeneration System (Inhibit Version)

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] DPF REGENERATION SYSTEM (INHIBIT VERSION) (1) Regeneration Mode (Inhibit Version) This system has "Auto Regeneration Mode" in which the DPF can regenerate automatically while working, "Inhibit Mode" in which the auto regeneration is inhibited and "Parked Regeneration Mode" in which the DPF regenerates while the tractor is parked.

  • Page 140: Pm Warning Level (Inhibit Version)

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) PM Warning Level (Inhibit Version) PM warning level 0 to 5 as shown below is set according to the amount of accumulated PM to prompt the operator to perform the required procedure in each level. •...

  • Page 141: Dpf Regeneration System (Default Version)

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Inhibit Mode Engine Warning Buzzer output Remark level limitation Level 0 Normal operation, Regeneration is not required. limitation Regeneration is required, but Auto Regeneration is not Level 1  limitation possible. Regeneration is required, but Auto Regeneration is not ...

  • Page 142: Pm Warning Level (Default Version)

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) PM Warning Level (Default Version) PM warning level 0 to 5 as shown below is set according to the amount of accumulated PM to prompt the operator to perform the required procedure in each level. •...
  • Page 143 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Inhibit Mode Engine Warning Buzzer output Remark level limitation Normal operation, Regeneration is not required.  limitation Regeneration is required, but Auto Regeneration is not permitted.   limitation Parking Regeneration is not possible. Auto Regeneration is prohibited.
  • Page 144 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Diesel Oxidation Catalyst (DOC) An oxidizing catalyst set in front of the Diesel Particulate Filter (DPF) step that uses post injection unburned fuel to actively regenerate the DPF. (1) Diesel Oxidation Catalyst (DOC) 9Y1210824ENM0043US0 Diesel Particulate Filter (DPF)
  • Page 145 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Intake Throttle Valve The amount of air intake is regulated by the angle of the throttle valve and the exhaust temperature is controlled when regenerating the DPF muffler. (1) Intake Throttle Valve 9Y1210824ENM0045US0 Air Flow Sensor The amount of air intake required for control of the...
  • Page 146 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Differential Pressure Sensor The differential pressure sensor is a sensor that detects the pressure differential between the inlet and the outlet of the DPF. The engine ECU calculates the amount of accumulated PM in the DPF using this signal. (1) Differential Pressure Sensor 9Y1210824ENM0048US0 Oil Separator...
  • Page 147 SERVICING CONTENTS 1. TROUBLESHOOTING.........................1-S1 2. SERVICING SPECIFICATIONS ....................1-S4 3. TIGHTENING TORQUES......................1-S10 4. CHECKING AND ADJUSTING....................1-S12 [1] ENGINE BODY........................1-S12 [2] LUBRICATING SYSTEM.....................1-S14 [3] COOLING SYSTEM ......................1-S14 [4] TURBOCHARGER ......................1-S16 [5] PCV VALVE.........................1-S17 [6] EGR COOLER........................1-S17 5. PREPARATION .........................1-S18 [1] SEPARATING DPF MUFFLER FROM TRACTOR .............1-S18 [2] SEPARATING CLUTCH HOUSING AND ENGINE (ROPS TYPE)........1-S24 [3] SEPARATING CLUTCH HOUSING AND ENGINE (CABIN TYPE) ........1-S37 6.

  • Page 148: Troubleshooting

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page No fuel Fill fuel Engine Does Not Start Air in the fuel system Bleed G-44 Water in the fuel system Change fuel and – repair or replace fuel system Fuel pipe or hose clogged...
  • Page 149 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Symptom Probable Cause Solution Page Excessive engine oil Reduce to the Either White or Blue specified level Exhaust Gas Is Observed Piston ring and cylinder worn or stuck Repair or replace 1-S86, 1-S92 Oil pipe clogged or damaged...
  • Page 150 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Symptom Probable Cause Solution Page Engine oil insufficient Fill Low Oil Pressure Oil strainer clogged Clean 1-S66 Relief valve stuck with dirt Repair or replace – Excessive oil clearance of the bearings Replace the metal, 1-S88, bushing or shaft...

  • Page 151: Servicing Specifications

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS ENGINE BODY Item Factory Specification Allowable Limit Valve Clearance (When Cold) 0.18 to 0.22 mm – 0.0071 to 0.0086 in. Compression Pressure 2.95 to 3.23 MPa / 2.35 MPa / (When You Crank the Engine with the Starter) 290 min (rpm)
  • Page 152 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit Valve Spring Free Length 41.7 to 42.2 mm 41.2 mm 1.65 to 1.66 in. 1.62 in. Setting Load / 118 N / 35.0 mm 100 N / 35.0 mm Setting Length 12.0 kgf / 35.0 mm 10.2 kgf / 35.0 mm...
  • Page 153 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit Camshaft Side Clearance 0.070 to 0.22 mm 0.30 mm 0.0028 to 0.0086 in. 0.012 in. Camshaft Bend – 0.01 mm 0.0004 in. Height 33.90 mm 33.85 mm (Intake / Exhaust) 1.335 in.
  • Page 154 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit Second Ring to Ring Groove Clearance 0.0780 to 0.110 mm 0.20 mm 0.00307 to 0.00433 in. 0.0079 in. [D1803-CR-E4, V2403-CR-E4] Clearance 0.0930 to 0.128 mm 0.20 mm [V2403-CR-TE4] 0.00367 to 0.00503 in.
  • Page 155 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit Crankpin to Crankpin Bearing Oil Clearance 0.025 to 0.087 mm 0.20 mm 0.00099 to 0.0034 in. 0.0079 in. • Crankpin O.D. 46.959 to 46.975 mm – 1.8488 to 1.8494 in. •...
  • Page 156 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM COOLING SYSTEM Item Factory Specification Allowable Limit Fan Belt Tension 7.0 to 9.0 mm (0.28 to – 0.35 in.) deflection at 98 N (10 kgf, 22 lbf) of force Thermostat Valve Opening- 80.5 to 83.5 °C –...

  • Page 157: Tightening Torques

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Tractor Item N·m...
  • Page 158 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM ENGINE Dimension × Item N·m kgf·m lbf·ft Pitch Injector clamp screw M8 × 1.25 24 to 27 2.4 to 2.8 18 to 20 Cylinder head cover screw M6 × 1.0 6.86 to 11.3 0.700 to 1.15 5.06 to 8.33 Injection pipe retaining nut...

  • Page 159: Checking And Adjusting

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING [1] ENGINE BODY Compression Pressure 1. After warming-up the engine, remove the air cleaner, muffler, glow lead, and glow plugs. 2. Set a compression tester (1) (Code No.: 07909-39081) with the adaptor (2) to the glow plug hole.
  • Page 160 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Valve Clearance IMPORTANT • You must examine and adjust the valve clearance when the engine is cold. 1. Remove the head cover. 2. Align the "1TC" mark line (3) on the flywheel and timing mark (2) on the housing.

  • Page 161: Lubricating System

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] LUBRICATING SYSTEM Engine Oil Pressure 1. Remove the engine oil pressure switch, and set the oil pressure tester (Code No. : 07916-32032). (Adaptor screw : PT 1/8) 2. Operate the engine for warming-up. 3.
  • Page 162 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Fan Belt Damage and Wear 1. Examine the fan belt for damage. 2. If the fan belt has a damage, replace it. 3. Examine if the fan belt is worn out and sunk in the pulley groove. 4.

  • Page 163: Turbocharger

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Opening-temperature of Thermostat Valve 1. Push down the thermostat valve and put the thread between the valve and the valve seat. 2. Put the thermostat and the thermometer in the container and increase the temperature of the water gradually.

  • Page 164: Pcv Valve

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] PCV VALVE PCV (Positive Crankcase Ventilation) Valve (Oil Separator) 1. Remove the cover (1) and PCV valve (spring and diaphragm) (2). 2. Check whether there is no damage of the spring and/or no breaking or damage of the diaphragm.

  • Page 165: Preparation

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. PREPARATION [1] SEPARATING DPF MUFFLER FROM TRACTOR Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 166 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM DPF Muffler 1. Remove the damper support (2). 2. Disconnect the differential pressure connector (1) and DPF temperature sensor connectors (3). 3. Remove the muffler pipe mounting screws (5). 4. Remove the DPF mounting screws R.H. (4). 5.
  • Page 167 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Filter Comp (DPF) (If necessary) NOTE • Always work in the workshop equipped with a electric hoist (including mobile hoist). • Put a tractor on a stable ground, and set the parking brake. •...
  • Page 168 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) (When reassembling) NOTE • Assemble DOC, DPF, DPF outlet body and DPF stay 1 according to the each alignment mark put on before disassembling. • Temporary tighten stay 1, stay 2 and muffler flange first, and then tighten and adjust them to the specified torque value to avoid stress to the DPF muffler.
  • Page 169 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Judgment of Reuse of Filter Comp (DPF) Before Cleaning (Service Dealer) IMPORTANT • Before ordering to a cleaning contractor, follow the procedure below to make a judgment on whether the DPF is reusable. 1.
  • Page 170 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Judgment of Reuse of Filter Comp (DPF) After Cleaning by Cleaning Contractor IMPORTANT • After the cleaning contractor has cleaned the filter comp DPF (2), they should measure the quantity of remaining ash in the following procedure, and evaluate the reusability.

  • Page 171: Separating Clutch Housing And Engine (Rops Type)

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] SEPARATING CLUTCH HOUSING AND ENGINE (ROPS TYPE) Draining Coolant WARNING • Do not remove the radiator cap when the engine is hot. Then loosen cap slightly to the stop to relieve any excess pressure before removing cap completely.
  • Page 172 L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 173 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 174 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Steering Joint Shaft 1. Remove the steering joint screw (1). 2. Remove the steering joint cover (2) and the steering joint support (3). 3. Remove the steering joint shaft (4). (1) Steering Joint Screw (3) Steering Joint Support (2) Steering Joint Cover (4) Steering Joint Shaft...
  • Page 175 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Tanks 1. Remove the left step. 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (1). 4. Place the disassembling stands under the right and left fuel tanks (5), (8).
  • Page 176 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Wiring Harness 1. Remove the harness clamps and harness cover (1). 2. Disconnect the battery positive cable (2) and battery. 3. Remove the slow blow fuse box (3). 4. Disconnect the alternator terminal B (4) and terminal IG (5). 5.
  • Page 177 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) (13) CCV GND Wiring Harness [A] Left Side (14) CCV Relay [B] Right Side (15) CCV Heater Fuse (16) CCV SB Fuse (17) CCV Heater (OUT) (18) CCV Heater (IN) 9Y1210824CLS0009US0 1-S30 KiSC issued 03, 2016 A...
  • Page 178 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Sensor Connectors 1. Disconnect the air flow sensor connector (1), intake throttle sensor connector (2), electromagnetic pump connector (3) and EGR valve connector (4). 2. Disconnect the common rail sensor connector (5), suction control valve connector (6) and camshaft position sensor connector (7).
  • Page 179 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Meter Panel and Wiring Harness 1. Remove the meter panel (1). 2. Remove the right and left mud shields (2). 3. Remove the fuse box (3) and relay box (8). 4. Disconnect the flasher relay connector (7), buzzer connector (5) and parking brake switch connector (6).
  • Page 180 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Panel Frame 1. Disconnect the multi function combination switch connector (1), side working light connector (6) and main switch connector (4). 2. Disconnect the foot throttle wire (3) and shuttle switch connector (8) (Manual Transmission and GST only) 3.
  • Page 181 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Propeller Shaft 1. Slide the propeller shaft cover (4) and (8) after removing the screws (7). 2. Tap out the spring pins (2), (6) and slide the couplings (1), (5) and then remove the propeller shaft with covers (4), (8). (When reassembling) •...
  • Page 182 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Hoses and Pillar 1. Disconnect the overflow hose (1) and fuel hoses (4), then remove the bracket (3) together with fuel sub tank (2). 2. Disconnect the overflow hose (5), fuel hose (7), (9), (13), then remove the fuel filter (6).
  • Page 183 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Axle Frame 1. [L3560] Remove one of the two engine hooks attached on the left side of the engine and install it on the right rear side of the engine. [except L3560] Install the engine hooks (1), (2).

  • Page 184: Separating Clutch Housing And Engine (Cabin Type)

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] SEPARATING CLUTCH HOUSING AND ENGINE (CABIN TYPE) Draining Coolant WARNING To avoid personal injury or death: • Do not remove radiator cap while coolant is hot. When cool, slowly rotate cap to the first stop and allow sufficient time for excess pressure to escape before removing the cap completely.
  • Page 185 L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 186 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 187 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Steering Joint Shaft 1. Remove the steering joint screw (1). 2. Remove the steering joint cover (2) and the steering joint support (3). 3. Remove the steering joint shaft (4). 4. Disconnect the heater hose (5) from the heater hose (6) and the heater hose (7) from the heater hose (8) inside, then reconnect the heater hose (5), (7) and heater hose (6), (8) to make the loop.
  • Page 188 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Seat and Seat Bracket 1. Disconnect the seat switch connector (1) and seat tilt switch connector (2). 2. Remove the seat (3). 3. Remove the seat suspension (4) together with seat bracket (5). (1) Seat Switch Connector (4) Seat Suspension (2) Seat Tilt Switch Connector...
  • Page 189 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wiring Harness 1. Remove the engine ECU support (2). 2. Disconnect the engine ECU connector (3). 3. Disconnect the range gear sensor connector (4). 4. Disconnect the joint connectors (5). 5. Remove the engine ECU power relay and glow relay (6) from the engine ECU support (2).
  • Page 190 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Tanks 1. Remove the right and left steps (1). 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (5). 4. Place the disassembling stands under the right and left fuel tanks (6), (12).
  • Page 191 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Linkage and Remote Control Valve 1. Remove the remote control valve support (1) together with the couplers. (If equipped.) 2. Remove the top link (2), right and left lift rods (3), lower links (4) and stabilizers (5).
  • Page 192 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Mat, Panel Cover and Linkage 1. Remove the step mat (1) and sound absorber (2). 2. Remove the steering post cover 1 and 2 (4). 3. Remove the panel cover (3). 4. Remove the universal joint screw (5) and disconnect the steering joint shaft (6).
  • Page 193 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Electric Wiring 1. Remove the slow blow fuse box (1). 2. Remove the defogger relay (2) and defogger slow blow fuse (3). (If equipped) 3. Disconnect the battery positive cable (4) and battery (6). 4.
  • Page 194 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Air Cleaner and Radiator Hose 1. Remove the cramps and hoses of oil separator (3), then remove the oil separator (3). 2. Remove the intake hose (1). 3. Remove the air cleaner bracket (5) together with air cleaner (4). 4.
  • Page 195 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Air Conditioner Parts and Cabin Assembly 1. Disconnect the 1P connector (1) from compressor (2). 2. Loosen the tension pulley mounting nut, the adjusting bolt (4) and remove the air conditioner belt (5). 3.
  • Page 196 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Pipe 1. Remove the front loader pipes (4). 2. Disconnect the suction hose (1) and suction pipe (6). 3. Remove the main delivery pipe (3), power steering delivery pipe (2) and delivery pipe (5). (When reassembling) 90.0 to 108 N·m Front loader pipe retaining...
  • Page 197 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Wiring Harness Connector 1. Disconnect the injector connectors (1). 2. Disconnect the glow plug connector (4). 3. Disconnect the boost sensor connector (2), EGR valve connector (3) and intake throttle sensor connector. 4.
  • Page 198 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Propeller Shaft 1. Slide the propeller shaft cover (4) and (8) after removing the screws (7). 2. Tap out the spring pins (2), (6) and slide the couplings (1), (5) and then remove the propeller shaft with covers (4), (8). (When reassembling) •...

  • Page 199: Disassembling And Assembling

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. DISASSEMBLING AND ASSEMBLING [1] OUTER PARTS Outer Parts of Engine 1. Remove the engine hooks (1) and (2). 2. Remove the starter motor (3). 3. Remove the hydraulic pump (4) with pump holder and regulating valve.

  • Page 200: Turbocharger And Egr

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] TURBOCHARGER AND EGR NOTE • When you remove or install the turbocharger assembly, do not let dust, dirt and other unwanted materials in the oil pipes. • After you replace the turbocharger assembly, fill clean engine oil through the oil filter port of the turbocharger.

  • Page 201: Common Rail

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] COMMON RAIL Common Rail and Injection Pipes CAUTION • Do not loosen the injection pipe when the fuel is under high pressure (within five minutes of stopping the engine). NOTE • Do not remove the pressure limiter (5) and rail pressure sensor (2) from the common rail (4).
  • Page 202 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Camshaft Position Sensor 1. Remove the camshaft position sensor mounting screw. 2. Remove the camshaft position sensor (1). (When reassembling) • Replace the O-ring with a new one. 0.2 to 1.3 mm Air Gap Factory specification 0.008 to 0.059 in.

  • Page 203: Cylinder Head And Valves

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Boost Sensor IMPORTANT • Be careful not to damage the sensor when removing the boost sensor. 1. Remove the boost sensor mounting screw (1). 2. Remove the boost sensor (2). (When reassembling) •...
  • Page 204 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Overflow Pipe and Injectors 1. Remove the overflow pipe (1). 2. Remove the injector clamp (2). 3. Remove the injector (3) and its gasket (4). IMPORTANT • Do not disassemble the injector (3). •...
  • Page 205 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Rocker Arm and Push Rods 1. Remove the screws of the rocker arm bracket. 2. Remove the rocker arm assembly (1). 3. Remove the push rods (2). (When reassembling) • When you put the push rods (2) on the tappets (3), make sure that their ends are correctly engaged with the grooves.
  • Page 206 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Cylinder Head 1. Remove the cylinder head screw in the sequence of (n or r) to (a). 2. Lift up the cylinder head (3) to remove. 3. Remove the cylinder head gasket (4). (When reassembling) •...
  • Page 207 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) IMPORTANT • After you replace an item below, you have to select a cylinder head gasket. – Piston – Piston pin – Small end bushing – Connecting rod – Crankpin bearings To select the cylinder head gasket 1.

  • Page 208: Thermostat

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Valves 1. Remove the valve caps (3). 2. Push the valve spring retainer with the valve spring replacer (1) and remove the valve spring collets (4). 3. Remove the valve spring retainer (5) and valve spring (6). 4.

  • Page 209: Supply Pump

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [7] SUPPLY PUMP Supply Pump CAUTION • Do not loosen the injection pipe when the fuel is under high pressure (Within five minutes of stopping the engine). 1. Remove the intake throttle valve assembly (2). 2.

  • Page 210: Gear Case And Timing Gear

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Oil Cooler 1. Remove the water pipe (1). 2. Remove the oil filter cartridge (2). 3. Remove the oil cooler joint screw (4). 4. Remove the oil cooler (3). 40 to 44 N·m Tightening torque Oil cooler joint screw 4.0 to 4.5 kgf·m...
  • Page 211 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Gear Case 1. Remove the hour meter gear case (if attached). 2. Remove the gear case (1). 3. Remove the O-rings (2). (When reassembling) • Replace the gear case gasket and O-rings (2). •...
  • Page 212 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Camshaft (D1803-CR-E4) 1. Remove the camshaft set screws (1) and pull out the camshaft (2). (When reassembling) • When you install the idle gear, align the marks on the gears. 24 to 27 N·m Tightening torque Camshaft set screw 2.4 to 2.8 kgf·m...

  • Page 213: Piston And Connecting Rod

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Oil Pump 1. Remove the nut. 2. Pull out the oil pump drive gear (2) with a gear puller (1). 3. Remove the 4 mounting screws of the oil pump. Remove the oil pump (3).
  • Page 214 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Pistons 1. Fully clean the carbon (1) in the cylinders. 2. Remove the connecting rod cap (3). 3. Turn the flywheel and move the piston to top dead center. 4. Lightly tap the piston from the bottom of the crankcase with the grip of a hammer to pull the piston out.
  • Page 215 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) 40 to 45 N·m Tightening torque Connecting rod screw 4.1 to 4.5 kgf·m 30 to 33 lbf·ft NOTE • Apply engine oil to the connecting rod screws and lightly screw it in by hand, then tighten it to the specified torque. (6) Code Number (A) Top Ring Gap (7) Piston Ring Compressor...
  • Page 216 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Piston Ring and Connecting Rod 1. Remove the piston rings (1), (2) and (3) with a piston ring tool. 2. Remove the piston pin (8) to disconnect the connecting rod (6) from the piston (5). (When reassembling) •...

  • Page 217: Flywheel And Crankshaft

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [11] FLYWHEEL AND CRANKSHAFT Flywheel 1. Attach the stopper to the flywheel (1). 2. Remove 2 flywheel screws. 3. Put the 2 flywheel guide screws (2) in the holes. 4. Remove all the flywheel screws. 5.
  • Page 218 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Measuring Angular Deviation between Crankshaft TDC and Crank Position Sensor Detected TDC IMPORTANT • Perform this correction every time the crank shaft or flywheel is replaced. 9Y1210824ENS0061US0 Confirmation of Top Dead Center 1.
  • Page 219 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Confirmation of Crank Position Sensor Top Dead Center Detection Position 1. Align the reference (17th for 3 cylinder models or 20th for 4 cylinder models) pulser hole (5) from the area where there is no pulser hole (1) on the outer circumference of the flywheel (2) with the crank position sensor mounting hole (4) on the flywheel housing (3).
  • Page 220 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Injection Timing Correction Amount The difference A between the top dead center mark (1) and the crank position sensor top dead center detection position mark (2) is the correction amount for fuel injection timing. Calculate the correction value referencing the following and using a diagnostics tool, overwrite the injection timing correction amount in the "data overwrite/confirmation".
  • Page 221 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Crankshaft NOTE • Before you disassemble, measure the side clearance of crankshaft. Measure it when you assemble again. [D1803-CR-E4] 1. Remove the screw 2 (1) of the main bearing case. 2. Turn the crankshaft to set the crankpin of the third cylinder to the bottom dead center.
  • Page 222 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Main Bearing Case Assembly 1. Remove the screws 1 of the main bearing case. Then remove the main bearing case (7). 2. Remove other main bearing cases as above. (When reassembling) • Clean the oil channel in the main bearing case. •...

  • Page 223: Servicing

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM 7. SERVICING [1] CYLINDER HEAD AND VALVES Top Clearance 1. Remove the cylinder head. 2. With the piston at TDC, use grease to affix three or four plastigauges (1) of a diameter 1.5 mm (0.059 in.) × 5.0 to 7.0 mm (0.20 to 0.27 in.) long to the crown of the piston;...
  • Page 224 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Cylinder Head Flaw 1. Prepare an air spray red check. 2. Clean the surface of the cylinder head with detergent (2). 3. Apply some red permeative liquid (1) on the cylinder head surface.
  • Page 225 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Replacement of Valve Guide (When removing) 1. Press out the used valve guide with the valve guide replacing tool. (See page "SPECIAL TOOLS".) (When installing) 1. Clean the new valve guide and valve guide bore, and apply engine oil to them.
  • Page 226 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Correction of Valve and Valve Seat NOTE • Before you correct the valve and seat, examine the valve stem and measure the I.D. of the valve guide section. Repair them if necessary. •...
  • Page 227 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Free Length and Tilt of Valve Spring 1. Measure the free length (B) of valve spring with a vernier calipers. 2. If the measurement is less than the allowable limit, replace it. 3.
  • Page 228 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Push Rod Bend 1. Put the push rod on V blocks. 2. Set a dial indicator with its point on the middle of the push rod. 3. Turn the push rod slowly and read the variation on the indicator. 4.

  • Page 229: Timing Gears

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] TIMING GEARS Timing Gear Backlash 1. Set a dial indicator (lever type) with its point on the gear tooth. 2. Hold the mating gear and move the gear to measure the backlash.
  • Page 230 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Side Clearance of Camshaft 1. Set a dial indicator with its point on the camshaft. 2. Move the cam gear to the front and rear to measure the side clearance. 3. If the measurement is more than the allowable limit, replace the camshaft stopper.
  • Page 231 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Oil Clearance of Balancer Shaft Journal (V2403-CR-E4 and V2403-CR-TE4) 1. Measure the balancer shaft journal O.D. with an outside micrometer. 2. Measure the cylinder block bore I.D. for balancer shaft with an inside micrometer or cylinder gauge.

  • Page 232: Piston And Connecting Rod

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Replacement of Idle Gear Bushing (When removing) 1. Press out the used idle gear bushing with the replacing tool. (See page G-55.) (When installing) 1. Clean a new idle gear bushing and idle gear bore, and apply engine oil to them.
  • Page 233 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Connecting Rod Alignment NOTE • Make sure that the oil clearance of the small end bushing is less than the allowable limit. 1. Install the piston pin into the connecting rod. 2. Install the connecting rod on the alignment tool of the connecting rod.

  • Page 234: Crankshaft

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Clearance between Piston Ring and Groove 1. Clean the rings and the ring grooves, and install each ring in its groove. 2. Measure the clearance between the ring and the groove with a feeler gauge or depth gauge.
  • Page 235 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Crankshaft Bend 1. Hold the 2 end journals of crankshaft with V blocks on the surface plate. 2. Set a dial indicator with its point on the middle journal. 3. Turn the crankshaft slowly and read the variation on the indicator.
  • Page 236 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Oil Clearance between Crankshaft Journal and Crankshaft Bearing 1 1. Measure the O.D. of the crankshaft journal with an external micrometer. 2. Measure the I.D. of the crankshaft bearing 1 with an internal micrometer.
  • Page 237 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Oil Clearance between Crankshaft Journal and Crankshaft Bearing 2 1. Put a strip of plastigauge on the center of the journal. 2. Install the bearing case and tighten the baring case screws 1 to the specified torque, and remove the bearing case again.
  • Page 238 ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM Replacement of Crankshaft Sleeve 1. Remove the used crankshaft sleeve (3). 2. Set the sleeve guide (2) to the crankshaft (5). 3. Set the stopper (1) to the crankshaft (5) (see the figure). 4.

  • Page 239: Cylinder

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] CYLINDER Cylinder Wear 1. Measure the I.D. of the cylinder at the 6 positions (see figure) with a cylinder gauge. 2. Find the maximum and minimum inner diameters. 3. Find the difference between the maximum and the minimum inner diameters.

  • Page 240: Oil Pump

    ENGINE L3560, L4060, L4760, L5060, L5460, L6060, WSM [6] OIL PUMP Rotor Lobe Clearance 1. Measure the clearance between the lobes of the inner rotor and the outer rotor with a feeler gauge. 2. Measure the clearance between the outer rotor and the pump body with a feeler gauge.
  • Page 241 CLUTCH KiSC issued 03, 2016 A...
  • Page 242 MECHANISM CONTENTS 1. FEATURE ........................... 2-M1 KiSC issued 03, 2016 A...
  • Page 243 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. FEATURE Manual Transmission / GST The dry single plate with diaphragm spring type clutch is adapted for manual transmission and GST. (1) Clutch Disc (9) Clutch Lever Shaft (2) Pressure Plate Assembly (10) Flywheel (3) Release Fork (11) Pressure Plate...
  • Page 244 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Unlike the manual transmission / GST, the HST is not equipped with a clutch. Only a clutch coupling is adapted. (1) Clutch Coupling (4) Flywheel (2) Shaft Case (5) Main Shaft (3) Gasket 9Y1210824CLM0002US0 2-M2 KiSC issued 03, 2016 A...
  • Page 245 SERVICING CONTENTS 1. TROUBLESHOOTING.........................2-S1 2. SERVICING SPECIFICATIONS ....................2-S2 3. TIGHTENING TORQUES......................2-S3 4. CHECKING AND ADJUSTING....................2-S4 5. PREPARATION ...........................2-S5 [1] SEPARATING CLUTCH HOUSING FROM ENGINE (ROPS TYPE)........2-S5 [2] SEPARATING CLUTCH HOUSING AND ENGINE (CABIN TYPE) ........2-S15 6. DISASSEMBLING AND ASSEMBLING ..................2-S27 7.

  • Page 246: Troubleshooting

    CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Clutch pedal free travel excessive Adjust 2-S4 Clutch Drags Dust on clutch disc generated from clutch disc Remove rust – facing Release fork broken Replace 2-S27 Clutch disc or pressure plate warped...

  • Page 247: Servicing Specifications

    CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Clutch Pedal Free travel 20 to 30 mm – 0.78 to 1.18 in. Clutch Disc Boss and Gear Shaft Backlash – 2.0 mm (Manual Transmission and GST) (Displacement 0.079 in.

  • Page 248: Tightening Torques

    CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) [ROPS Model] Item N·m...

  • Page 249: Checking And Adjusting

    CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING Clutch Pedal Free Travel (Manual Transmission and GST Only) CAUTION • When checking, park the tractor on flat ground, apply the parking brake, stop the engine and remove the key. 1.

  • Page 250: Preparation

    L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 251 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 252 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Steering Joint Shaft 1. Remove the steering joint screw (1). 2. Remove the steering joint cover (2) and the steering joint support (3). 3. Remove the steering joint shaft (4). (1) Steering Joint Screw (3) Steering Joint Support (2) Steering Joint Cover (4) Steering Joint Shaft...
  • Page 253 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Tanks 1. Remove the left step. 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (1). 4. Place the disassembling stands under the right and left fuel tanks (5), (8).
  • Page 254 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Wiring Harness 1. Remove the harness clamps and harness cover (1). 2. Disconnect the battery positive cable (2) and battery. 3. Remove the slow blow fuse box (3). 4. Disconnect the alternator terminal B (4) and terminal IG (5). 5.
  • Page 255 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) (13) CCV GND Wiring Harness [A] Left Side (14) CCV Relay [B] Right Side (15) CCV Heater Fuse (16) CCV SB Fuse (17) CCV Heater (OUT) (18) CCV Heater (IN) 9Y1210824CLS0009US0 2-S10 KiSC issued 03, 2016 A...
  • Page 256 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Sensor Connectors 1. Disconnect the air flow sensor connector (1), intake throttle sensor connector (2), electromagnetic pump connector (3) and EGR valve connector (4). 2. Disconnect the common rail sensor connector (5), suction control valve connector (6) and camshaft position sensor connector (7).
  • Page 257 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Meter Panel and Wiring Harness 1. Remove the meter panel (1). 2. Remove the right and left mud shields (2). 3. Remove the fuse box (3) and relay box (8). 4. Disconnect the flasher relay connector (7), buzzer connector (5) and parking brake switch connector (6).
  • Page 258 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Panel Frame 1. Disconnect the multi function combination switch connector (1), side working light connector (6) and main switch connector (4). 2. Disconnect the foot throttle wire (3) and shuttle switch connector (8) (Manual Transmission and GST only) 3.
  • Page 259 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Propeller Shaft 1. Slide the propeller shaft cover (4) and (8) after removing the screws (7). 2. Tap out the spring pins (2), (6) and slide the couplings (1), (5) and then remove the propeller shaft with covers (4), (8). (When reassembling) •...

  • Page 260: Separating Clutch Housing And Engine (Cabin Type)

    L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 261 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Draining Coolant WARNING To avoid personal injury or death: • Do not remove radiator cap while coolant is hot. When cool, slowly rotate cap to the first stop and allow sufficient time for excess pressure to escape before removing the cap completely.
  • Page 262 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 263 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Steering Joint Shaft 1. Remove the steering joint screw (1). 2. Remove the steering joint cover (2) and the steering joint support (3). 3. Remove the steering joint shaft (4). 4. Disconnect the heater hose (5) from the heater hose (6) and the heater hose (7) from the heater hose (8) inside, then reconnect the heater hose (5), (7) and heater hose (6), (8) to make the loop.
  • Page 264 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Seat and Seat Bracket 1. Disconnect the seat switch connector (1) and seat tilt switch connector (2). 2. Remove the seat (3). 3. Remove the seat suspension (4) together with seat bracket (5). (1) Seat Switch Connector (4) Seat Suspension (2) Seat Tilt Switch Connector...
  • Page 265 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wiring Harness 1. Remove the engine ECU support (2). 2. Disconnect the engine ECU connector (3). 3. Disconnect the range gear sensor connector (4). 4. Disconnect the joint connectors (5). 5. Remove the engine ECU power relay and glow relay (6) from the engine ECU support (2).
  • Page 266 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Tanks 1. Remove the right and left steps (1). 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (5). 4. Place the disassembling stands under the right and left fuel tanks (6), (12).
  • Page 267 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Linkage and Remote Control Valve 1. Remove the remote control valve support (1) together with the couplers. (If equipped.) 2. Remove the top link (2), right and left lift rods (3), lower links (4) and stabilizers (5).
  • Page 268 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Mat, Panel Cover and Linkage 1. Remove the step mat (1) and sound absorber (2). 2. Remove the steering post cover 1 and 2 (4). 3. Remove the panel cover (3). 4. Remove the universal joint screw (5) and disconnect the steering joint shaft (6).
  • Page 269 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Dismounting Cabin 1. Remove the wiring harness cover (1) and wiring harness tighteners (2). 2. Remove the cabin outer roof (3). 3. Secure the cabin with nylon straps and hoist. 4. Remove the cabin mounting bolts and nuts. 5.
  • Page 270 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Pipe 1. Remove the front loader pipes (4). 2. Disconnect the suction hose (1) and suction pipe (6). 3. Remove the main delivery pipe (3), power steering delivery pipe (2) and delivery pipe (5). (When reassembling) 90.0 to 108 N·m Front loader pipe retaining...
  • Page 271 CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Propeller Shaft 1. Slide the propeller shaft cover (4) and (8) after removing the screws (7). 2. Tap out the spring pins (2), (6) and slide the couplings (1), (5) and then remove the propeller shaft with covers (4), (8). (When reassembling) •...

  • Page 272: Disassembling And Assembling

    CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. DISASSEMBLING AND ASSEMBLING Clutch Assembly (Manual Transmission and GST) 1. Remove the clutch from the flywheel. (When reassembling) • Direct the shorter end of the clutch disc boss toward the flywheel. •...

  • Page 273: Servicing

    CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM 7. SERVICING [1] MANUAL TRANSMISSION AND GST Backlash between Clutch Disc Boss and Gear Shaft 1. Mount the clutch disc to the gear shaft. 2. Hold the gear shaft so that it may not turn. 3.

  • Page 274: Hst

    CLUTCH L3560, L4060, L4760, L5060, L5460, L6060, WSM Pressure Plate Flatness 1. Place a straight edge on the pressure plate and measure clearance with a feeler gauge at several points. 2. If the clearance exceeds the allowable limit, replace it. 3.
  • Page 275 TRANSMISSION KiSC issued 03, 2016 A...
  • Page 276 MECHANISM CONTENTS 1. STRUCTURE..........................3-M1 [1] MANUAL TRANSMISSION ....................3-M1 [2] GLIDE SHIFT TRANSMISSION (GST) ................3-M2 [3] HYDROSTATIC TRANSMISSION (HST) ................3-M3 2. MANUAL TRANSMISSION ......................3-M4 [1] POWER TRAIN FOR TRAVELING GEAR ................3-M4 (1) Main Gear Shift Section....................3-M4 (2) Shuttle Shift Section .......................

  • Page 277: Structure

    L3560, L4060, L4760, L5060, L5460, L6060, WSM TRANSMISSION 1. STRUCTURE [1] MANUAL TRANSMISSION (1) Main Gear Shift Section (2) PTO Clutch Section (3) Shuttle Shift Section (4) Range Gear Shift Section (5) Front Wheel Drive Shift Section 3-M1 KiSC issued 03, 2016 A...
  • Page 278 L3560, L4060, L4760, L5060, L5460, L6060, WSM TRANSMISSION [2] GLIDE SHIFT TRANSMISSION (GST) (1) Main Gear Shift Section (3) PTO Clutch Section (4) Sub-range Gear Shift Section (5) Shuttle Shift Section (6) Range Gear Shift Section (7) Front Wheel Drive Shift Section (2) Clutch Pack for GST 3-M2 KiSC issued 03, 2016 A...
  • Page 279 L3560, L4060, L4760, L5060, L5460, L6060, WSM TRANSMISSION [3] HYDROSTATIC TRANSMISSION (HST) (1) Hydrostatic Transmission Section (2) PTO Clutch Section (3) Range Gear Shift Section (4) Front Wheel Drive Section [A] All CABIN Model [B] All ROPS Model 3-M3 KiSC issued 03, 2016 A...

  • Page 280: Main Gear Shift Section

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. MANUAL TRANSMISSION [1] POWER TRAIN FOR TRAVELING GEAR The transmission consists of a series of gears and shafts as shown in previous page. The traveling system consists of main gear shift section, shuttle shift section, range gear shift section and front wheel drive section.

  • Page 281: Range Gear Shift Section

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Range Gear Shift Section The range gear shift section is located in the differential gear case, and it uses constant mesh. (1) Shuttle Gear Shaft (6) Counter Gear (2) Gear for Low (7) Spiral Bevel Pinion (3) Shifter (4) Gear for High...

  • Page 282: Shift Linkage Mechanism

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] SHIFT LINKAGE MECHANISM (1) Main Gear Shift Lever The links are connected from the shift lever (6) to the shift forks (1), (2) as shown in the figure. Each speed from the 1st to 4th can be changed by a single shift lever (6).

  • Page 283: Range Gear Shift Lever

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Range Gear Shift Lever The links from the shift lever (1) to the shift fork (5) are connected as shown in the figure. When the shift lever (1) is moved to the "A" side, the shift fork (5) is moved to the "A"...

  • Page 284: Glide Shift Transmission (Gst)

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. GLIDE SHIFT TRANSMISSION (GST) [1] CHARACTERISTIC AND SYSTEM OUTLINE In addition to the former GST system that controls the gear shifting and clutch operation hydraulically, the GST system of L60 series tractor has the function to control these operations electrically.

  • Page 285: Power Train

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] POWER TRAIN (1) Main Shift Section (3) Sub-range Shift Section (4) Shuttle Shift Section (5) Main Range Shift Section (2) GST Clutch Pack The transmission consists of the fully synchronized gear shifting and the hydraulic clutch as shown above figure. And the double cone type synchromesh is adapted on L side of main range shift section (5).

  • Page 286: Electrical Control System

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] ELECTRICAL CONTROL SYSTEM (1) Electrical Control An electrical control of GST system is as follows. 1. Shift the GST lever and shuttle lever to desired position. 2. The output voltage of selected gear shift position is output to microcomputer of the main ECU by lever sensor.

  • Page 287: Hydraulic Control System

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] HYDRAULIC CONTROL SYSTEM (1) Hydraulic Circuit and System Outline (1) Regulating Valve Assembly (11) Solenoid Valve 5 (19) 3-4 Shift Check Valve To Steering Controller (2) Hydraulic Pump (Sub-range Shift) (20) 1-2 Shift Check Valve From Steering Controller (3) Hydraulic Oil Filter (12) Shift Piston...
  • Page 288 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) 7. Because pressure in the GST clutch (27) is gradually pressurized by function of proportional reducing valve (26), clutch is able to engage without shock and smoothly. 8. When the pressure in the circuit rises to the system pressure, pressure is kept. And the GST clutch is kept at engaging condition until the next gear shifting.

  • Page 289: Construction And Function Of Components

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Construction and Function of Components [A] Regulating Valve The oil from the hydraulic pump for the power steering system flows to the GST circuit to set the pressure of the circuit. Other oil flows to the power steering circuit.
  • Page 290 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [B] GST Valve GST Valve Assembly The GST valve assembly is installed at the left side of the transmission mid case. In the GST valve assembly, many parts comprising the system are installed, including the solenoid valves, shift pistons, shift check valves, low-pass valve, proportional reducing valve, clutch valve, check valves, sensor and switches.
  • Page 291 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shift Piston The shift pistons (1), (2), (3), (4) are actuated by the oil distributed by the each solenoid valve. At the tip of these shift pistons (1), (2), (3) are installed the shifters (5), which are connected to each shift rod and shift the gear.
  • Page 292 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shift Check Valve The shift check valves (2), (3), (4), (5), (6) are provided on each shift piston and the shuttle shift rod. From the start to the end of gear shifting, the shift check valves (2), (4), (5), (6) of the shift pistons are opened because the ball (9) of the check pin (18) is on the straight portion, the oil in the pilot circuit of the clutch...
  • Page 293 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Low-pass Valve After completion of the gear shifting, the low-pass valve (8) opens immediately to flow oil into the GST clutch (9), to promote the engagement of the clutch. When the gear shifting starts, the oil in the GST clutch (9) passes the clutch valve (7) to be drained into the tank.
  • Page 294 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Proportional Reducing Valve After the gear shifting is completed, this valve has function which gradually rises the pressure in the clutch (4) in order to make a clutch engaging for without shock and smoothly.
  • Page 295 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Clutch Valve The clutch valve (5) changes the flow of the oil flowing to the GST clutch to do "ENGAGE" / "DISENGAGED" of the clutch. Except for during gear shifting, the oil of the pilot circuit flows in from the A-port to push the spool to the right when the pilot circuit is pressurized.

  • Page 296: Shift Linkage Mechanism

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [C] GST Clutch The GST clutch is hydraulic multiple plate type and is provided between the counter shaft (3) and the shuttle shaft (8), and it "engages" and "disengages" the power from the engine. This is controlled by the operation of clutch valve (2).

  • Page 297: Hydrostatic Transmission (Hst)

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. HYDROSTATIC TRANSMISSION (HST) [1] POWER TRAIN The transmission of this model consists of a series of gears and shafts as shown in previous page. The traveling system chiefly consists of hydrostatic transmission section, range gear shift section and front wheel drive section. 9Y1210824TRM0027US0 (1) Structure (1) Input Shaft...
  • Page 298 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (1) Input Shaft (10) Piston (Pump) (19) Check and High Pressure Sectional View X-X (2) Servo Piston (11) Piston (Hi) Relief Valve (Foward) Sectional View Y-Y (3) Feedback Rod (12) Cylinder Block (Motor) (20) Check and High Pressure Sectional View Z-Z (4) Proportional Valve...
  • Page 299 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Oil Flow (1) HST Assembly (8) Motor Cylinder Block (15) Oil Cooler To PTO Clutch Valve (2) Case Relief Valve (9) Piston H (16) Hydraulic Pump To Steering Controller (3) Pump Cylinder Block (10) Piston L (17) Proportional Valve From Steering Controller...
  • Page 300 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Function of Components [A] Servomechanism (1) Servo Piston (5) Piston Adjusting Screw To Reverse Side Pump Port (2) Feedback Rod (Connected to (6) Spring To Forward Side Tank Port Swashplate Position Sensor) (7) Proportional Valve (Forward) Slit for Connection of (3) Swashplate Position Sensor...

  • Page 301: Operation

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Operation [A] Stage 1  When the HST pedal is in the neutral position [Tractor Condition] HST pedal: Neutral Position Hi-Lo select lever: Lo (1) Pump Swashplate (12) Piston H (24) PTO Valve A Port (2) Pump Piston (13) Piston L...
  • Page 302 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [B] Stage 2  When the pedal is pressed toward the forward side [Tractor Condition] HST pedal: Forward Position Hi-Lo select lever: Lo (1) Pump Swashplate (12) Piston H (24) PTO Valve A Port (2) Pump Piston (13) Piston L...
  • Page 303 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [C] Stage 3  When the pedal is pressed toward the reverse side [Tractor Condition] HST pedal: Reverse Position Hi-Lo select lever: Lo (1) Pump Swashplate (12) Piston H (24) PTO Valve A Port (2) Pump Piston (13) Piston L...
  • Page 304 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [D] Stage 4  When the pedal is located on the forward side and the Hi-Lo change lever is set to "Hi" (The lamp of the rabbit lights up and the turtle goes off) [Tractor Condition] HST pedal: Forward Position Hi-Lo select lever: Lo →...
  • Page 305 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Signals are sent from the Hi-Lo change lever switch to the ECU. Then the signals are sent from the ECU to the Hi-Lo change valve. Then the Hi-Lo solenoid valve is opened. As a result, the position of the two-speed change spool is changed with charge oil to the position shown in the drawing.
  • Page 306 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [E] Stage 5  When the pedal is located on the forward side and the Hi-Lo change lever is changed from "Hi" to "Lo" (The lamp of the turtle lights up and the rabbit goes off) [Tractor Condition] HST pedal: Forward Position Hi-Lo select lever: Lo →...
  • Page 307 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Signals are sent from the Hi-Lo change lever switch to the ECU. Then the signals are sent from the ECU to the Hi-Lo change valve. As a result, the Hi-Lo solenoid valve is closed and the two-speed change spool is changed by the force of the spring to the position shown in the drawing.
  • Page 308 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [F] Stage 6  When loads are applied with the pedal located on the forward side and the engine stall prevention function is activated (Stall Guard lamp lights up on the panel) [Tractor Condition] HST pedal: Forward Position Hi-Lo select lever: Lo...
  • Page 309 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Since loads are applied on the motor shaft, the pressure between "A" and "C" is increased. With the pressure between "A" and "C" increased, the pump receives more resistance, thereby decreasing the engine speed. The engine stall prevention function is controlled by the engine speed sensor and accelerator opening sensor.
  • Page 310 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [G] Stage 7  When loads are applied and the engine stall prevention function is activated with the HST pedal located on the forward side, the Hi-Lo lever sets at "Hi" position, and the automatic gear shifting sets at "ON" (Stall Guard lamp and AUTO H-DS lamp light up on the panel) [Tractor Condition] HST pedal: Forward Position...
  • Page 311 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) With loads applied on the motor shaft, the pressure between "A" and "C" is increased. With the pressure between "A" and "C" increased, the pump receives more resistance, thereby decreasing the engine speed. Since the engine stall prevention function starts to operate first, the ECU controls the proportional control valve according to signals from the engine speed sensor and accelerator opening sensor so that the engine torque and loads on the HST should keep well-balanced relation.
  • Page 312 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [H] Stage 8  When loads are applied and the engine stall prevention function is activated with the HST pedal located on the forward side, the Hi-Lo lever sets at "Hi", and the automatic gear shifting sets at "ON" (Stall Guard lamp and AUTO H-DS lamp light up on the panel) [Tractor Condition] HST pedal: Forward Position...
  • Page 313 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) 1. The swashplate on the motor side is changed to the Lo side (The lamp of the turtle lights up and the rabbit lamp goes off). 2. At the same time, the swashplate on the pump side is inclined toward the speed increasing side (To achieve smooth shift transmission).

  • Page 314: Range Gear Shift Section

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [K] Stage 11  Cruise Control Switch [Tractor Condition] HST Pedal : Forward Position Cruise Control Switch : "Set" and "Increase" The cruise control function is to keep the swashplate at the same angle on the pump side. As the result, the tractor keeps same traveling speed.

  • Page 315: Front Wheel Drive Section

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (6) Front Wheel Drive Section Front wheel drive section is located in the differential gear case. 2 wheel drive or 4 wheel drive is selected by operating the front wheel drive lever to shift the shifter gear (6).

  • Page 316: Pto System

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. PTO SYSTEM [1] STRUCTURE (1) PTO Gear Shaft 1 (4) PTO Counter Shaft (7) Output Shaft (Motor Shaft) [A] Manual Transmission and (2) PTO Gear Shaft 2 (5) PTO Drive Shaft (8) PTO Gear Shaft 1 (3) PTO Clutch Pack (6) PTO Shaft...
  • Page 317 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Circuit The oil from the regulator valve (4) flows into the PTO clutch solenoid valve (6). When PTO switch is at "OFF" position, the oil flows is stopped by PTO solenoid valve (6). When PTO switch is at "ON"...
  • Page 318 SERVICING CONTENTS 1. TROUBLESHOOTING.........................3-S1 [1] GENERAL ..........................3-S1 [2] ERROR DISPLAY ON THE INTELLIPANEL .................3-S3 [3] PTO SYSTEM ........................3-S12 2. SERVICING SPECIFICATIONS ....................3-S13 3. TIGHTENING TORQUES......................3-S16 4. CHECKING AND ADJUSTING....................3-S20 [1] PTO CLUTCH........................3-S20 [2] GLIDE SHIFT TRANSMISSION (GST) ................3-S21 (1) Electrical Adjusting [GST Fine-adjustment with Electronic Instrument Panel (Intellipanel)] ........................3-S21 (2) Hydraulic Checking......................3-S23 [3] HYDROSTATIC TRANSMISSION (HST) ................3-S27...
  • Page 319 (1) Bearing, Gear and Shaft ....................3-S132 (2) PTO Clutch ........................3-S132 (3) Differential Gears......................3-S132 (4) HST..........................3-S132 KiSC issued 03, 2016 A...
  • Page 320 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING [1] GENERAL Reference Symptom Probable Cause Solution Page Transmission fluid insufficient Fill Excessive Transmission Noise Gear worn or backlash improper Replace 3-S127 Bearing worn or broken Replace 3-S123 Shift fork worn Replace 3-S123 Spline worn...
  • Page 321 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Symptom Probable Cause Solution Page Differential lock pedal return spring weaken or Replace – Differential Lock damaged Pedal Does Not Return Differential lock shifter pin bent or damaged Replace 3-S75, 3-S94, 3-S120 Differential lock fork shaft bent Replace...

  • Page 322: Error Display On The Intellipanel

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] ERROR DISPLAY ON THE INTELLIPANEL Error Display for Manual Transmission Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • CANbus wiring is disconnected Check the communication line – or short-circuited Communication error •...
  • Page 323 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Error Display for GST Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • CANbus wiring is disconnected Check the communication line – or short-circuited Communication error • No signals from main ECU for ERROR No.
  • Page 324 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • Solenoid output terminal's Able to travel at speeds other voltage is out of specification than 1, 7 and 8 (Forward) or 1 –...
  • Page 325 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Error Display for HST Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • CANbus wiring is disconnected Check the communication line – or short-circuited Communication error • No signals from main ECU for ERROR No.
  • Page 326 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • Output voltage of proportional Travel motion is possible on – valve terminal or return current the backward side only is out of specification Check the connector of 9-S58 •...
  • Page 327 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Error Message Does not Indicate on LCD (GST) Reference Symptom Probable Cause Solution Page Oil level is low Check oil level or fill The Tractor Does Not oil to proper level Move While Shifted Clogged hydraulic oil filter Replace oil filter G-31...
  • Page 328 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Symptom Probable Cause Solution Page Oil level is too low Check oil level or fill Quick Engagement oil to proper level While Starting or Large shock While Transmission oil quality is too low Fill correct fluid Shifting GST valve improperly adjusted...
  • Page 329 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Error Message Does not Indicate on LCD (HST) Reference Symptom Probable Cause Solution Page Oil level is low Check oil level or fill System Will Not oil to proper level Operate in Either Direction Charge pressure is too low Solution order...
  • Page 330 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Symptom Probable Cause Solution Page Oil level is too low Check oil level or fill Loss of Power oil to proper level Charge pressure is too low Solution order G-22 1. Replace oil filter cartridge 2.

  • Page 331: Pto System

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] PTO SYSTEM PTO CLUTCH Reference Symptom Probable Cause Solution Page Operating pressure is low Adjust 3-S20 PTO Clutch Slip PTO clutch valve malfunctioning Repair or replace 3-S66 Clutch disc or drive plate excessively worn Replace 3-S68 Deformation of piston or return plate...

  • Page 332: Servicing Specifications

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS ALL MODEL Item Factory Specification Allowable Limit Gear to Spline Clearance 0.030 to 0.078 mm 0.2 mm 0.0012 to 0.0030 in. 0.008 in. Shift Fork to Shifter Gear Groove Clearance 0.20 to 0.40 mm 0.8 mm...
  • Page 333 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit GST System Pressure Setting Pressure 2.30 to 2.50 MPa – 23.5 to 25.4 kgf/cm Condition • Engine Speed 334 to 362 psi Idling • Oil Temperature 40 to 60 °C (104 to 140 °F) Regulating Pressure Setting Pressure 2.40 to 2.55 MPa...
  • Page 334 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit Check and High Pressure Relief Valve Setting Pressure 33.3 to 36.3 MPa – 340 to 370 kgf/cm Condition • Engine Speed 4830 to 5260 psi Rated Speed •...

  • Page 335: Tightening Torques

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) ROPS TYPE Item N·m...
  • Page 336 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM ALL MODEL Item N·m kgf·m lbf·ft Joint bolt for main delivery pipe 118 to 137 12.0 to 14.0 86.8 to 101 Front loader pipe retaining nut 90.0 to 108 9.18 to 11.0 66.4 to 79.6 Joint bolt for PTO delivery pipe 35 to 39...
  • Page 337 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM MANUAL TRANSMISSION Item N·m kgf·m lbf·ft Release fork mounting screw 24 to 27 2.4 to 2.8 18 to 20 Main shift base mounting screw 24 to 27 2.4 to 2.8 18 to 20 Main shift arm mounting screw 9.81 to 11.2 1.00 to 1.15...
  • Page 338 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM HYDROSTATIC TRANSMISSION Item N·m kgf·m lbf·ft Joint bolt for PTO delivery pipe 35 to 39 3.5 to 4.0 26 to 28 Joint bolt for HST return pipe 88 to 98 9.0 to 9.9 65 to 72 Joint bolt for main delivery pipe 40 to 49...

  • Page 339: Checking And Adjusting

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING [1] PTO CLUTCH PTO Clutch Operating Pressure IMPORTANT • Do not connect the universal joint of the implement to the tractor PTO shaft while testing. • Set the main shift lever, shuttle lever and HST pedal in Neutral position.

  • Page 340: Glide Shift Transmission (Gst)

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] GLIDE SHIFT TRANSMISSION (GST) (1) Electrical Adjusting [GST Fine-adjustment with Electronic Instrument Panel (Intellipanel)] NOTE • The fine-adjustment function is a function to update the data of the memory device in the main ECU when a sensor, a valve, and an electronic instrument panel which relates to the GST system are repaired or are re-installed.
  • Page 341 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Valve Fine-adjustment (Setting function proportional reducing valve) CAUTION • Use extra caution when setting the Mode "F", because the tractor will move and stop automatically. NOTE • When the main ECU or GST valve is replaced, this adjustment is required.

  • Page 342: Hydraulic Checking

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM GST Shift Shock Fine-adjustment Mode (Adjusting the clutch engaging interval) NOTE • Perform Mode G for adjusting the GST shifting shock. 1. While holding down the display mode switch, start the engine. 2.
  • Page 343 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking GST System Pressure 1. Start the engine and warm up the transmission fluid, and then stop the engine. 2. Remove the GST system pressure checking port (1) plug (PT 1/8) on the GST valve (2). 3.
  • Page 344 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Pilot Pressure 1. Start the engine and warm up the transmission fluid, and then stop the engine. 2. Remove the pilot pressure checking port plug (PT 1/8) on the GST valve (2). 3.
  • Page 345 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Clutch Pack Pressure 1. Start the engine and warm up the transmission fluid, and then stop the engine. 2. Remove the clutch pack pressure checking port plug (PT 1/8) on the GST valve (2). 3.

  • Page 346: Hydrostatic Transmission (Hst)

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HYDROSTATIC TRANSMISSION (HST) (1) Electrical Adjusting [Adjustment with Electronic Instrument Panel (Intellipanel)] Adjustment of HST Sensor (HST Pedal and Range Shift Lever Fine-adjustment Mode) NOTE • When one of the followings is replaced, this adjustment is required.
  • Page 347 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) NOTE • When "Out of Setting Position ERROR No. ** (72 or 73)" is displayed (l), refer to the below chart. 12. "Hold button for 3s more" is displayed (f) : Hold down the display mode switch (2) for more than 3 seconds.
  • Page 348 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Adjustment of Throttle Sensor NOTE • When the main ECU or throttle sensor is replaced, this adjustment is required. (Tractor condition) • Parking Brake: Engaged position • HST Pedal : Neutral position •...

  • Page 349: Hydraulic Checking And Adjusting

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Hydraulic Checking and Adjusting Fuel Tank 1. Remove the left step (1). 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (5). 4. Place the disassembling stands under the left fuel tank L.H. (6). 5.
  • Page 350 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking High Pressure Relief Valve Pressure CAUTION • When checking, park the machine on flat ground, apply the parking brake. 1. Remove the hex. socket head plug from P1 or P2 port. (P1 is for forward and P2 is for reverse.) 2.
  • Page 351 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Charge Relief Pressure CAUTION • When checking, park the machine on flat ground, apply the parking brake. NOTE • Use a new transmission oil filter. 1. Remove the hex. socket head plug from charge pressure check port (1).
  • Page 352 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking and Adjusting HST Neutral Position CAUTION • Park the tractor on a flat place and keep all the levers at neutral position. • Jack up the engine tractor and bring it in the 2WD mode. 1.

  • Page 353: Preparation

    L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 354 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 355 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Steering Joint Shaft 1. Remove the steering joint screw (1). 2. Remove the steering joint cover (2) and the steering joint support (3). 3. Remove the steering joint shaft (4). (1) Steering Joint Screw (3) Steering Joint Support (2) Steering Joint Cover (4) Steering Joint Shaft...
  • Page 356 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM ROPS 1. Remove the plates (2) and the upper frame (1) mounting screws (8), (9). 2. Remove the top link (3), lift rods (5) and lower links (6). (When reassembling) NOTE • Do not firmly tighten all screws until most components are attached.
  • Page 357 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Meter Panel and Wiring Harness 1. Remove the meter panel (1). 2. Remove the right and left mud shields (2). 3. Remove the fuse box (3) and relay box (8). 4. Disconnect the flasher relay connector (7), buzzer connector (5) and parking brake switch connector (6).
  • Page 358 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Wiring Harness 1. Disconnect the multi function combination switch connector (1), side working light connector (6) and main switch connector (4). 2. Disconnect the shuttle switch connector (7) and the foot throttle wire (3).
  • Page 359 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Lever Grips and Lever Guide 1. Remove the front wheel drive lever grip (2) and range gear shift lever grip (1). 2. Remove the lever guide (3). 3. Disconnect the range gear sensor connector (4). (1) Range Gear Shift Lever Grip [A] Manual Transmission / GST (2) Front Wheel Drive Lever Grip...
  • Page 360 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM PTO Switch Connector and Lever Guide 1. Remove the position control lever grip (2) and covers (5). 2. Disconnect the PTO switch connector (6) and accelerator sensor connector (7). 3. Disconnect the boots (1) from lever guide (4) then remove the lever guide (4).
  • Page 361 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Linkages 1. Disconnect the differential lock rod (1). 2. Remove the lowering adjusting knob (2). 3. Remove the range gear shift rod (3). [HST] 4. Disconnect the front loader control lever linkage ß pins (4) to release the links.
  • Page 362 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wiring Harness 1. Remove the engine ECU support (2). 2. Disconnect the engine ECU connector (3). 3. Disconnect the range gear sensor connector (4). 4. Disconnect the joint connector (5). 5. Remove the engine ECU power relay (6) and glow relay from the engine ECU support.
  • Page 363 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Tanks 1. Remove the left step. 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (1). 4. Place the disassembling stands under the right and left fuel tanks (5), (8).
  • Page 364 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Electric Connector for GST 1. Disconnect the pressure switch connector (1), proportional reducing valve connector (2), solenoid valve connector (3), oil temperature sensor connector (4). (1) Pressure Switch Connector (3) Solenoid Valve Connector (2) Proportional Reducing Valve (4) Oil Temperature Sensor Connector Connector...
  • Page 365 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM PTO Connector and Electric Connector 1. Disconnect the traveling speed sensor connector (1). 2. Disconnect the PTO connector (2). (1) Traveling Speed Sensor Connector (2) PTO Connector 9Y1210824TRS0007US0 Step and Floor Seat 1.

  • Page 366: Cabin Type

    L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 367 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Draining Coolant WARNING To avoid personal injury or death: • Do not remove radiator cap while coolant is hot. When cool, slowly rotate cap to the first stop and allow sufficient time for excess pressure to escape before removing the cap completely.
  • Page 368 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 369 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Steering Joint Shaft 1. Remove the steering joint screw (1). 2. Remove the steering joint cover (2) and the steering joint support (3). 3. Remove the steering joint shaft (4). 4. Disconnect the heater hose (5) from the heater hose (6) and the heater hose (7) from the heater hose (8) inside, then reconnect the heater hose (5), (7) and heater hose (6), (8) to make the loop.
  • Page 370 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Seat and Seat Bracket 1. Disconnect the seat switch connector (1) and seat tilt switch connector (2). 2. Remove the seat (3). 3. Remove the seat suspension (4) together with seat bracket (5). (1) Seat Switch Connector (4) Seat Suspension (2) Seat Tilt Switch Connector...
  • Page 371 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wiring Harness 1. Remove the engine ECU support (2). 2. Disconnect the engine ECU connector (3). 3. Disconnect the range gear sensor connector (4). 4. Disconnect the joint connectors (5). 5. Remove the engine ECU power relay and glow relay (6) from the engine ECU support (2).
  • Page 372 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Tanks 1. Remove the right and left steps (1). 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (5). 4. Place the disassembling stands under the right and left fuel tanks (6), (12).
  • Page 373 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Linkage and Remote Control Valve 1. Remove the remote control valve support (1) together with the couplers. (If equipped.) 2. Remove the top link (2), right and left lift rods (3), lower links (4) and stabilizers (5).
  • Page 374 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Mat, Panel Cover and Linkage 1. Remove the step mat (1) and sound absorber (2). 2. Remove the steering post cover 1 and 2 (4). 3. Remove the panel cover (3). 4. Remove the universal joint screw (5) and disconnect the steering joint shaft (6).
  • Page 375 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Dismounting Cabin 1. Remove the wiring harness cover (1) and wiring harness tighteners (2). 2. Remove the cabin outer roof (3). 3. Secure the cabin with nylon straps and hoist. 4. Remove the cabin mounting bolts and nuts. 5.
  • Page 376 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Propeller Shaft 1. Slide the propeller shaft cover (4) and (8) after removing the screws (7). 2. Tap out the spring pins (2), (6) and slide the couplings (1), (5) and then remove the propeller shaft with covers (4), (8). (When reassembling) •...

  • Page 377: Disassembling And Assembling

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. DISASSEMBLING AND ASSEMBLING [1] MANUAL TRANSMISSION (1) Clutch Housing Hydraulic Pipe 1. Remove the front loader pipes (1). 2. Disconnect the suction pipe (4). 3. Remove the main delivery pipe (2) and PTO delivery pipe (3). (When reassembling) 118 to 137 N·m Joint bolt for main delivery...
  • Page 378 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shift Levers 1. Disconnect the brake rods (1), (5). 2. Tap out the spring pins (3) of main shift rod 1 (4). 3. Remove the shuttle shift arm stopper mounting screw, and then pull the shuttle shift shaft (2) with shuttle shift arm (6) up.
  • Page 379 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Clutch Housing and Mid Case 1. Remove the clutch housing and mid case mounting screws and nuts. 2. Separate the clutch housing (1) and mid case (2). (When reassembling) • Apply liquid gasket (Three Bond 1208C or equivalent) to joint face of the clutch housing and mid case.
  • Page 380 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shaft Case 1. Remove the shaft case mounting screws. 2. Screw down the two M6 jack bolts (1) into the shaft case (2) and pull it out. 3. Remove the shaft case (2). (When reassembling) •...
  • Page 381 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Clutch Housing Bearing Holder 1. Remove the three interlock balls (2) after removing the stopper screw (1). 2. Pull out the clutch housing bearing holder (5) with using two jack bolts (6). NOTE •...
  • Page 382 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Counter Shaft (1) Internal Snap Ring (6) Synchronizer Ring (10) Shifter (14) Needle Bearing (2) Bearing (7) Synchronizer Spring (11) 29T Gear (3rd) (15) 37T Gear (1st) (3) Needle Bearing (8) Hub (12) Counter Shaft (16) Bearing (4) 24T Gear (4th)

  • Page 383: Mid Case

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Mid Case Hydraulic Pipe 1. Remove the front loader pipes (1). 2. Disconnect the suction pipe (4). 3. Remove the main delivery pipe (2) and PTO delivery pipe (3). (When reassembling) 118 to 137 N·m Joint bolt for main delivery 12.0 to 14.0 kgf·m...
  • Page 384 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Mid Case 1. Lift up the shuttle shift arm (1). 2. Separate the mid case (4) from the clutch housing (3) after removing their mounting screws. (When reassembling) • Apply liquid gasket (Three Bond 1208C or equivalent) to joint face of clutch housing (3) and mid case (4).
  • Page 385 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM PTO Clutch Valve 1. Remove the PTO clutch valve (2) as a unit. 2. Pull out the pipe (1). (When reassembling) • Apply small amount of grease for the O-ring (3). • Install the pipe (1) to the hole (4) of the PTO clutch valve (2) firmly.
  • Page 386 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shuttle Shaft 1. Remove the external snap ring (16) and collar (15). 2. Draw out the bearing (14) with the bearing puller. 3. Remove the thrust collar (13), 18T gear (11) and synchronizer ring (12).
  • Page 387 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Clutch Discs and Hub of PTO Clutch 1. Remove the internal snap ring (3). 2. Remove the back plate (4), clutch discs (5), clutch plates (6), hub (1) and bearing (2). (When reassembling) •...
  • Page 388 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Clutch Case 1. Remove the external snap ring (5). 2. Remove the clutch case (1). (When reassembling) • Apply small amount of the grease to the seal rings (2). (1) Clutch Case (4) Bearing (2) Seal Ring (5) External Snap Ring...

  • Page 389: Transmission Case

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Transmission Case Hydraulic Pipe 1. Remove the front loader pipes (1). 2. Disconnect the suction pipe (4). 3. Remove the main delivery pipe (2) and PTO delivery pipe (3). (When reassembling) 118 to 137 N·m Joint bolt for main delivery 12.0 to 14.0 kgf·m...
  • Page 390 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM ROPS, 3 Point Linkages and Others 1. Remove the PTO shaft cover (2). 2. Remove the drawbar frame (3). 3. Remove the main gear shift lever (4), range gear shift lever (5) and four wheel drive lever (6).
  • Page 391 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Hydraulic Block and Lift Arm Support 1. Remove the rear hydraulic block (3), cover (2) and lift arm support (1) as a unit. (When reassembling) • Apply liquid gasket (Three Bond 1208C or equivalent) to joint face of the differential case and cover (2).
  • Page 392 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Mid Case and Transmission Case 1. Separate the mid case and transmission case after removing their mounting screws and nut. (When reassembling) • Make sure to insert the PTO shaft to PTO clutch firmly, turning the PTO shaft.
  • Page 393 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Transmission Bearing Holder 1. Remove the transmission bearing holder mounting screws. 2. Tap out the spring pin (8) on the shift fork rod (3). 3. Jack up the bearing holder (1) by using the two jack bolts (5) until the taper roller bearing (7) can be removed.
  • Page 394 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Disassembling Shaft Assemblies 1. Disassembling the each shaft referring to the figure. (1) 20T-49T Gear (7) Spiral Bevel Pinion Shaft (2) Range Gear Shaft (8) 29T Gear (L3560) (3) 17T Gear 31T Gear (L4060) (4) Needle Bearing (9) PTO Drive Shaft (5) 34T Gear...
  • Page 395 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM PTO Shaft 1. Remove the PTO shaft cover. 2. Remove the bearing case mounting screws, and draw out the PTO shaft (1) with bearing case (2). 3. Remove the internal snap ring (3). 4.
  • Page 396 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Differential Case Cover and Differential Side Gear 1. Remove the differential case cover (3). 2. Remove the differential side gear (1) and differential side gear washer (2). (When reassembling) • Apply molybdenum disulfide (Three Bond 1901 or equivalent) to the inner circumferential surface of the differential side gear boss.

  • Page 397: Glide Shift Transmission

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Differential Side Gear 1. Remove the differential side gear (2) and differential side gear washer (1). (When reassembling) • Check the thrust and bearing surface of both differential side gears (2). If they are worn or damaged, bores in the differential case may also be damaged.
  • Page 398 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shuttle Shift Arm and GST Valve Assembly 1. Remove the shuttle shift arm stopper screw, and then pull the shuttle shift shaft (1) with shuttle shift arm (3) up. 2. Remove the GST valve (2) using two jack bolts. 3.
  • Page 399 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Clutch Housing and Mid Case 1. Remove the clutch housing and mid case mounting screws and nuts. 2. Separate the clutch housing (1) and mid case (2). (When reassembling) • Apply liquid gasket (Three Bond 1208C or equivalent) to joint face of the clutch housing and mid case.
  • Page 400 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 23T (24T) Gear Shaft and 27T (26T) Gear 1. Remove the 23T (24T) gear shaft (1). 2. Remove the external snap ring (3) and 27T (26T) gear (2). (When reassembling) • Install the oil seal (4) on the 18T gear shaft (6), noting the direction of the oil seal (4) as shown in the figure.
  • Page 401 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shaft Assemblies 1. Remove the external snap ring (1) and thrust collar (2). 2. Draw out the shaft assemblies (4), (5), (6), (7), (9) and shift forks (10) and rods. 3. Pull out the front axle drive shaft (8) to the rear side. (When reassembling) •...

  • Page 402: Mid Case

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Mid Case Hydraulic Pipe 1. Remove the front loader pipes (2) and main delivery pipe (1). 2. Remove the left and right brake rods. 3. Disconnect the suction pipe (3). 4. Remove the GST delivery pipe (5) and PTO delivery pipe (4). (When reassembling) 118 to 137 N·m Joint bolt for main delivery...
  • Page 403 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Mid Case and Transmission Case 1. Separate the mid case and transmission case after removing their mounting screws. (When reassembling) • Make sure to insert the PTO shaft to PTO clutch firmly, turning the PTO shaft.
  • Page 404 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM PTO Clutch Valve 1. Remove the PTO clutch valve (2) as a unit. 2. Pull out the pipe (1). (When reassembling) • Apply small amount of grease for the O-ring (3). • Install the pipe (1) to the hole (4) of the PTO clutch valve (2) firmly.
  • Page 405 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shaft Assemblies 1. Pull out the sub-range shift rod (4) and remove the shift fork (3). 2. Remove the external snap ring (2) which is located at rear side of the mid case. 3.
  • Page 406 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Clutch Case and GST Clutch Piston 1. Remove the external snap ring (1) while pushing the spring retainer (2) by hand press. 2. Remove the spring retainer (2), springs (3) and piston (4). (When reassembling) •...
  • Page 407 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shuttle Shift Gears (1) External Snap Ring (2) Thrust Collar (3) Bearing (4) Thrust Collar (5) External Snap Ring (6) Thrust Collar (7) External Snap Ring (8) Hub (9) Needle Bearing (10) 20T Gear (11) 22T Gear (12) Needle Bearing (13) Thrust Collar...

  • Page 408: Transmission Case

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Transmission Case Hydraulic Pipe 1. Remove the front loader pipes (2) and main delivery pipe (1). 2. Remove the left and right brake rods. 3. Disconnect the suction pipe (3). 4. Remove the GST delivery pipe (5) and PTO delivery pipe (4). (When reassembling) 118 to 137 N·m Joint bolt for main delivery...
  • Page 409 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Cylinders and Front Loader Control Valve 1. Disconnect the hydraulic cylinder hoses (2) and return hoses (3) at the rear hydraulic block (1). 2. Remove the two pins, and remove the hydraulic cylinders (4). 3.
  • Page 410 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Brake Case 1. Remove the range gear shift lever fulcrum screw. 2. Remove the brake case mounting screws and nuts. 3. Separate the brake case, tapping the brake case lever lightly. (When reassembling) •...
  • Page 411 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Mid Case and Transmission Case 1. Separate the mid case and transmission case after removing their mounting screws and nut. (When reassembling) • Make sure to insert the PTO shaft to PTO clutch firmly, turning the PTO shaft.
  • Page 412 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Transmission Bearing Holder 1. Remove the transmission bearing holder mounting screws. 2. Tap out the spring pin (8) on the shift fork rod (3). 3. Jack up the bearing holder (1) by using the two jack bolts (5) until the taper roller bearing (7) can be removed.
  • Page 413 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Disassembling Shaft Assemblies 1. Disassemble the each shaft referring to the figure. (1) 20T-49T Gear (7) Spiral Bevel Pinion Shaft (2) Range Gear Shaft (8) 29T Gear (L3560, L4060,L5060) (3) 17T Gear 31T Gear (L4760) (4) Needle Bearing (9) PTO Drive Shaft...
  • Page 414 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM PTO Shaft 1. Remove the PTO shaft cover. 2. Remove the bearing case mounting screws, and draw out the PTO shaft (1) with bearing case (6). 3. Remove the internal snap ring (2). 4.

  • Page 415: Regulating Valve

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Regulating Valve Front Grille, Skirt and Battery Cable 1. Open the bonnet (1) and disconnect the battery negative cable (2). 2. Remove the skirt RH (4). and front grille (3). (1) Bonnet (3) Front Grille (2) Battery Negative Cable (4) Skirt RH...
  • Page 416 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Disassembling Regulating Valve NOTE • The regulating valve has been precisely machined and assembled. It is advisable not to disassemble it as long as there is no necessary. 1. Remove the plate (8), reducing spool (11), spring retainer (5) and spring (10).

  • Page 417: Gst Valve Assembly

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (5) GST Valve Assembly NOTE • The GST valve has been precisely machined and assembled. It is advisable not to disassemble it. If unavoidably necessary to do it, take the following precautions. 1.
  • Page 418 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Solenoid Valve 1. Remove the cover (7). 2. Disconnect the connector (8) and remove the solenoid valves. (When reassembling) • Be sure to install the each solenoid valve to their original positions as shown in the photo and table below. Solenoid Name Color of wiring Shift Solenoid 1 (1st shift)
  • Page 419 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shift Check Valve 1. Remove the lower body mounting hex. socket head cap screws (1). 2. Separate the upper body (2) and lower body (4). 3. Remove the 1-2, 3-4 shift check pin (10), (11), sub-range shift check pin (7), main range shift check pin (6), shuttle shift check pin (8), balls (5) and pin (9) from lower body (4).
  • Page 420 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shift Piston 1. Separate the upper body, and lower body. (See page 3-S100.) 2. Tap out the spring pins (6), and remove the shifters (5). (For 1-2, 3-4 and sub-range shift piston) 3.
  • Page 421 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Low-pass Valve IMPORTANT • Do not adjust or remove the adjustor (2), otherwise the GST clutch engagement feeling will be changed. If this valve is disassembled, be sure to check and adjust the low-pass pressure.
  • Page 422 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Proportional Reducing Valve and Filter 1. Remove the valve mounting hex. socket head cap screws. 2. Remove the proportional reducing valve (2). 3. Remove the cover (6). 4. Remove the plug (3) and orifice support (4) with filter (5). (When reassembling) •...

  • Page 423: Hydrostatic Transmission

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HYDROSTATIC TRANSMISSION (1) Clutch Housing Hydraulic Pipe 1. Remove the front loader pipes (4). 2. Disconnect the suction hose (1) and suction pipe (6). 3. Remove the main delivery pipe (3), power steering delivery pipe (2) and delivery pipe (5).
  • Page 424 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Engine from Clutch Housing 1. Place the disassembling stands under the engine and clutch housing. 2. Remove the engine and clutch housing mounting screws and nuts. 3. Separate the engine from clutch housing. (When reassembling) •...
  • Page 425 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Axle Drive Shaft 1. Pull out the front axle drive shaft (1) to the rear side. (When reassembling) • Install the front axle drive shaft (1) from front side after assembling the clutch housing case (HST unit) and mid case. Then install the bearing (5), sleeve (7), collar (6), oil seal (8), internal snap ring, O-ring (3) and spacer (2) in order.
  • Page 426 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Port Block 1. Remove the port block mounting hex. socket head screws (1). 2. Pull and remove the port block (2) from the HST housing. (When reassembling) • Install port block with O-rings (3), valve plates and gasket in place.
  • Page 427 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Servo Piston Assembly NOTE • The servo piston has been precisely machined and assembled. It is advisable not to disassemble it as long as there is no necessary. 1. Remove the regulating valve assembly (2). 2.
  • Page 428 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shaft Case, Input Shaft, Motor Shaft and Gear 1. Remove the shaft case mounting screws. 2. Screw down the M6 jack bolt (3) into the shaft case (1) and pull it out. 3.
  • Page 429 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Hi-Lo Valve 1. Remove the Hi-Lo solenoid valve assembly (1). 2. Remove the external snap ring (2). 3. Remove the Hi-Lo solenoid (5) with connector. 4. Remove the hex. socket head screw (7) and remove the spring (8) and Hi-Lo spool (9).

  • Page 430: Mid Case

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Charge Relief Valve 1. Remove the hex. socket head plug (5). 2. Remove the spring guide (3), shim (4), spring (2) and valve poppet (1). (When reassembling) NOTE • Install valve component, noting the number of shims (4) in the charge relief valve.
  • Page 431 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Pipe and Wiring Harness 1. Disconnect the speed sensor connector (1). 2. Disconnect the PTO clutch valve connector (2). 3. Disconnect the proportional valve connector (3). 4. Remove the brake rod R.H. (5). 5.
  • Page 432 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Clutch Housing and Mid Case 1. Remove the clutch housing and mid case mounting screws and nuts. 2. Separate the clutch housing (1) and mid case (2). (When reassembling) • Gasket should be replaced with new one. •...

  • Page 433: Transmission Case

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Mid Case Bearing Holder with Gears 1. Remove the mid case bearing holder 1 (4). 2. Remove the gear shafts (3), (7), (6), (5). 3. Remove the mid case bearing holder 2 (1) with PTO clutch (9). (When reassembling) •...
  • Page 434 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Pipe 1. Remove the front loader pipes (4). 2. Disconnect the suction hose (1) and suction pipe (6). 3. Remove the main delivery pipe (3), power steering delivery pipe (2) and delivery pipe (5). (When reassembling) 90.0 to 108 N·m Front loader pipe retaining...
  • Page 435 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Cylinders and Front Loader Control Valve 1. Remove the remote control hoses (1). 2. Remove the remote control valve (5) and pipe (2). 3. Remove the delivery pipe (3). 4. Remove the front loader control valve (4) with front loader control valve bracket assembly.
  • Page 436 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Separating Mid Case and Transmission Case 1. Separate the mid case and transmission case after removing their mounting screws and nut. (When reassembling) • Make sure to insert the PTO shaft to PTO clutch firmly, turning the PTO shaft.
  • Page 437 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Transmission Bearing Holder 1. Remove the transmission bearing holder mounting screws. 2. Tap out the spring pin (8) on the shift fork rod (3). 3. Jack up the bearing holder (1) by using the two jack screws (5) until the taper roller bearing (7) can be removed.
  • Page 438 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Shaft Assemblies 1. Remove the traveling speed sensor (1). 2. Remove the spiral bevel pinion shaft assembly (4) with shift fork (6), range gear shaft assembly (5) and PTO drive shaft assembly (3). 3.
  • Page 439 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Differential Lock Shift Fork 1. Tap out the left side spring pin (4). 2. Remove the cotter pin and clevis pin (3). 3. Draw out the differential lock fork shaft (1) and remove differential lock shift fork (2).

  • Page 440: Regulating Valve

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Differential Gear Assembly 1. Remove the differential support, noting the number of left shims. 2. Remove the differential gear assembly, noting the number of right shims. (When reassembling) • Check the spiral bevel gear for wear or damage. If it is no longer serviceable, replace it.
  • Page 441 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Disassembling Regulating Valve NOTE • The regulating valve has been precisely machined and assembled. It is advisable not to disassemble it as long as there is no necessary. 1. Remove the cap nuts (1), (27) and lock nuts (3), (25). 2.

  • Page 442: Servicing

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM 7. SERVICING [1] MANUAL TRANSMISSION (1) Bearing, Gear and Shaft Checking Bearing 1. Hold the inner race, and push and pull the outer race in all directions to check for wear and roughness. 2.

  • Page 443: Synchronized Gear

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Synchronized Gear Clearance between Shift Fork and Shifter Groove 1. Measure the width of shift fork. 2. Measure the shifter groove width, and calculate the clearance. 3. If the clearance exceeds the allowable limit, replace them. Shuttle 0.20 to 0.45 mm Factory...

  • Page 444: Pto Clutch

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) PTO Clutch PTO Clutch Disc Wear 1. Measure the thickness of PTO clutch disc with vernier calipers. 2. If the thickness is less than the allowable limit, replace it. 1.70 to 1.90 mm Factory specification 0.0670 to 0.0748 in.

  • Page 445: Differential Gears

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Thickness of Seal Ring 1. Measure the thickness of seal rings (1) with an outside micrometer. 2. If the measurement is less than the allowable limit, replace it. 2.45 to 2.50 mm Factory specification 0.0965 to 0.0984 in.
  • Page 446 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Backlash and Tooth Contact between Spiral Bevel Gear and Spiral Bevel Pinion Shaft 1. Set the dial indicator (lever type) with its finger on the tooth surface. 2. Measure the backlash by fixing the spiral bevel pinion shaft (3) and moving the spiral bevel gear (4) by hand.
  • Page 447 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) More than 35 % contact area on the gear tooth surface. The center of tooth contact at 1/3 of the entire width from the small end. Replace the adjusting shim (2) with thicker one to move the spiral bevel pinion shaft backward.

  • Page 448: Glide Shift Transmission (Gst)

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Clearance between Differential Pinion Shaft and Differential Pinion 1. Measure the differential pinion shaft O.D. 2. Measure the differential pinion I.D. and calculate the clearance. 3. If the clearance exceed the allowable limit, replace them. 0.060 to 0.102 mm Factory specification Clearance between...

  • Page 449: Gst Clutch

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM (5) GST Clutch Clutch Disc Wear 1. Measure the thickness of GST clutch disc with vernier calipers. 2. If the thickness is less than the allowable limit, replace it. 2.55 to 2.65 mm Factory specification 0.101 to 0.104 in.
  • Page 450 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Thickness of Seal Ring 1. Measure the thickness of seal rings (1) with an outside micrometer. 2. If the measurement is less than the allowable limit, replace it. 2.45 to 2.50 mm Factory specification 0.0965 to 0.0984 in.

  • Page 451: Hydrostatic Transmission (Hst)

    TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HYDROSTATIC TRANSMISSION (HST) (1) Bearing, Gear and Shaft Refer to 3-S123. 9Y1210824TRS0145US0 (2) PTO Clutch Refer to 3-S125. 9Y1210824TRS0147US0 (3) Differential Gears Refer to 3-S126. 9Y1210824TRS0148US0 (4) HST Charge Pump 1. Check the charge pump housing and the rotor (1), (2) for scratches and wear.
  • Page 452 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Cylinder Block Face 1. Check the polished face (1) of cylinder block for scoring. 2. If scored, replace cylinder block assembly. 3. Check the spring (2) for breakage. 4. If broken, replace cylinder block assembly. (1) Polished Face (2) Spring 9Y1210824TRS0161US0...
  • Page 453 TRANSMISSION L3560, L4060, L4760, L5060, L5460, L6060, WSM Check and High Pressure Relief Valve 1. Check the valve plug (1) and valve for scratches and damage. 2. Check the valve seat in the port block for damage. 3. Check the spring (3) for breakage and wear. 4.
  • Page 454 REAR AXLE KiSC issued 03, 2016 A...
  • Page 455 MECHANISM CONTENTS 1. STRUCTURE..........................4-M1 KiSC issued 03, 2016 A...
  • Page 456 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. STRUCTURE [L3560, L4060 and L4760] (1) Ball Bearing (4) Differential Gear Shaft (7) Differential Pinion (10) Differential Lock Shifter (2) Rear Axle (5) Brake Case (8) Ring Gear (11) Differential Case (3) Rear Axle Case (6) Brake Disc (9) Final Gear...
  • Page 457 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM [L5060, L5460 and L6060] (1) Rear Axle Cover (5) Differential Gear Shaft (8) Differential Pinion (11) Differential Lock Shifter (2) Ball Bearing (6) Brake Case (9) Ring Gear (12) Differential Case (3) Rear Axle (7) Brake Disc (10) Final Gear...
  • Page 458 SERVICING CONTENTS 1. TROUBLESHOOTING.........................4-S1 2. TIGHTENING TORQUES......................4-S2 3. PREPARATION ...........................4-S3 4. DISASSEMBLING AND ASSEMBLING ..................4-S7 KiSC issued 03, 2016 A...
  • Page 459 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Bearing worn Replace 4-S7 Excessive or Unusual Noise at All Time Insufficient or improper type of transmission fluid Fill or change used Differential gear shaft and final gear worn or Replace 4-S7 Noise while Turning...
  • Page 460 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. TIGHTENING TORQUES Tightening torques of screws and nuts on the table below are especially specified. (For general use screws and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Item N·m kgf·m lbf·ft...
  • Page 461 L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 462 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wheel and ROPS (ROPS Type) 1. Place the disassembling stand under the transmission case. 2. Remove the rear wheel mounting screws and nuts. 3. Remove the rear wheels (1). 4. Remove the top link (3) and lift rod (5). 5.
  • Page 463 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wheel and Cabin Mount Screw (Cabin Type) 1. Place the disassembling stand under the mid case. 2. Remove the rear wheels (1). 3. Remove the top link (2) and lift rod (3). 4.
  • Page 464 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Axle Case 1. Place the disassembling stand under the rear axle case. 2. Remove the rear axle mounting screws and nuts. 3. Separate the rear axle case from brake case. (When reassembling) •...
  • Page 465 REAR AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. DISASSEMBLING AND ASSEMBLING Rear Axle (1) Rear Axle (2) Oil Seal (3) Internal Snap Ring (4) Ball Bearing (5) Spacer (6) Rear Axle Case (7) Gear (8) Lock Nut (9) Ball Bearing (10) Ball Bearing (11) Rear Axle Cover (12) O-ring...
  • Page 466 BRAKES KiSC issued 03, 2016 A...
  • Page 467 MECHANISM CONTENTS 1. STRUCTURE..........................5-M1 2. OPERATION..........................5-M2 KiSC issued 03, 2016 A...
  • Page 468 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. STRUCTURE (1) Brake Case (2) Brake Cam Lever (3) Parking Brake Lever (4) Brake Pedal (5) Brake Rod (6) Brake Lever Link (7) Turnbuckle [A] Manual Transmission and [B] HST This is used hanging type brake pedals (4) to have wider space of the platform. Independent mechanical wet disc brakes are used for the right and left travelling brakes.
  • Page 469 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. OPERATION (1) Brake Case (3) Cam Plate (5) Brake Cam Lever (7) Brake Cam (2) Brake Disc (4) Steel Ball (6) Plate (8) Brake Shaft The brakes are provided on the power transmitting shafts (brake shafts (8)) through which power is transmitted to the final reduction system.
  • Page 470 SERVICING CONTENTS 1. TROUBLESHOOTING.........................5-S1 2. SERVICING SPECIFICATIONS ....................5-S2 3. TIGHTENING TORQUES......................5-S3 4. CHECKING AND ADJUSTING....................5-S4 [1] BRAKE PEDAL........................5-S4 5. DISASSEMBLING AND ASSEMBLING ..................5-S5 [1] BRAKE PEDAL........................5-S5 [2] BRAKE CASE........................5-S8 6. SERVICING ..........................5-S15 KiSC issued 03, 2016 A...
  • Page 471 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Brake pedal play unevenly adjusted Adjust 5-S4 Uneven Braking Force Brake disc worn Replace 5-S15 Cam plate warped Replace 5-S15 Brake pedal play too small Adjust 5-S4 Brake Drags...

  • Page 472: Servicing Specifications

    BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Brake Pedal Free Travel 15 to 20 mm – 0.59 to 0.78 in. Cam Plate Flatness – 0.30 mm 0.012 in. Cam Plate and Ball Height 20.9 to 21.1 mm 20.5 mm...
  • Page 473 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws and nuts in the table below are especially specified. (For general use screws and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Item N·m kgf·m lbf·ft Rear wheel mounting screw and nut...

  • Page 474: Checking And Adjusting

    BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING [1] BRAKE PEDAL Checking Brake Pedal Free Travel CAUTION • Stop the engine and chock the wheels before checking brake pedal. 1. Release the parking brake. 2. Slightly depress the brake pedal and measure free travel "L" at top of pedal stroke.

  • Page 475: Disassembling And Assembling

    BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. DISASSEMBLING AND ASSEMBLING [1] BRAKE PEDAL Panel Cover 1. Remove the panel cover (1). 2. Remove the steering post covers (2). (1) Panel Cover (2) Steering Post Cover 9Y1210824BRS0005US0 Meter Panel (Electronic Instrument Panel) 1.
  • Page 476 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Brake Pedal and Brake Rod (Manual Transmission / GST) (1) Parking Brake Lever (2) External Snap Ring (3) Bush (4) Brake Pedal RH (5) Spring (6) Spring Pin (7) Brake Pedal LH (8) Clutch Pedal (9) Brake Pedal Shaft (10) Brake Pedal Rod RH...
  • Page 477 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Brake Pedal and Brake Rod (HST) (1) Brake Pedal Shaft (2) Brake Pedal RH (3) Spring Pin (4) Spring (5) Bush (6) Brake Pedal LH (7) External Snap Ring (8) Parking Brake Lever (9) Brake Pedal Rod RH (10) Brake Rod RH (11) Brake Pedal Rod LH...

  • Page 478: Brake Case

    L6060 9.90 Imp.gals IMPORTANT • Use only KUBOTA SUPER UDT fluid. Use of other oils may damage the transmission or hydraulic system. (Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9.) • Do not mix different brands of fluid together.
  • Page 479 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wheel and ROPS (ROPS Type) 1. Place the disassembling stand under the transmission case. 2. Remove the rear wheel mounting screws and nuts. 3. Remove the rear wheels (1). 4. Remove the top link (3) and lift rod (5). 5.
  • Page 480 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wheel and Cabin Mount Screw (Cabin Type) 1. Place the disassembling stand under the mid case. 2. Remove the rear wheels (1). 3. Remove the top link (2) and lift rod (3). 4.
  • Page 481 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Axle Case 1. Place the disassembling stand under the rear axle case. 2. Remove the rear axle mounting screws and nuts. 3. Separate the rear axle case from brake case. (When reassembling) •...
  • Page 482 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Remote Control Valve (If Equipped) 1. Remove the seat bracket (1) screws and nuts. 2. Open the seat bracket (1) and set the seat stand (2). 3. Remove the hydraulic pipe screw (3) of remote control valve (5). 4.
  • Page 483 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Brake Case 1. Remove the PTO cover. 2. Remove the screw (1) and displace the hydraulic cylinder pin (2) to drawbar side. 3. Disconnect the brake rod (3). 4. Place a block of wood (5) between floor seat (6) and lift arm support to support the floor seat.
  • Page 484 BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM Brake Cam and Brake Cam Lever 1. Remove the brake cam mounting nut and remove the brake cam (2) and brake cam lever (4). (When reassembling) • Apply grease to the O-ring (3) and be careful not damage the O-ring.

  • Page 485: Servicing

    BRAKES L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. SERVICING Brake Cam Lever Movement 1. Assemble the brake cam (1) and brake cam lever (2). 2. Move the brake cam lever by hand to check the movement. 3. If the movement is heavy, refine the brake cam lever or brake case with sandpaper.
  • Page 486 FRONT AXLE KiSC issued 03, 2016 A...
  • Page 487 MECHANISM CONTENTS 1. STRUCTURE..........................6-M1 KiSC issued 03, 2016 A...
  • Page 488 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. STRUCTURE The four-wheel drive axle has powered front wheels. 9Y1210824FAM0001US0 L3560 and L4060 (1) Axle (7) Bevel Gear (13) Spiral Bevel Gear (19) Differential Yoke Shaft (2) Collar (8) Differential Side Gear (14) Spiral Bevel Pinion Shaft (20) Front Axle Case (3) Axle Flange...
  • Page 489 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM L4760, L5060, L5460 and L6060 (1) Axle (8) Bevel Gear Case (14) Spiral Bevel Gear (20) Differential Yoke Shaft (2) Collar (9) Differential Side Gear (15) Spiral Bevel Pinion Shaft (21) Front Axle Case (3) Axle Flange (10) Differential Pinion (16) Front Axle Bracket, Rear...
  • Page 490 SERVICING CONTENTS 1. TROUBLESHOOTING.........................6-S1 2. SERVICING SPECIFICATIONS ....................6-S2 3. TIGHTENING TORQUES......................6-S4 4. CHECKING AND ADJUSTING....................6-S5 5. DISASSEMBLING AND ASSEMBLING ..................6-S7 [1] SEPARATING FRONT AXLE ASSEMBLY ................6-S7 [2] DISASSEMBLING FRONT AXLE..................6-S8 6. SERVICING ..........................6-S15 KiSC issued 03, 2016 A...
  • Page 491 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Tire pressure uneven Adjust G-73 Front Wheels Wander to Right or Left Improper toe-in adjustment (improper alignment) Adjust 6-S5 Clearance between front axle case boss and Replace 6-S19 front axle bracket (front, rear) bushing excessive...

  • Page 492: Servicing Specifications

    FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Front Wheel Alignment Toe-in 2 to 8 mm – 0.08 to 0.3 in. Front Wheel Axial Sway 5.0 mm – 0.20 in. Bevel Gear Case to Stopper Clearance 1.0 to 3.0 mm –...
  • Page 493 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit Front Axle Case Boss (Front) to Bracket Clearance 0.120 to 0.275 mm 0.50 mm Bushing 0.00473 to 0.0108 in. 0.020 in. • Front Axle Case Boss (Front) O.D.
  • Page 494 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Item N·m kgf·m...

  • Page 495: Checking And Adjusting

    FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING Toe-in 1. Park the tractor on the flat place. 2. Inflate the tires to the specified pressure. 3. Turn steering wheel so front wheels are in the straight ahead position.
  • Page 496 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Adjust Front Axle Pivot 1. Loosen the lock nut (2), tighten the adjusting screw (1) all the way, and then loosen the adjusting screw (1) by 1/6 turn. 2. Retighten the lock nut (2). NOTE •...

  • Page 497: Disassembling And Assembling

    FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. DISASSEMBLING AND ASSEMBLING [1] SEPARATING FRONT AXLE ASSEMBLY Propeller Shaft 1. Slide the propeller shaft cover (4) and (8) after removing the screws (7). 2. Tap out the spring pins (2), (6) and slide the couplings (1), (5) and then remove the propeller shaft with covers (4), (8).

  • Page 498: Disassembling Front Axle

    8.5 L L5060 9.0 U.S.qts L5460 7.5 Imp.qts L6060 IMPORTANT • Use KUBOTA SUPER UDT fluid or SAE80, 90 gear oil. Refer to "4. LUBRICANTS, FUEL AND COOLANT" on page G-9. (1) Check Plug (3) Drain Plug (2) Filling Plug 9Y1210824FAS0012US0...
  • Page 499 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Propeller Shaft 1. Slide the propeller shaft cover (4) and (8) after removing the screws (7). 2. Tap out the spring pins (2), (6) and slide the couplings (1), (5) and then remove the propeller shaft with covers (4), (8). (When reassembling) •...
  • Page 500 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Bevel Gear Case and Front Gear Case (L4760, L5060, L5460 and L6060) 1. Remove the bevel gear case mounting screws. 2. Remove the bevel gear case (3) and front gear case (4) as a unit from the front axle case (1).
  • Page 501 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Bevel Gear Case and Gears 1. Remove the axle case support (7). (except L3560 and L4060) 2. Remove the external snap ring (1). 3. Tap the bevel gear case (2) and separate it from the front gear case (3).
  • Page 502 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Power Steering Hoses 1. Disconnect the power steering hoses R.H. (1) and L.H. (2) from steering cylinder (3). (When reassembling) 25 to 29 N·m Power steering hose 2.5 to 3.0 kgf·m retaining nut 18 to 21 lbf·ft Tightening torque...
  • Page 503 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Spiral Bevel Pinion Shaft and Differential Gear Assembly 1. Remove the differential yoke shaft (9), (10) both sides. 2. Remove the oil seal (6) and internal snap ring (5). 3. Remove the collar (4). 4.
  • Page 504 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Differential Gear 1. Remove the differential case cover mounting screws (9). 2. Remove the differential case cover (5), ball bearing (6) and spiral bevel gear (7) as a unit 3. Remove the external snap ring (8), and then remove the ball bearing (6) and spiral bevel gear (7) as a unit with a puller.

  • Page 505: Servicing

    FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. SERVICING Clearance between Differential Case (Differential Case Cover) and Differential Side Gear 1. Measure the differential side gear O.D.. 2. Measure the differential case bore I.D. and calculate the clearance. 3.
  • Page 506 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Backlash between Differential Pinion and Differential Side Gear 1. Set a dial gauge (lever type) on a tooth of the differential pinion. 2. Fix the differential side gear and move the differential pinion to measure the backlash.
  • Page 507 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Backlash between Spiral Bevel Pinion Shaft and Spiral Bevel Gear 1. Set a dial gauge (lever type) with its finger on the spline of spiral bevel pinion shaft. 2. Measure the backlash by moving the spiral bevel pinion shaft by hand lightly.
  • Page 508 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Backlash between Bevel Gear and Bevel Gear 1. Stick a strip of plastigauge to three spots on the bevel gear (1) with grease. 2. Fix the axle flange and front gear case. 3.
  • Page 509 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Clearance between Front Axle Case Bosses and Bracket Bushings 1. Measure the front axle case bosses O.D. with an outside micrometer. 2. Measure the bracket bushing I.D. and calculate the clearance. 3.
  • Page 510 FRONT AXLE L3560, L4060, L4760, L5060, L5460, L6060, WSM Clearance between Bevel Gear Case Boss and Front Axle Support Bushing (for L4760, L5060, L5460 and L6060) 1. Measure the bevel gear case boss O.D. with an outside micrometer. 2. Measure the support bushing I.D. and calculate the clearance. 3.
  • Page 511 STEERING KiSC issued 03, 2016 A...
  • Page 512 MECHANISM CONTENTS 1. STRUCTURE..........................7-M1 2. HYDRAULIC CIRCUIT ....................... 7-M2 3. HYDRAULIC PUMP........................7-M3 4. STEERING CONTROLLER......................7-M4 5. STEERING CYLINDER ......................7-M6 KiSC issued 03, 2016 A...
  • Page 513 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. STRUCTURE (1) Steering Wheel (3) Hydraulic Pump (5) Steering Controller (7) Steering Joint Shaft 2 (2) Steering Joint Shaft 1 (4) Steering Cylinder (6) Steering Joint Shaft 3 (8) Steering Shaft The full hydrostatic type power steering is used on these tractors.
  • Page 514 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. HYDRAULIC CIRCUIT When the engine starts, the hydraulic pump (8) pressure-feeds the oil, drawn from the transmission case (7) through the oil filter (6), to the steering controller (3). The oil which has entered steering controller (3) is directed to control valve (10).
  • Page 515 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. HYDRAULIC PUMP The gear type hydraulic pump is adopted for these tractor. This pump is tandem type, consists of two pair of gears, side plates, bushings and other components as shown in the figure. The hydraulic pump pressure-fed the oil drawn from the transmission case through oil filter to power steering circuit and main hydraulic circuit.
  • Page 516 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. STEERING CONTROLLER Neutral Position When the steering wheel (1) is not being turned, valve plate (2) is held in the neutral position by centering spring. Under this condition, an oil passage is formed between P port (from pump) and T port (to transmission case) in the control valve, and all oil from the hydraulic pump flows to T port.
  • Page 517 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM Left Turn The steering system operates in the same way at a left-turn as well, except that oil flows into and out of steering cylinder (4) in the directions opposite to those at a right-turn.
  • Page 518 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. STEERING CYLINDER (1) Tie-rod (3) Head Cover (5) Head Cover (7) Internal Snap Ring (2) Piston Rod (4) Cylinder Tube (6) Front Axle Case The steering cylinder is single piston both rod double-acting type. This steering cylinder is installed parallel to the front axle and connected to tie-rods (1).
  • Page 519 SERVICING CONTENTS 1. TROUBLESHOOTING.........................7-S1 2. SERVICING SPECIFICATIONS ....................7-S2 3. TIGHTENING TORQUES......................7-S3 4. CHECKING AND ADJUSTING....................7-S4 [1] STEERING CONTROLLER....................7-S4 5. DISASSEMBLING AND ASSEMBLING ..................7-S5 [1] STEERING CONTROLLER....................7-S5 [2] STEERING LINKAGE......................7-S6 [3] STEERING CYLINDER ......................7-S7 6. SERVICING ..........................7-S8 [1] STEERING CYLINDER ......................7-S8 KiSC issued 03, 2016 A...
  • Page 520 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Steering controller broken Replace 7-S5 Tractor Can Not Be Steered Steering linkage broken Replace 7-S5 Pipe broken Replace – Improper toe-in adjustment Adjust 6-S5 Front Wheels Vibrate Air in the hydraulic system Bleed...

  • Page 521: Servicing Specifications

    STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS STEERING CONTROLLER Item Factory Specification Allowable Limit Relief Valve Setting Pressure L3560, L4060 10.7 to 11.7 MPa – Condition • Engine Speed 110 to 119 kgf/cm Maximum 1560 to 1690 psi •...
  • Page 522 STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Item N·m kgf·m...

  • Page 523: Checking And Adjusting

    STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING [1] STEERING CONTROLLER Relief Valve Setting Pressure Test 1. Disconnect the power steering hose L.H.. 2. Install the power steering tee fitting adaptor to the steering cylinder and connect the power steering hose L.H.. 3.

  • Page 524: Disassembling And Assembling

    STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. DISASSEMBLING AND ASSEMBLING [1] STEERING CONTROLLER IMPORTANT • Use only the transmission fluid (see page G-9.), in no case use mixture of oils of different brands. • Before disassembling the power steering system hydraulic components, check the performance of hydraulic pump and power steering using a flowmeter.

  • Page 525: Steering Linkage

    STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] STEERING LINKAGE Steering Wheel and Steering Post Covers 1. Remove the steering wheel (1). 2. Remove the steering panel cover (2). 3. Remove the steering post cover 1 (3) and the steering post cover 2 (4).

  • Page 526: Steering Cylinder

    STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] STEERING CYLINDER Front Wheel, Cylinder Cover and Tie-rod 1. Place a disassembly stand under the engine and support it with a jack. 2. Remove the front wheel and cylinder cover (2). 3.

  • Page 527: Servicing

    STEERING L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. SERVICING [1] STEERING CYLINDER Steering Cylinder I.D. 1. Measure the steering cylinder I.D. with a cylinder gauge. 2. If the cylinder I.D. exceed the allowable limit, replace the cylinder tube. 55.000 to 55.074 mm Factory specification 2.1654 to 2.1682 in.
  • Page 528 HYDRAULIC SYSTEM KiSC issued 03, 2016 A...
  • Page 529 MECHANISM CONTENTS 1. STRUCTURE..........................8-M1 [1] MANUAL TRANSMISSION AND GLIDE SHIFT TRANSMISSION ........8-M1 [2] HYDROSTATIC TRANSMISSION ..................8-M2 2. HYDRAULIC CIRCUIT ....................... 8-M3 [1] MANUAL TRANSMISSION ....................8-M3 [2] GLIDE SHIFT TRANSMISSION (GST) ................8-M4 [3] HYDROSTATIC TRANSMISSION (HST) ................8-M5 3.

  • Page 530: Structure

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. STRUCTURE [1] MANUAL TRANSMISSION AND GLIDE SHIFT TRANSMISSION (1) Hydraulic Block (4) Regulating Valve (6) Front Loader Control Valve (8) Hydraulic Pump (2) GST Valve (GST Only) (5) PTO Solenoid Valve (7) Auxiliary Control Valve (3) Power Steering Controller (If Equipped)

  • Page 531: Hydrostatic Transmission

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] HYDROSTATIC TRANSMISSION (1) Hydraulic Block (3) Power Steering Cylinder (5) Regulating Valve (7) Front Loader Control Valve (2) HST Unit (4) Hydraulic Pump (6) PTO Solenoid Valve (8) Auxiliary Control Valve (If Equipped) The hydraulic system of machine consists of a hydraulic pump (4), front loader control valve (7), hydraulic cylinder and other components.

  • Page 532: Hydraulic Circuit

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. HYDRAULIC CIRCUIT [1] MANUAL TRANSMISSION (1) Position Control Valve (5) Auxiliary Control Valve (9) Hydraulic Pump 2 (12) Hydraulic Pump 1 (2) Hydraulic Cylinder (6) Power Steering Controller (10) Oil Filter (13) Relief Valve (3) Cylinder Safety Valve (7) PTO Clutch Valve...

  • Page 533: Glide Shift Transmission (Gst)

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] GLIDE SHIFT TRANSMISSION (GST) (1) Position Control Valve (5) Auxiliary Control Valve (9) Regulating Valve (13) Hydraulic Pump 1 (2) Hydraulic Cylinder (6) Power Steering Controller (10) Hydraulic Pump 2 (14) Relief Valve (3) Cylinder Safety Valve (7) PTO Clutch Valve...

  • Page 534: Hydrostatic Transmission (Hst)

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HYDROSTATIC TRANSMISSION (HST) (1) Position Control Valve (5) Auxiliary Control Valve (9) Hydrostatic Transmission (13) Oil Filter (2) Hydraulic Cylinder (6) Power Steering Controller (HST) (14) Front Loader Control Valve (3) Cylinder Safety Valve (7) Oil Filter (10) Hydraulic Pump 2...

  • Page 535: Hydraulic Pump

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. HYDRAULIC PUMP The gear type hydraulic pump is adopted for these tractor. This pump is tandem type consists of two pair of gears, side plates, bushings and other components as shown in the figure.

  • Page 536: Three Point Hitch Hydraulic System

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. THREE POINT HITCH HYDRAULIC SYSTEM [1] THREE POINT HITCH HYDRAULIC CIRCUIT (1) Position Control Valve (2) Hydraulic Cylinder (3) Cylinder Safety Valve (4) Lowering Speed Adjusting Valve (5) Auxiliary Control Valve (6) Rear Hydraulic Block (7) Front Loader Control Valve (8) Hydraulic Pump 1...
  • Page 537 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] REAR HYDRAULIC BLOCK (1) Cylinder Safety Valve (4) Cover (Rear Hydraulic Outlet From Hydraulic Pump To or From Hydraulic (2) Lowering Speed Adjusting Port) To or From Hydraulic Cylinder Valve (5) Check Valve Cylinder (3) Position Control Valve...
  • Page 538 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Lifting When the control lever is moved to "LIFT" position, spool (1) is pushed by the spool operating lever, forming a circuit with the P port and chamber A. The pressurized oil thus flows into the chamber A and closes unload poppet 1 (2).

  • Page 539: Position Control Linkage

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] POSITION CONTROL LINKAGE Position control is a mechanism to raise or lower the implement attached to the tractor in proportion to the movement of the control lever. The implement can be set at any height by moving the position control lever.

  • Page 540: Lowering Speed Adjusting Valve

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] LOWERING SPEED ADJUSTING VALVE Turning the rotor shaft (2) clockwise decreases the lowering speed, counterclockwise increases lowering speed of the three points linkage. When the rotor shaft (2) is completely closed, the three point linkage is held at its position since oil in the hydraulic cylinder is sealed between the hydraulic cylinder and rotor (4).

  • Page 541: Hydraulic Cylinder

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [6] HYDRAULIC CYLINDER The external type hydraulic cylinders are used for three point linkage system. This hydraulic cylinder is single acting type, and it is installed directly between hydraulic lift arm and lower link. The main components of the hydraulic cylinder are shown in the figure.

  • Page 542: Front Loader Control Valve Assembly

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. FRONT LOADER CONTROL VALVE ASSEMBLY [1] STRUCTURE (1) Inlet and Outlet Section Pump Port A1: A1 Port B1: B1 Port (2) Boom Control Valve Tank Port A2: A2 Port B2: B2 Port (3) Bucket Control Valve PB: Power Beyond Port (4) Power Beyond...

  • Page 543: Front Loader Hydraulic Circuit

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] FRONT LOADER HYDRAULIC CIRCUIT (1) Relief Valve Pump Port A1: A1 Port To Hydraulic Block (2) Boom Control Valve Tank Port A2: A2 Port (3) Bucket Control Valve B1: B1 Port (4) Front Loader Control Valve B2: B2 Port PB: Power Beyond Port...

  • Page 544: Operation

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] OPERATION Neutral (1) Boom Control Section (5) PB Passage 1 Tank Port B1: B1 Port (2) Bucket Control Section (6) PB Passage 2 Pump Port B2: B2 Port (3) Spool (7) Load Check Valve A1: A1 Port PB: Power Beyond Port...
  • Page 545 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (1) Boom Control Section (5) Neutral Passage 1 Pump Port A1: A1 Port (2) Bucket Control Section (6) Load Check Valve Tank Port (From Boom Cylinder) (3) Spool (7) Passage 1 B1: B1 Port (4) PB Passage 1 (8) Boom Cylinder...
  • Page 546 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Down (1) Boom Control Section (5) Neutral Passage 1 Pump Port A1: A1 Port (2) Bucket Control Section (6) Load Check Valve Tank Port (To Boom Cylinder) (3) Spool (7) Passage 1 B1: B1 Port (4) PB Passage 1 (8) Boom Cylinder...
  • Page 547 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Floating (1) Boom Control Section (5) Detent Mechanism Pump Port A1: A1 Port (2) Bucket Control Section (6) Neutral Passage 1 Tank Port B1: B1 Port (3) Spool (7) Boom Cylinder PB: Power Beyond Port (4) PB Passage 1 Low Pressure...
  • Page 548 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Roll-back (1) Boom Control Section (6) PB Passage 2 Pump Port B2: B2 Port (2) Bucket Control Section (7) Load Check Valve Tank Port (To Bucket Cylinder) (3) PB Passage 1 (8) Passage 2 PB: Power Beyond Port Low Pressure...
  • Page 549 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Dump 1 (1) Boom Control Section (6) PB Passage 2 Pump Port A2: A2 Port (2) Bucket Control Section (7) Load Check Valve Tank Port (To Bucket Cylinder) (3) PB Passage 1 (8) Passage 2 PB: Power Beyond Port B2: B2 Port...
  • Page 550 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Dump 2 (1) Boom Control Section (6) PB Passage 2 Pump Port A2: A2 Port (2) Bucket Control Section (7) Load Check Valve Tank Port (To Bucket Cylinder) (3) PB Passage 1 (8) Passage 2 PB: Power Beyond Port B2: B2 Port...

  • Page 551: Auxiliary Control Valve (If Equipped)

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. AUXILIARY CONTROL VALVE (IF EQUIPPED) [1] DOUBLE ACTING TYPE Neutral Pressure-fed oil from the hydraulic pump is delivered into the P port, and flows to the position control valve via N port.

  • Page 552: Other

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 7. OTHER The cylinder safety valve is located on the hydraulic cylinder of the three point hydraulic system. These tractors use a direct acting relief valve, which is suitable for low volume and less frequent operations.This valve has a fast response, makes it ideal for relieving shock pressure caused by heavy implement bounce and thereby reducing the possibility of damage to three point...
  • Page 553 SERVICING CONTENTS 1. TROUBLESHOOTING.........................8-S1 2. SERVICING SPECIFICATIONS ....................8-S2 3. TIGHTENING TORQUES......................8-S5 4. CHECKING AND ADJUSTING....................8-S6 [1] HYDRAULIC PUMP (FOR POWER STEERING) ..............8-S6 (1) Pump Test Using Flow-meter ..................8-S6 [2] HYDRAULIC PUMP (FOR THREE POINT HITCH) ..............8-S9 (1) Pump Test Using Flow-meter ..................8-S9 [3] RELIEF VALVE AND SAFETY VALVE ................8-S11 [4] POSITION CONTROL ROD ....................8-S13 5.
  • Page 554 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Control linkage improperly adjusted Adjust 8-S13 Implement Does Not Rise (Not Noise) Control linkage improperly assembled or Repair or replace – damaged Position control valve malfunctioning Repair or replace 8-S19 Relief valve spring weaken or broken...

  • Page 555: Servicing Specifications

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS HYDRAULIC PUMP Item Factory Specification Allowable Limit Hydraulic Pump for Power Steering Delivery at No Above – Pressure 18.6 L/min. Condition • Engine Speed Manual 4.91 U.S.gals/min. Approx. 2700 min (rpm) Transmission and 4.09 Imp.gals/min.
  • Page 556 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Item Factory Specification Allowable Limit Hydraulic Pump for Three Point Hitch Delivery at No Above Pressure 31.5 L/min. – Condition • Engine Speed Manual 8.32 U.S.gals/min. Approx. 2700 min (rpm) Transmission and 6.93 Imp.gals/min.
  • Page 557 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM RELIEF VALVE Item Factory Specification Allowable Limit Relief Valve Setting Pressure 17.1 to 18.1 MPa – L3560 175 to 184 kgf/cm Condition • Engine Speed 2480 to 2620 psi Maximum • Oil Temperature L4060, L4760, 18.1 to 19.1 MPa –...
  • Page 558 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Item N·m kgf·m...

  • Page 559: Checking And Adjusting

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING [1] HYDRAULIC PUMP (FOR POWER STEERING) (1) Pump Test Using Flow-meter Preparation 1. Pull down the knob and open the bonnet. 2. Remove the side skirt R.H. and front grill. 3.
  • Page 560 L3560, L4060, L4760, L5060, L5460, L6060, WSM Hydraulic Flow Test (for Power Steering) IMPORTANT • When using a flowmeter other than KUBOTA specified flowmeter, be sure to use the instructions with that flowmeter. • Do not close the flowmeter loading valve completely, before testing, because it has no relief valve.
  • Page 561 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) [Manual Transmission and GST] Above Hydraulic pump delivery 18.6 L/min. Factory specification at no pressure 4.91 U.S.gals/min. 4.09 Imp.gals/min. Above 18.2 L/min. Factory specification 4.81 U.S.gals/min. Hydraulic pump delivery 4.00 Imp.gals/min. at rated pressure 16.2 L/min.

  • Page 562: Hydraulic Pump (For Three Point Hitch)

    (1) Main Delivery Pipe 9Y1210824HYS0006US0 Hydraulic Flow Test IMPORTANT • When using a flowmeter other than KUBOTA specified flowmeter, be sure to use the instructions with that flowmeter. • Do not close the flowmeter loading valve completely, before testing, because it has no relief valve.
  • Page 563 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Manual Transmission and GST [L3560] Above Hydraulic pump delivery 31.5 L/min. Factory specification at no pressure 8.32 U.S.gals/min. 6.93 Imp.gals/min. Above 30.9 L/min. Factory specification 8.16 U.S.gals/min. Hydraulic pump delivery 6.80 Imp.gals/min.

  • Page 564: Relief Valve And Safety Valve

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] RELIEF VALVE AND SAFETY VALVE Relief Valve Setting Pressure Test Using Pressure Tester (Coupler) 1. Install the relief valve set pressure adaptor to the quick coupler (1) and then install a pressure gauge (Code No. 07916-50322), cable (Code No.
  • Page 565 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Safety Valve Setting Pressure Test Using Injection Nozzle Tester 1. Remove the safety valve assembly (1). 2. Attach the safety valve assembly (1) to a safety valve tester with a safety valve setting adaptor (see page G-69). 3.

  • Page 566: Position Control Rod

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] POSITION CONTROL ROD Adjusting Uppermost Position of Lift Arm 1. Set the position control lever (1) to the lowest position. 2. Start the engine, and after warming-up, set the engine speed at the idling.

  • Page 567: Disassembling And Assembling

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. DISASSEMBLING AND ASSEMBLING [1] HYDRAULIC PUMP IMPORTANT • The hydraulic pump is precision machined and assembled: if disassemble once, it may be unable to keep its original performance. Therefore, when the hydraulic pump fails, replacement should be done with the hydraulic pump assembled except when emergency repair is unavoidable.
  • Page 568 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Power Steering Delivery Pipe and Oil Cooler Return Pipe 1. Disconnect the power steering delivery pipe (2) and oil cooler return pipe (1). (When reassembling) • Install the copper washers firmly. •...

  • Page 569: Disassembling Hydraulic Pump

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Disassembling Hydraulic Pump Hydraulic Pump Assembly 1. Remove the pump cover mounting screws (7). 2. Remove the drive gear (6), driven gear (2) and side plate (3) from the casing. (When reassembling) •...

  • Page 570: Three Point Hitch Hydraulic Block Assembly

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] THREE POINT HITCH HYDRAULIC BLOCK ASSEMBLY (1) Separating Hydraulic Block Assembly Seat and Seat Bracket 1. Disconnect the seat switch connector (1) and seat tilt switch connector (2). 2. Remove the seat (3). 3.
  • Page 571 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Hydraulic Block 1. Disconnect the position control feedback rod (3) and return hoses (2). 2. Remove the lowering speed adjusting valve joint shaft (5). 3. Disconnect the delivery pipe (6). 4.

  • Page 572: Disassembling Hydraulic Assembly

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Disassembling Hydraulic Assembly Lowering Speed Adjusting Valve 1. Draw out the spring pin (4). 2. Remove the holder (5). 3. Draw out the lowering speed adjusting shaft (3), dowel pin (6) and rotor (2).

  • Page 573: Position Control Valve

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] POSITION CONTROL VALVE (1) Separating Control Valve Separating Hydraulic Block Assembly • See page 8-S19. 9Y1210824HYS0024US0 Disassembling Position Control Valve (1) Nut (2) External Snap Ring (3) Unload Plug (4) Spring (5) Unload Poppet (6) Valve Body (7) Unload Poppet 2...

  • Page 574: Lift Arm Support And Hydraulic Cylinder

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] LIFT ARM SUPPORT AND HYDRAULIC CYLINDER (1) Separating Hydraulic Cylinder Top Link, Lift Rod and PTO Cover 1. Remove the top link (1), lower links and PTO cover (3). 2. Disconnect the lift rods (2), (4) from lift arm. (When reassembling) 78 to 90 N·m Lift arm pin mounting nut...

  • Page 575: Disassembling Hydraulic Cylinder

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Disassembling Hydraulic Cylinder Hydraulic Cylinder 1. Remove the cylinder cover (1). 2. Remove the liquid gasket from top of head (5). 3. Slightly tap-in the head (5) to inside, and remove the internal snap ring (4) by using the small screwdriver.

  • Page 576: Disassembling Lift Arm Shaft

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Disassembling Lift Arm Shaft Lift Arm and Lift Arm Shaft 1. Remove the external snap ring (5). 2. Remove the lift arm R.H. (6). 3. Draw out the lift arm shaft (1) and lift arm L.H. (7) as a unit. 4.

  • Page 577: Front Loader Control Valve And Relief Valve

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] FRONT LOADER CONTROL VALVE AND RELIEF VALVE (1) Removing Front Loader Control Valve Assembly Fuel Tanks 1. Remove the left step. 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (1). 4.
  • Page 578 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Seat and Seat Bracket 1. Disconnect the seat switch connector (1) and seat tilt switch connector (2). 2. Remove the seat (3). 3. Remove the seat suspension (4) together with seat bracket (5). (1) Seat Switch Connector (4) Seat Suspension (2) Seat Tilt Switch Connector...
  • Page 579 HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Loader Control Valve 1. Remove the ß pin (1). 2. Remove the delivery pipe 2 (2) and delivery pipe 1 (3). 3. Remove the front loader pipes (4). 4. Remove the front loader control valve assembly (5). (When reassembling) 118 to 137 N·m Joint bolt for delivery pipe 1...

  • Page 580: Disassembling Front Loader Control Valve And Relief Valve

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Disassembling Front Loader Control Valve and Relief Valve (1) Plug (2) O-ring (3) Washer (4) Shim (5) Spring (6) Poppet 2 (7) Poppet 1 (8) Plug (9) O-ring (10) Spring (11) Check Valve (12) Dust Seal (13) O-ring...

  • Page 581: Safety Valve

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [6] SAFETY VALVE Disassembling Safety Valve 1. Remove the safety valve assembly (1). 2. Secure the safety valve assembly in a vise. 3. Loosen the lock nut (3), and remove the adjust screw (2). 4.

  • Page 582: Servicing

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. SERVICING [1] LIFT ARM Lift Arm Support Bushing 1. Visually inspect the DX bushings for signs of wear or damage. (The DX bushing tends to show concentrated wear.) 2. If the DX bushing is worn beyond the alloy portion "A", replace (Reference) 0.57 mm Lift arm support bushing...

  • Page 583: Hydraulic Cylinder

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] HYDRAULIC CYLINDER Hydraulic Cylinder Rod Bushing 1. Visually inspect the DX bushings for signs of wear or damage. (The DX bushing tends to show concentrated wear.) 2. If the DX bushing is worn beyond the alloy portion "A", replace (Reference) Hydraulic cylinder rod 0.57 mm...

  • Page 584: Hydraulic Pump

    HYDRAULIC SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HYDRAULIC PUMP Clearance between Bushing and Gear Shaft 1. Measure the gear shaft O.D. with an outside micrometer. 2. Measure the bushing I.D. with an inside micrometer or cylinder gauge, and calculate the clearance. 3.
  • Page 585 ELECTRICAL SYSTEM KiSC issued 03, 2016 A...
  • Page 586 MECHANISM CONTENTS 1. WIRING DIAGRAM........................9-M1 [1] MANUAL TRANSMISSION (WITHOUT CCV HEATER) ............9-M1 [2] MANUAL TRANSMISSION (WITH CCV HEATER).............. 9-M2 [3] GST (WITHOUT CCV HEATER) ..................9-M3 [4] GST (WITH CCV HEATER) ....................9-M4 [5] HST ROPS TYPE (WITHOUT CCV HEATER) ..............9-M5 [6] HST ROPS TYPE (WITH CCV HEATER) ................

  • Page 587: Wiring Diagram

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM 1. WIRING DIAGRAM [1] MANUAL TRANSMISSION (WITHOUT CCV HEATER) 9-M1 KiSC issued 03, 2016 A...

  • Page 588: Manual Transmission (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [2] MANUAL TRANSMISSION (WITH CCV HEATER) 9-M2 KiSC issued 03, 2016 A...

  • Page 589: Gst (Without Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [3] GST (WITHOUT CCV HEATER) 9-M3 KiSC issued 03, 2016 A...

  • Page 590: Gst (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [4] GST (WITH CCV HEATER) 9-M4 KiSC issued 03, 2016 A...

  • Page 591: Hst Rops Type (Without Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [5] HST ROPS TYPE (WITHOUT CCV HEATER) 9-M5 KiSC issued 03, 2016 A...

  • Page 592: Hst Rops Type (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [6] HST ROPS TYPE (WITH CCV HEATER) 9-M6 KiSC issued 03, 2016 A...

  • Page 593: Hst Cabin Type (Without Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [7] HST CABIN TYPE (WITHOUT CCV HEATER) 9-M7 KiSC issued 03, 2016 A...

  • Page 594: Hst Cabin Type (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [8] HST CABIN TYPE (WITH CCV HEATER) 9-M8 KiSC issued 03, 2016 A...

  • Page 595: Electrical Circuit

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM 2. ELECTRICAL CIRCUIT [1] MANUAL TRANSMISSION (WITHOUT CCV HEATER) 9-M9 KiSC issued 03, 2016 A...

  • Page 596: Manual Transmission (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [2] MANUAL TRANSMISSION (WITH CCV HEATER) 9-M10 KiSC issued 03, 2016 A...

  • Page 597: Gst (Without Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [3] GST (WITHOUT CCV HEATER) 9-M11 KiSC issued 03, 2016 A...

  • Page 598: Gst (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [4] GST (WITH CCV HEATER) 9-M12 KiSC issued 03, 2016 A...

  • Page 599: Hst Rops Type (Without Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [5] HST ROPS TYPE (WITHOUT CCV HEATER) 9-M13 KiSC issued 03, 2016 A...

  • Page 600: Hst Rops Type (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [6] HST ROPS TYPE (WITH CCV HEATER) 9-M14 KiSC issued 03, 2016 A...

  • Page 601: Hst Cabin Type (Without Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [7] HST CABIN TYPE (WITHOUT CCV HEATER) 9-M15 KiSC issued 03, 2016 A...

  • Page 602: Hst Cabin Type (With Ccv Heater)

    L3560, L4060, L4760, L5060, L5460, L6060, WSM ELECTRICAL SYSTEM [8] HST CABIN TYPE (WITH CCV HEATER) 9-M16 KiSC issued 03, 2016 A...

  • Page 603: Electronic Control Panel

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. ELECTRONIC CONTROL PANEL [1] SYSTEM OUTLINE (1) Liquid Crystal Display (LCD) (2) Electronic Instrument Panel (Intellipanel) The CPU does CAN (Control Area Network) communication with main ECU (Electronic Control Unit), engine ECU (Electronic Control Unit), various sensors, switches and other related devices in order to give the functions that accurately and timely provide the operator with various information necessary for tractor operation.

  • Page 604: Construction And Function Of Components

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued)  Self-diagnosis Function  Glow Control Function  Data Input, Fine-adjustment and Test Function • The function such as an input of various data, fine-adjustment and a testing of each sensor, etc. can be done by using LCD and switch operation.

  • Page 605: Switches

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Switches Main Switch The main switch (1) transmits a main switch "ON" signal and an "ST" signal at the time of engine start to the electronic instrument panel. When each lever switch and the associated are in the neutral position, the computer in the electronic instrument panel detects the signals and determines whether the engine can be...
  • Page 606 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Hazard Switch The pilot lamp at the panel lights up by the operation of hazard switch (1), interlocked with the hazard lamp flashing through the hazard unit. (1) Hazard Switch 9Y1210824ELM0017US0 Parked Regeneration Switch Press the parked regeneration switch (1) under the specified condition, and the parked regeneration starts.
  • Page 607 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Display Mode Switch and Auto Throttle Advance Switch (HST Only) These switches (1), (2) are located at the left side of the electronic instrument panel and both are of tact type. Usually, the display mode switch (1) is used at the switching of display indication, and the auto throttle advance switch (2) is used to switching to the auto...
  • Page 608 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Oil Pressure Switch: For GST This switch (1) is designed to detect that the gear shift completion of GST and pressurizing of GST clutch pressure, and is mounted at the side of GST valve. It is turned on when the pilot pressure has become higher than 0.49 MPa (5 kgf/cm , 71 psi) and is turned off when...

  • Page 609: Sensors

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM H-DS (Hydro Dual Speed) Lever : For HST The H-DS lever (1) is located on the left of the steering. When the H-DS lever (1) is operated, signals are sent to the ECU. When the H-DS lever (1) is pulled up, the HST motor is changed to the "Hi"...
  • Page 610 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Hand Throttle Lever Sensor The hand throttle lever sensor detects amount of hand throttle lever operation. (1) Hand Throttle Lever Sensor 9Y1210824ELM0033US0 Foot Throttle Sensor : For Manual Transmission and The foot throttle sensor detects the amount of depressing of foot throttle pedal.

  • Page 611: Others

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Swashplate Position Sensor : For HST The swashplate position sensor is located above the regulating valve. The sensor is linked with the servo piston. If the servo piston moves (if swashplate is inclined), the sensor detects its position and signals are sent to the ECU.
  • Page 612 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Flusher Unit Flusher unit controls the blinking frequency as a only one side of lamp blinking of turn signal and both right and left side lamps blinking of hazard signal. The blinking frequency is 60 to 80 times per minutes. (1) Flasher Unit 9Y1210824ELM0041US0 Alternator...
  • Page 613 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Proportional Valve : For HST The proportional valves (1), (2) are located on the right of the HST. There are two proportional valves; one for forward motion and the other for the reverse motion. The proportional valve is controlled by signals from the ECU and feeds oil sent from the regulating valve to the servo piston.

  • Page 614: Basic Control System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] BASIC CONTROL SYSTEM (1) Indication Items of Meter Panel (1) Tachometer (6) Engine oil pressure warning (12) PTO indicator (18) H-DS High speed range (2) Turn signal / hazard indicator indicator (13) Cruise control indicator [HST] indicator [HST]...
  • Page 615 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Electronic Instrument Panel (IntelliPanel™) Display The electronic instrument panel (IntelliPanel) display provides information as follows. The liquid crystal display (LCD) (2) is split in 2 parts. The upper side "A" shows position of the gear shift lever (3), service inspect indicator (4), travel speed (5) and clock (6).
  • Page 616 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Display Model Message Description Display the position of the range gear shift that was "L", "H", "M" or "N" selected with the range gear shift lever. "F" is displayed when forward operation is selected with the shuttle lever.

  • Page 617: Electronic Instrument Panel (Intellipanel™) Display

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Normal Display The normal display is a message indicated in the liquid crystal display (LCD) (2) while the main switch is turned "ON" or the engine is starting. By pushing the display mode switch (3), it is switched to five kinds (HST : six kinds) of displays shown in the table below.
  • Page 618 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Display 1: • [HOUR meter] Hour meter / Total operating hours are displayed. Trip meter mode • [TRIP meter] Total operating hours, counted from the previous resetting, is displayed. • The hour meter indicates in six digits the hours the tractor has been used;...

  • Page 619: Information Display (Attention Display At Engine Starting)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Information Display (Attention Display at Engine Starting) If neither of the levers, switches and pedals are in neutral positions when the main switch is turned to the "START" position, the engine can not be started. The LCD displays a message for the operator to correct the situation by placing the appropriate lever or pedal in the neutral position.
  • Page 620 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM The safety switch for engine starting is adapted for PTO switch and HST pedal in this model. (1) LCD (Liquid Crystal Display) 9Y1210824ELM0055US0 When the HST pedal and PTO switch are not set a Neutral position.
  • Page 621 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (5) Easy Checker™ If the indicators in the Easy Checker™ come on during operation, immediately stop the engine, and find the cause as shown below. Never operate the tractor while Easy Checker™ lamp is on.

  • Page 622: Confirmation Display

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) (4) Engine warning This indicator serves the following two functions. If the indicator lights up, pinpoint the cause and take a proper measure. 1. Error with the engine control system If during operation the water temperature gauge reads an acceptable level but the warning lamp in the Easy Checker™...
  • Page 623 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Overheating Warning The indicator needle reaches the red zone position, engine coolant is overheated. The electronic instrument panel informs the rise of coolant temperature, and overheat warning as shown in the table below. (1) Liquid Crystal Display (LCD) (3) Engine Warning Indicator (2) Master System Warning...

  • Page 624: Indicator Control

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (7) Indicator Control In this electronic instrument panel, the control of various monitor lamps shown in figure are equipped in addition to indicators. (1) Parking Brake Indicator If the parking brake is applied, parking brake switch is turned on and monitor lamp will come on.

  • Page 625: Assistant Control System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] ASSISTANT CONTROL SYSTEM (1) Fail-safe Function If a sensor or solenoid valve of the system gets in trouble during operation, an error message appears in the LCD screen of the electronic instrument panel. The entire system adjusts itself on the safer side and keeps itself from getting into another trouble.
  • Page 626 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Error Messages) Manual Transmission Display on IntelliPanel™ Trouble Item (Affected Model) Communication error between ERROR No. 20 ECU and IntelliPanel™ CAN NG ECU's memory device is in ERROR No. 30 trouble ECU Memory DEVICE NG Input voltage to sensor from ERROR No.
  • Page 627 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Display on IntelliPanel™ Trouble Item (Affected Model) Solenoid 5 (Hi-Lo) is in trouble ERROR No. 65 (At reverse) 1-4th Speed NG ERROR No. 66 Solenoid 6 (H-L) is in trouble 3, 5, 7, 9th Speed NG ERROR No.

  • Page 628: Testing, Setting And Adjusting Function

    For setting the throttle sensor (Input the sensor Throttle Sensor Fine-adjustment Mode    information to ECU). Mode for Factory Contact your KUBOTA distributor.  Tractor Model Select Mode For inputting the model of tractor ECU.   ...

  • Page 629: Engine Starting System And Stopping System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. ENGINE STARTING SYSTEM AND STOPPING SYSTEM [1] MANUAL TRANSMISSION (1) Main Switch (7) Seat Tilt Switch (13) Coolant Temperature Sensor (19) Fuel Pump (2) Starter Relay (8) PTO Switch (14) Camshaft Position Sensor (20) Glow Plug (3) Instrument Panel (9) Engine ECU...

  • Page 630: Gst

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] GST (1) Main Switch (7) Seat Tilt Switch (13) Coolant Temperature Sensor (19) Fuel Pump (2) Starter Relay (8) PTO Switch (14) Camshaft Position Sensor (20) Glow Plug (3) Instrument Panel (9) Engine ECU (15) Crankshaft Position Sensor (21) Glow Relay...

  • Page 631: Hst

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] HST (1) Main Switch (7) Seat Tilt Switch (13) Coolant Temperature Sensor (19) Fuel Pump (2) Starter Relay (8) PTO Switch (14) Camshaft Position Sensor (20) Glow Plug (3) Instrument Panel (9) Engine ECU (15) Crankshaft Position Sensor (21) Glow Relay...

  • Page 632: Related Switches

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] RELATED SWITCHES Seat Switch and Seat Tilt Switch These switches are located under the seat. When sitting on the seat, the seat switch (1) is pushed in and electrical circuit is closed. When the seat is vacant, this switch is not pushed and electric circuit is opened.
  • Page 633 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM HST Pedal Sensor: for HST The HST pedal sensor is located on the right of the HST pedal. When the HST pedal is operated, signals are sent to the ECU. (1) HST Pedal Sensor 9Y1210824ELM0076US0 Main ECU (Electrical Control Unit) The main ECU is located inside of steering cover.

  • Page 634: Engine Starting Conditions

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] ENGINE STARTING CONDITIONS When the following conditions become complete, electric voltage reaches starter AC terminal through operator presence controller from main switch ST terminal, and the engine can be started. (1) Shuttle Shift Lever [A] Manual Transmission and (2) PTO Switch...

  • Page 635: Automatic Engine Stop

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [6] AUTOMATIC ENGINE STOP The tractor is equipped with Operator Presence Control (OPC) system. The engine automatically stops when the operator stands from the seat while engaging PTO clutch. (1) Shuttle Shift Lever [A] Manual Transmission and (2) PTO Switch (3) Seat Switch...

  • Page 636: Can (Controller Area Network) Communication

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. CAN (CONTROLLER AREA NETWORK) COMMUNICATION The Controller Area Network (CAN) specification defines the Data Link Layer, ISO 11898 defines the Physical Layer. The CAN bus [CANbus] is a Balanced (differential) 2-wire interface running over a Shielded Twisted Pair (STP), WIRING HARNESS (4) and (5).
  • Page 637 SERVICING CONTENTS 1. TROUBLESHOOTING.........................9-S1 2. SERVICING SPECIFICATIONS ....................9-S9 3. TIGHTENING TORQUES......................9-S10 4. CHECKING AND ADJUSTING....................9-S11 [1] BATTERY ..........................9-S11 [2] ECU AND ELECTRONIC INSTRUMENT PANEL (INTELLIPANEL)........9-S14 (1) Main ECU ........................9-S14 (2) Engine ECU........................9-S14 (3) Electronic Instrument Panel...................9-S15 [3] TESTING, SETTING AND ADJUSTING BY ELECTRONIC INSTRUMENT PANEL (INTELLIPANEL) .........................9-S15 (1) Mode Selection......................9-S16 (2) Mode "A"...
  • Page 638 [7] CHARGING SYSTEM......................9-S68 [8] LIGHTING SYSTEM ......................9-S69 (1) Multi Function Combination Lever (Combination Switch) ..........9-S69 [9] WARNING LAMPS ......................9-S72 [10]MONITOR LAMP .........................9-S73 [11]GAUGES ..........................9-S74 [12]ENGINE CONTROL SYSTEM.....................9-S75 (1) Injector ...........................9-S75 (2) SCV (Suction Control Valve) ..................9-S76 (3) Rail Pressure Sensor.....................9-S77 (4) Fuel Pump ........................9-S78 (5) Boost Sensor (If Equipped)....................9-S79 (6) EGR Valve ........................9-S80...
  • Page 639 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Battery discharged or damaged Recharge or replace 9-S12 All Electrical Equipment Do Not Battery positive cable disconnected or improperly Repair or replace – Operate connected Battery negative cable disconnected or...
  • Page 640 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM CHARGING SYSTEM Reference Symptom Probable Cause Solution Page Wiring harness disconnected or improperly Repair or replace – Charging Lamp Does connected Not Light when Main Switch is Turned ON Alternator damaged Repair or replace 9-S91 Short circuit between alternator terminal L lead...
  • Page 641 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM GAUGES Reference Symptom Probable Cause Solution Page Fuel level sensor damaged Replace 9-S74 Fuel Gauge Does Not Function Wiring harness disconnected or improperly Repair or replace – connected Electrical instrument panel damaged Replace 9-S15 Coolant temperature sensor damaged...
  • Page 642 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Error Display for Manual Transmission Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • CANbus wiring is disconnected Check the communication line – or short-circuited Communication error • No signals from main ECU for ERROR No.
  • Page 643 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Error Display for GST Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • CANbus wiring is disconnected Check the communication line – or short-circuited Communication error • No signals from main ECU for ERROR No.
  • Page 644 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • Solenoid output terminal's Able to travel at speeds other voltage is out of specification than 1, 7 and 8 (Forward) or 1 –...
  • Page 645 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Error Display for HST Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • CANbus wiring is disconnected Check the communication line – or short-circuited Communication error • No signals from main ECU for ERROR No.
  • Page 646 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Display on IntelliPanel Trouble Item Probable Cause Solution Page • Output voltage of proportional Travel motion is possible on – valve terminal or return current the backward side only is out of specification Check the connector of 9-S58 •...

  • Page 647: Servicing Specifications

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit GST Proportional Reducing Valve Resistance Approx. – 8 to 9 Ω Shift Solenoid Valve Resistance Approx. – 11 to 15 Ω Glow Plug Resistance Approx.

  • Page 648: Tightening Torques

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Item N·m kgf·m...

  • Page 649: Checking And Adjusting

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. CHECKING AND ADJUSTING CAUTION • To avoid accidental short circuit, be sure to attach the positive cable to the positive terminal before the negative cable is attached to the negative terminal. •...
  • Page 650 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Recharging CAUTION • When the battery is being activated, hydrogen and oxygen gases in the battery are extremely explosive. Keep open sparks and flames away from the battery at all times, especially when charging the battery.
  • Page 651 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Battery Specific Gravity CAUTION • If battery acid (dilute sulfuric acid) gets on you it could cause blindness or burns, or could cause corrosion of machinery and tools so please be careful when handling. •...

  • Page 652: Ecu And Electronic Instrument Panel (Intellipanel)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] ECU AND ELECTRONIC INSTRUMENT PANEL (INTELLIPANEL) (1) Main ECU Main ECU 1. Remove the cover (1). 2. Disconnect the main ECU connector A (3) and connector B (2). IMPORTANT • [HST] When replacing the main ECU, be sure to adjust the mode "N"...

  • Page 653: Electronic Instrument Panel

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Electronic Instrument Panel Disconnecting Electronic Instrument Panel Connector 1. Remove the panel cover (1). 2. Remove the electronic instrument panel (2) from panel frame (3). 3. Disconnect the panel connector (4). NOTE •...

  • Page 654: Mode Selection

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (1) Mode Selection CAUTION • To preform the testing of the electronic instrument panel the operator must be seated on the tractor. • Select a corresponded mode by the following procedure, and do the test, the adjustment, the setting, and the confirmation respectively.

  • Page 655: Mode "A" (Test Mode)

    Throttle Sensor Fine-adjustment Mode    When the main ECU or throttle sensor is replaced or changed. Mode for Factory Contact your KUBOTA distributor.  For inputting the model of tractor to main ECU. Tractor Model Select Mode   ...
  • Page 656 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Transmission Display Contents Condition Value (unit) Model Battery Voltage More than 12 (V) −30 → 20 → 100 °C Coolant temperature sensor voltage 4.73 → 3.13 → 0.89 (V) (−22 → 68 → 212 °F) Fuel sensor voltage F to E 0.31 to 3.24 (V)
  • Page 657 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Transmission Display Contents Condition Value (unit) Model Battery Voltage More than 12 (V) −30 → 20 → 100 °C Coolant temperature sensor voltage 4.73 → 3.13 → 0.89 (V) (−22 → 68 → 212 °F) Fuel sensor voltage F to E 0.31 to 3.24 (V)

  • Page 658: Mode "B" (Traveling Speed Coefficient Input Mode) Input The 4 Digit Tire Code For Correct Travel Speed To The Electronic Instrument Panel Memory Panel

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Mode "B" (Traveling Speed Coefficient Input Mode) Input the 4 Digit Tire Code for Correct Travel Speed to the Electronic Instrument Panel Memory Panel NOTE • When the tire size is changed or electronic instrument panel is replaced, this operation is required.

  • Page 659: Mode "C" (Pto Coefficient Number Input Mode) Input The Numeric Code Number For Pto Speed Into The Electronic Instrument Panel

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Mode "C" (PTO Coefficient Number Input Mode) Input the Numeric Code Number for PTO Speed into the Electronic Instrument Panel NOTE • When the electronic instrument panel is replaced, this operation is required.

  • Page 660: Mode "D" (Error Information Reset Mode) Delete The Error Information From The Electronic Instrument Panel

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (5) Mode "D" (Error Information Reset Mode) Delete the Error Information from the Electronic Instrument Panel NOTE • When the tire size is changed or electronic instrument panel is replaced, this operation is required. 1.

  • Page 661: Mode "E" (Gst Lever Sensor Fine-Adjustment Mode) Setting The Gst Lever's Neutral Position With Its Sensor

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (6) Mode "E" (GST Lever Sensor Fine-adjustment Mode) Setting the GST Lever's Neutral Position with its Sensor IMPORTANT • As for the fine-adjustment, make sure to set it correctly to have the standard control thereafter. NOTE •...

  • Page 662: Mode "F" (Gst Valve Fine-Adjustment Mode) Setting The Function Of Proportional Reducing Valve

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (7) Mode "F" (GST Valve FIne-adjustment Mode) Setting the Function of Proportional Reducing Valve CAUTION • Use extra caution when setting the Mode "F", because the tractor will move and stop automatically. NOTE •...
  • Page 663 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) NOTE • To make this adjustment, follow these steps in the exact order described. (Otherwise the switch does not work to go next step can be moved without their settings.) 8.

  • Page 664: Mode "G" (Gst Shift Shock Fine-Adjustment Mode) Adjusting The Clutch Engaging Interval

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (8) Mode "G" (GST Shift Shock Fine-adjustment Mode) Adjusting the Clutch Engaging Interval NOTE • Perform Mode G for adjusting the GST shifting shock. 1. While holding down the display mode switch, start the engine. 2.

  • Page 665: Mode "K" (Hst Pedal And Range Shift Lever Fine-Adjustment Mode)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (10) Mode "K" (HST Pedal and Range Shift Lever Fine-adjustment Mode) NOTE • When one of the followings is replaced, this adjustment is required. (Main ECU, HST pedal sensor, swashplate position sensor, range gear shift sensor, HST proportional valve (Forward and Reverse)).
  • Page 666 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) 15. "Hold button for 3s more" is displayed (i) : Hold down the display mode switch for more than 3 seconds. 16. "Complete" is displayed (j) : The setting has been preserved correctly to the main ECU.

  • Page 667: Mode "L" (Throttle Sensor Fine-Adjustment Mode)

    (g) Correct Preserving Display (c) Error Display-1 (h) Error Display-2 (d) Setting Display-1 Error Display-3 (e) Adjusting Display-1 9Y1210824ELS0021US0 (12) Mode "M" (Mode for Factory) NOTE • Consult your KUBOTA distributor for this mode. 9Y1210824ELS0022US0 9-S29 KiSC issued 03, 2016 A...

  • Page 668: Mode "N" (Tractor Model Select Mode)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (13) Mode "N" (Tractor Model Select Mode) SET-A NOTE • When the main ECU is replaced, this adjustment is required. 1. While holding down the display mode switch, turn on the main switch.
  • Page 669 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM SET-B NOTE • When the main ECU is replaced, this adjustment is required. 1. While holding down the display mode switch, turn on the main switch. 2. Mode selection display (a) is indicated on the LCD. 3.

  • Page 670: Electric Control System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [4] ELECTRIC CONTROL SYSTEM CAUTION • For checking of electric circuit, use the circuit tester and test function of electronic instrument panel (see page 9-S17). • As for the checking of sensors, switches and solenoid, do the following order; check the battery, fuse and grounding line first, check by the test function of electronic instrument panel next, and check the connectors of panel or electronic control unit.

  • Page 671: Ecu Control System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [5] ECU CONTROL SYSTEM (1) Checking Fuse and Connector Checking Fuse 1. The tractor electrical system is protected from potential damage by fuses. A blown fuse indicates that there is an overload or short somewhere in the electrical system.
  • Page 672 Checking Slow-Blow Fuses 1. The slow-blow fuses are intended to protect the electrical cabling. If any of them has blown out, be sure to pinpoint the cause. Never use any substitute, use only a KUBOTA genuine part. Capacity (A) Protected circuit...
  • Page 673 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Checking Ground Cable 1. Check the whether the ground cables (1) are connected securely to the tractor chassis. 2. If the ground cables are broken or disconnected, replace it. (1) Ground Cable (A) Located at Left Side of Transmission Case (Manual Transmission)

  • Page 674: Checking By Electronic Instrument Panel Connector

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Checking by Electronic Instrument Panel Connector Connector of Wire Harness Side Color of wiring Terminal Name CAN (L) CAN (H) – – – – – – – – – – Turn Signal Switch RH Turn Signal Switch LH Br/Y...
  • Page 675 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Disconnecting Instrument Panel Connector 1. Remove the panel cover (1). 2. Remove the electronic instrument panel (2) from panel frame (3). 3. Disconnect the panel connector. NOTE • When replacing the electronic instrument panel, adjust to mode "B", "C"...

  • Page 676: Unit Checking

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Unit Checking Display Mode Switch: For Manual Transmission and GST 1. Check the resistance between terminal 1 and 2 while pushing the display mode switch (1). 2. It is OK if 0 ohm is indicated. NOTE •...

  • Page 677: Checking By Main Electric Control Unit (Main Ecu)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Checking by Main Electric Control Unit (Main ECU) Manual Transmission Connector A (26P Connector) of Wire Harness Side Color of wiring Terminal Name GND (Ground for Circuit Line) – – –...
  • Page 678 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Connector B (34P Connector) of Wire Harness Side Color of wiring Terminal Name – – – – Parked Regeneration Switch Lamp Foot Throttle Sensor 1 – – – – Traveling Speed Sensor –...
  • Page 679 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Connector A (26P Connector) of Wire Harness Side Color of wiring Terminal Name GND (Ground for Circuit Line) Return line terminal for proportional reducing valve – – Output terminal for 2nd shift solenoid Output terminal for 1st shift solenoid PTO Solenoid +12 V (Power Source from Main Switch)
  • Page 680 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Connector B (34P Connector) of Wire Harness Side Color of wiring Terminal Name – – – – Parked Regeneration Switch Lamp Foot Throttle Sensor 1 – – GST Lever Sensor Traveling Speed Sensor –...
  • Page 681 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Connector A (26P Connector) of Wire Harness Side Color of wiring Terminal Name GND (Ground for Circuit Line) Return line terminal for proportional valve (Forward) Return line terminal for proportional valve (Reverse) –...
  • Page 682 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Connector B (34P Connector) of Wire Harness Side Color of wiring Terminal Name – – Br/W Swashplate Position Sensor 2 Parked Regeneration Switch Lamp HST Pedal Sensor 1 – – Range Gear Shift Sensor Traveling Speed Sensor –...
  • Page 683 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Connector Voltage 1. Disconnect the connectors (2) (3). 2. Measure the voltage between connector A of terminal 18 and chassis. 3. Turn the main switch ON. 4. Measure the voltage between connector A of terminal 7 and chassis.

  • Page 684: Checking By Engine Electric Control Unit (Ecu)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (5) Checking by Engine Electric Control Unit (ECU) Color of wiring Terminal Name Color of wiring Terminal Name ECU (−) – – ECU (−) – – Injector #1 and #4 (+) Engine ECU Main Relay (Coil Side) Engine ECU Main Relay (Switch Side) Injector #2 (−)
  • Page 685 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Color of wiring Terminal Name Color of wiring Terminal Name Intake Throttle Valve Position Sensor Intake Throttle Valve Motor (DC Motor +) (Signal) DPF Differential Pressure Sensor Intake Throttle Valve Motor (DC Motor −) (Signal) Crankshaft Position Sensor (+) Intake Air Temperature Sensor (Signal)

  • Page 686: Checking Sensor And Switch For Manual Transmission

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (6) Checking Sensor and Switch for Manual Transmission Hand Throttle Lever Sensor and Foot Throttle Sensor 1. Measure the resistance between terminal c (6) and GND (7). 2. Measure the resistance between terminal GND (7) and a while slowly turning the sensor shaft.

  • Page 687: Checking Sensor And Switch For Gst

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Traveling Speed Sensor 1. Measure the resistance between terminal 7 of main ECU connector B and terminal 2 of sensor connector. 2. If 0 ohm is not indicated, the wiring harness is faulty. NOTE •...
  • Page 688 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Pressure Switch Resistance 1. Disconnect the pressure switch connector (1). 2. Connect the circuit tester pins to each terminal of pressure switch (2). 3. Start the engine and depress the clutch pedal. 4.
  • Page 689 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Shift Solenoid Resistance 1. Measure the resistance between each connector terminal and each valve body. 2. It is OK if the resistance comes to have shown in the table below. NOTE •...
  • Page 690 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Hand Throttle Lever Sensor and Foot Throttle Sensor 1. Measure the resistance between terminal c (6) and GND (7). 2. Measure the resistance between terminal GND (7) and a while slowly turning the sensor shaft. 3.

  • Page 691: Checking Sensor And Switch For Hst

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Traveling Speed Sensor 1. Measure the resistance between terminal 7 of main ECU connector B and terminal 2 of sensor connector. 2. If 0 ohm is not indicated, the wiring harness is faulty. NOTE •...
  • Page 692 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM HST Range Gear Shift Lever Sensor Resistance 1. Measure the resistance between terminal a (2) and b (3) while shifting the range gear shift lever. 2. It is OK if the resistance is smoothly changing. NOTE •...
  • Page 693 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM HST Pedal Sensor, Hand Throttle Sensor and Swashplate Sensor 1. Measure the resistance between terminal c (7) and GND (8). 2. Measure the resistance between terminal GND (8) and a while slowly turning the sensor shaft.
  • Page 694 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Cruise Control Release Switch 1. Disconnect the cruise control release switch connector (2). 2. Measure the resistance between connector terminal as shown in the table below. 3. If the switch is damaged, replace it. NOTE •...
  • Page 695 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Cruise Control Switch 1. Remove the meter panel cover. 2. Disconnect the cruise control switch connector (2). 3. Remove the cruise control switch (1). 4. Perform the following check. 1) Connector Voltage 1.
  • Page 696 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Throttle-Up Switch 1. Remove the side cover. 2. Disconnect the 2P connector of throttle-up switch (1). 3. Measure the continuity with an ohmmeter across the switch terminals. 4. If it does not conduct or any value is indicated when the switch is pushed, the switch is faulty.
  • Page 697 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Hi-Lo Solenoid 1. Remove the cover. 2. Disconnect the connector (1). 3. Remove the Hi-Lo solenoid valve assembly. 4. Disassembling the Hi-Lo solenoid valve assembly. 5. Measure the resistance with an ohmmeter across the terminal on the connector and valve body.

  • Page 698: Starting System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Traveling Speed Sensor 1. Measure the resistance between terminal 7 of main ECU connector B and terminal 2 of sensor connector. 2. If 0 ohm is not indicated, the wiring harness is faulty. NOTE •...

  • Page 699: Main Switch (Cabin Type)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Main Switch at ON Position 1. Turn the main switch "ON" position. 2. Measure the resistance across the B terminal and the AC terminal. 3. If 0 ohm is not indicated, renew the main switch. Resistance B terminal –...

  • Page 700: Safety Switch

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Main Switch at START Position 1. Turn and hold the main switch at the "START" position. 2. Measure the resistances across the B terminal and the IG1 terminal, and across the B terminal, and the ST terminal. 3.
  • Page 701 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Shuttle Switch Continuity (For Manual Transmission and GST) 1. Remove the steering post under cover. 2. Disconnected the shuttle switch connector (1). 3. Measure the resistance across four terminal referring to the table below.

  • Page 702: Starter

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Seat Tilt Switch 1. Disconnect the seat tilt switch connector (2). 2. Measure the resistance between connector terminal as shown in the table below. 3. If the switch is damaged, replace it. When switch spring is Infinity pushed...
  • Page 703 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Magnet Switch Test (Pull-in, Holding Coils) 1. Remove the motor from the starter housing. 2. Prepare a 6 V battery for the test. 3. Connect jumper leads from the battery negative terminal to the housing and the starter C terminal.

  • Page 704: Relays

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (5) Relays Relays 1) Checking Connector Voltage 1. Remove the panel cover and panel. 2. Remove the relays. 3. Measure the voltage with a voltmeter across the battery terminal and chassis as table below. 4.

  • Page 705: Engine Ecu Power Relay, Glow Relay And Defogger Relay

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (6) Engine ECU Power Relay, Glow Relay and Defogger Relay Checking Connector Voltage 1. Measure the voltage with a voltmeter across the battery terminal and chassis as table below. 2. If the voltage differs from the battery voltage, the wiring harness or fuse is faulty.

  • Page 706: Glow Control System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (7) Glow Control System Glow Plug Lead Terminal Voltage 1. Disconnect the wiring lead (1) from the glow plug (2) after turning the main switch off. 2. Turn the main switch key to the "PREHEAT" position, and measure the voltage between the lead terminal and the chassis.

  • Page 707: Lighting System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM No-Load Test 1. Connect the 2P connector (6) to previous positions of the alternator after turning the main switch OFF. 2. Connect the jumper lead (3) between IG terminal (4) and B terminal (2).
  • Page 708 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 2) Light Switch and Turn Signal Light Switch Continuity 1. Measure the resistance across seven terminal referring to the table below. [Light Switch] [Turn Signal Switch] (1) Multi Combination Lever Switch 9Y1210824ELS0086US0 Hazard Switch and Side Work Light Switch 1.
  • Page 709 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Flasher Unit Connector Voltage 1. Remove the instrument panel. 2. Disconnect the connector from the flasher unit (1). 3. Measure the voltage with a voltmeter across the h terminal and chassis. 4.

  • Page 710: Warning Lamps

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [9] WARNING LAMPS Engine Oil Pressure Switch, Panel Board and Wiring Harness 1. Disconnect the lead (2) from the engine oil pressure switch after turning the main switch "OFF". 2. Turn the main switch "ON" and connect a jumper lead from the lead to the chassis.

  • Page 711: Monitor Lamp

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [10] MONITOR LAMP Parking Brake Switch Continuity 1. Disconnect the connector from the parking brake switch (1) after turning the main switch "OFF". 2. Measure the resistance across the two terminals. 3.

  • Page 712: Gauges

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [11] GAUGES Checking Fuel Level Sensor 1. Remove the fuel level sensor from the fuel tank. 2. Measure the resistance with an ohmmeter across the terminal a and terminal b. 3. If the measurement is not indicated, the sensor is faulty. Float at uppermost 3.0 to 5.0 Ω...

  • Page 713: Engine Control System

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [12] ENGINE CONTROL SYSTEM (1) Injector IMPORTANT • When replacing the engine ECU, be sure to do injector correction. (Refer to the "DIAGNOSIS MANUAL" (9Y120-02420) 9Y1210824ELS0099US0 Injector Resistance 1. Measure the resistance with an ohmmeter across the terminals shown in the table below.

  • Page 714: Scv (Suction Control Valve)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) SCV (Suction Control Valve) NOTE • Firstly check the connector voltage, secondly check the other wires continuity, then finally check the SCV resistance. 9Y1210824ELS0101US0 Connector Voltage 1. Disconnect the connector, and turn the main key switch "ON" position.

  • Page 715: Rail Pressure Sensor

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Rail Pressure Sensor NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal. 9Y1210824ELS0104US0 Connector Voltage 1.

  • Page 716: Fuel Pump

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Fuel Pump NOTE • Firstly check the connector voltage, secondly check the other wires continuity, then finally check the pump resistance. 9Y1210824ELS0106US0 Connector Voltage 1. Disconnect the connector, and turn the main key switch "ON" position.

  • Page 717: Boost Sensor (If Equipped)

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (5) Boost Sensor (If Equipped) NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal. 9Y1210824ELS0109US0 Connector Voltage 1.

  • Page 718: Egr Valve

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (6) EGR Valve NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal. 9Y1210824ELS0111US0 Connector Voltage 1.

  • Page 719: Crankshaft Position Sensor

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (7) Crankshaft Position Sensor IMPORTANT • When replacing the crankshaft position sensor, be sure to do crankshaft position sensor correction. (See page 1-S71 to 1-S73.) NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal.

  • Page 720: Camshaft Position Sensor

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (8) Camshaft Position Sensor NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal. 9Y1210824ELS0115US0 Connector Voltage 1.

  • Page 721: Air Flow Sensor

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (9) Air Flow Sensor NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal. 9Y1210824ELS0117US0 Connector Voltage 1.

  • Page 722: Intake Throttle Valve

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (10) Intake Throttle Valve NOTE • Firstly check the connector voltage, secondly check the other wires continuity, then finally check the sensor resistance. 9Y1210824ELS0119US0 Connector Voltage 1. Disconnect the connector, and turn the main key switch "ON" position.

  • Page 723: Exhaust Temperature Sensor

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (11) Exhaust Temperature Sensor NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal. 9Y1210824ELS0122US0 Connector Voltage 1.

  • Page 724: Differential Pressure Sensor

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (12) Differential Pressure Sensor NOTE • Since it is not possible to do unit checking for this sensor, judge the sensor is faulty if the relating electric circuit is normal. 9Y1210824ELS0125US0 Connector Voltage 1.

  • Page 725: Parked Regeneration Switch

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (13) Parked Regeneration Switch NOTE • Firstly check the connector voltage, secondly check the other wires continuity, then finally check the switch continuity. 9Y1210824ELS0127US0 Connector Voltage 1. Disconnect the connector, and turn the main key switch "ON" position.

  • Page 726: Auto Regeneration Switch

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (14) Auto Regeneration Switch NOTE • Firstly check the connector voltage, secondly check the other wires continuity, then finally check the switch continuity. 9Y1210824ELS0130US0 Connector Voltage 1. Disconnect the connector, and turn the main key switch "ON" position.

  • Page 727: Ccv Heater

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [13] CCV HEATER (1) CCV Relay Checking Connector Voltage 1. Measure the voltage with a voltmeter across the battery terminal and chassis as table below. 2. If the voltage differs from the battery voltage, the wiring harness or fuse is faulty.

  • Page 728: Ccv Heater

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) CCV Heater Heater Resistance (for Reference) 1. Check the resistance between terminal 1 and 2. 2. If the reference value is not indicated, the heater is faulty. Resistance at 25 °C (77 °F) 1.8 - 2.5 Ω...

  • Page 729: Disassembling And Assembling

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. DISASSEMBLING AND ASSEMBLING [1] STARTER Disassembling Motor 1. Disconnect the connecting lead (9) from the magnet switch (8). 2. Remove the screws (6), and then separate the end frame (4), yoke (2) and armature (1).
  • Page 730 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear End Cover 1. Remove the three rear end cover screws and the B terminal nut, and remove the rear end cover. 9Y1210824ELS0137US0 Brush Holder 1. Remove the two screws holding the brush holder, and remove the brush holder (1).
  • Page 731 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Rotor 1. Press out the rotor (1) from drive end frame (3). IMPORTANT • Be very careful not to drop the rotor and damage the slip ring or fan, etc.. (1) Rotor (3) Drive End Frame (2) Block 9Y1210824ELS0154US0...

  • Page 732: Servicing

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. SERVICING [1] STARTER Overrunning Clutch 1. Inspect the pinion for wear or damage. 2. If there is any problem, replace the overrunning clutch assembly. 3. Check that the pinion turns freely and smoothly in the overrunning direction and does not slip in the cranking direction.
  • Page 733 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Brush Holder 1. Check the continuity across the brush holder and the holder support with an ohmmeter. 2. If it conducts, replace the brush holder. Brush holder – Resistance Infinity Holder support 9Y1210824ELS0161US0 Armature Coil 1.

  • Page 734: Alternator

    ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] ALTERNATOR Bearing 1. Check the bearing for smooth rotation. 2. If it does not rotate smoothly, replace it. 9Y1210824ELS0142US0 Stator 1. Measure the resistance across each lead of the stator coil with an ohmmeter.
  • Page 735 ELECTRICAL SYSTEM L3560, L4060, L4760, L5060, L5460, L6060, WSM Rectifier 1. Check the continuity across each diode of rectifier with an analog ohmmeter. Conduct the test in the (R × 1) setting. 2. The rectifier is normal if the diode in the rectifier conducts in one direction and does not conduct in the reverse direction.
  • Page 736 CABIN KiSC issued 03, 2016 A...
  • Page 737 MECHANISM CONTENTS 1. AIR CONDITIONER SYSTEM....................10-M1 [1] OUTLINE OF AIR CONDITIONING SYSTEM..............10-M1 [2] SYSTEM CONTROL ......................10-M3 [3] ELECTRICAL SYSTEM...................... 10-M4 (1) Electrical Circuit......................10-M4 (2) Compressor Relay, Blower Relays and Compressor Relay ......... 10-M5 KiSC issued 03, 2016 A...

  • Page 738: Air Conditioner System

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. AIR CONDITIONER SYSTEM [1] OUTLINE OF AIR CONDITIONING SYSTEM (1) Heater Hose (Out Side) (5) Outside Air Filter (9) Side Air Outlet (13) Low Pressure Pipe (2) Heater Hose (In Side) (6) Inside Air Filter (10) Front Air Outlet (14) Compressor...
  • Page 739 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (Continued) Factory Capacity (Cooling) 2.9 to 3.5 kW specification Water 3.9 to 4.3 kW Factory Capacity (Warming) specifi- LLC* 3.2 to 4.0 kW cation 50 % R134a Kinds of refrigerant Factory 0.95 to 1.05 kg (Charge amount) specification 2.09 to 2.31 lbs...

  • Page 740: System Control

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM [2] SYSTEM CONTROL (1) Temperature Control Dial (5) Fresh Air (10) Temperature Door D2 (A) Control Plate (2) Mode Switch (6) Air Intake Door D1 (Air Mixed Door) (B) Block Diagram of Air Flow (3) Air Conditioner Switch with (7) Recirculated Air (11) Heater...

  • Page 741: Electrical System

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM [3] ELECTRICAL SYSTEM (1) Electrical Circuit (1) Battery (6) Pressure Switch (10) Blower Motor (14) Control Panel (2) Slow Blow Fuse (80 A) (7) Compressor Relay (11) Blower Resistor (15) Mode Switch (3) Slow Blow Fuse (60 A) (8) Blower Relay (12) Mode Motor...

  • Page 742: Compressor Relay, Blower Relays And Compressor Relay

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Compressor Relay, Blower Relays and Compressor Relay Remove the outer roof and the relays are visible at the ceiling rear of the cabin: blower relay (1) and compressor relay (2). When the blower fan is adjusted for the air flow rate, the blower relay (1) is activated by a signal from the fan switch on the control panel.
  • Page 743 SERVICING CONTENTS 1. TROUBLESHOOTING.......................10-S1 2. SERVICING SPECIFICATIONS ....................10-S5 3. TIGHTENING TORQUES......................10-S6 4. PRECAUTIONS AT REPAIRING REFRIGERANT CYCLE............10-S7 [1] HANDLING OF SERVICE TOOLS ..................10-S9 (1) Manifold Gauge Set.......................10-S9 (2) Refrigerant Charging Hose..................10-S10 (3) Vacuum Pump Adaptor ....................10-S11 (4) Electric Gas Leak Tester .....................10-S11 (5) Can Tap Valve......................10-S11 (6) T-joint...........................10-S12 (7) R134a Refrigerant Recovery and Recycling Machine..........10-S12...

  • Page 744: Troubleshooting

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM 1. TROUBLESHOOTING COMPRESSOR Reference Symptom Probable Cause Solution Page Bearing of compressor worn or damaged Replace 10-S45 Noisy (Compressor ON) Valves in compressor damaged Replace 10-S45 Belt slipping Adjust or replace G-29 Compressor bracket mounting screws loosen Tighten –...
  • Page 745 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Symptom Probable Cause Solution Page Belt slipping Adjust or replace G-29 Insufficient Cooling (Compressor Does Magnetic clutch damaged Repair or replace 10-S22 Not Rotate Properly) Compressor damaged Replace 10-S45 Thermostat damaged Replace –...
  • Page 746 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Reference Symptom Probable Cause Solution Page Refrigerant overcharged Check with manifold 10-S13 Insufficient Cooling gauge (Low-pressure Level is Too High) Heat-sensitive tube in poor contact Check and repair – Expansion valve too open Replace –...
  • Page 747 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM WINDSHIELD WIPER Reference Symptom Probable Cause Solution Page Fuse blown (Short-circuit, burnt component Correct cause and G-45 Windshield Wiper inside motor or other part for operation) replace Does Not Operate Wiper motor damaged (Broken armature, worn Replace 10-S33 motor brush or seized motor shaft)

  • Page 748: Servicing Specifications

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Refrigerating Cycle Pressure 0.15 to 0.20 MPa – (Refrigerating Cycle is Normal Operating) (LO Pressure Side) 1.5 to 2.0 kgf/cm 21 to 28 psi Pressure 1.27 to 1.66 MPa –...

  • Page 749: Tightening Torques

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.) Item N·m kgf·m...

  • Page 750: Precautions At Repairing Refrigerant Cycle

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM 4. PRECAUTIONS AT REPAIRING REFRIGERANT CYCLE When checking or repairing the air conditioning system, the following precautions and rules must be observed. And it is of first importance that no other personnel than a well-trained serviceman should be allow to handle the refrigerant.
  • Page 751 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (Refrigerant) R134a Kinds of refrigerant Factory specification 770 to 870 g (Charge amount) 1.70 to 1.91 lbs (Compressor Oil) Quantity (Total) Brand Name 50 to 70 cc ND-OIL 8 0.053 to 0.073 U.S.qts <PAG* oil>...

  • Page 752: Handling Of Service Tools

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM [1] HANDLING OF SERVICE TOOLS (1) Manifold Gauge Set The hand valves on the manifold gauge set are used to open and close the valve. The hand valve inscribed LO is for the low pressure side valve (5) and HI is for the high pressure side valve (3).

  • Page 753: Refrigerant Charging Hose

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Refrigerant Charging Hose The charging hoses are classified into three colors. Each charging hose must be handled as follows: • The air conditioner manufacture recommends that the blue hose (6) is used for the LO pressure side (suction side), the green hose (5) for refrigeration side (center connecting port) and the red hose (3) for HI pressure side (discharged side).

  • Page 754: Vacuum Pump Adaptor

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Vacuum Pump Adaptor Objective of the Vacuum Pump Adaptor 1. After vacuum has been created in the air conditioning cycle, when the vacuum pump is stopped, since there is vacuum in hoses within the gauge manifold, the vacuum pump oil flows back into the charging hose.

  • Page 755: T-Joint

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (6) T-joint T-joint (2) is used to increase efficiency of gas charging using two refrigerant containers (4) at a time. 1. Install two refrigerant container service valves to T-joint (2) sides and connect the charging hose (1) to it. (1) Charging Hose (Green) (3) Can Tap Valve (2) T-joint...

  • Page 756: Checking And Charging Refrigerant Cycle

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM 5. CHECKING AND CHARGING REFRIGERANT CYCLE [1] CHECKING WITH MANIFOLD GAUGE IMPORTANT • The gauge indications described in the following testing are those taken under the same condition, so it should be noted that the gauge readings will differs somewhat with the ambient conditions. Condition •...
  • Page 757 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Insufficient Refrigerant 1. Symptoms seen in refrigerating cycle • Both LO and HI pressure side (1), (2) pressures too low. LO pressure side (1) 0.05 to 0.10 MPa (0.5 to 1.0 kgf/cm , 7.1 to 14.2 psi) HI pressure side (2) 0.69 to 0.98 MPa (7 to 10 kgf/cm...
  • Page 758 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Air Entered in the Cycle 1. Symptoms seen in refrigerating cycle • Both LO and HI pressure side (1), (2) pressures too high. LO pressure side (1) 0.20 to 0.35 MPa (2.0 to 3.5 kgf/cm , 28.4 to 49.8 psi) HI pressure side (2) 1.96 to 2.45 MPa (20 to 25 kgf/cm...
  • Page 759 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Refrigerant Fails to Circulate 1. Symptoms seen in refrigerating cycle • LO pressure side (1) pressure is vacuum and, HI pressure side (2) is low pressure. LO pressure side (1) Vacuum HI pressure side (2) 0.49 to 0.59 MPa (5 to 6 kgf/cm , 71.2 to 85.3 psi) 2.

  • Page 760: Discharging, Evacuating And Charging

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Faulty Compression of Compressor 1. Symptoms seen in refrigerating cycle • LO pressure side (1) 0.39 to 0.59 MPa (4 to 6 kgf/cm , 56.9 to 85.3 psi) • HI pressure side (2) 0.69 to 0.98 MPa (7 to 10 kgf/cm , 99.6 to 142.2 psi) 2.

  • Page 761: Evacuating The System

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Evacuating the System 9Y1210824CAS0042US0 Evacuating the System 1. Discharge refrigerant from the system by R134a refrigerant recovery and recycling machine. 2. Connect the charging hose (6) (red) to the HI pressure side charging valve and connect the charging hose (5) (blue) to the LO pressure side charging valve.

  • Page 762: Charging The Refrigerant

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (3) Charging the Refrigerant Charging an Empty System (Liquid) This procedure is for charging an empty system through the HI pressure side with the refrigerant in the liquid state. CAUTION • Never run the engine when charging the system through the HI pressure side.
  • Page 763 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Charging an Empty or Partially Charged System (Vapor) This procedure is to charge the system through the LO pressure side with refrigerant in the vapor state. When the refrigerant container is set right side up, refrigerant will enter the system as a vapor.

  • Page 764: Checking Charge Refrigerant Amount

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Checking Charge Refrigerant Amount After charging the refrigerant, check for amount of charging refrigerant as follows. NOTE • The pressure on the following checking are the gauge indications at ambient temperature 30 °C (86 °F), so it should be noted that the pressure will differ some what with the ambient temperature.

  • Page 765: Checking, Disassembling And Servicing

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM 6. CHECKING, DISASSEMBLING AND SERVICING [1] CHECKING AND ADJUSTING (1) Compressor Operation of Magnetic Clutch 1. Turn off the A/C switch after starting the engine. 2. Check whether abrasion or abnormal noise is heard when only the magnetic clutch pulley is running.

  • Page 766: Control Panel (Blower Switch, A/C Switch, Mode Control Dial And Temperature Control Dial)

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Control Panel (Blower Switch, A/C Switch, Mode Control Dial and Temperature Control Dial) Blower Switch Connector Voltage 1. Disconnect the 6P connector (2) from blower switch. 2. Turn the main switch to "ON" position. 3.
  • Page 767 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Connector Voltage 1. Disconnect the 16P connector (2) from control panel switch. 2. Turn the main switch to "ON" position. 3. Measure the voltage with a voltmeter across the terminal 15 and terminal 5.
  • Page 768 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Recirculation / Fresh Air Selection Switch Checking 1. Use a circuit tester to check the recirculation / fresh air selection switch. 2. Connect the 16P connector (1) and the 6P connector (2). 3.

  • Page 769: Blower Resistor

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Temperature Control Dial Checking 1. Turn the temperature control dial counterclockwise till it stops (at "COOL" position). 2. Measure the voltage with a voltmeter across the terminal 1 and terminal 3. Make the following measurement with the terminals connected.

  • Page 770: Blower Motor

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Blower Motor Blower Motor Test 1. Remove the outer roof. 2. Turn the blower motor (1) by hand and check whether it turns smoothly. 3. Disconnect the 2P connector (2) of blower motor (1). 4.

  • Page 771: Recirculation / Fresh Air Motor Checking

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (6) Recirculation / Fresh Air Motor Checking Recirculation / Fresh Air Motor Checking 1. Remove the outer roof. 2. Make sure that the recirculation / fresh air selection switch is functioning. 3. Turn the main switch to "ON" position. 4.

  • Page 772: Compressor Relay

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (8) Compressor Relay Compressor Relay Checking 1. Remove the panel cover (1). 2. Remove the electronic instrument panel (2). from panel frame (3). 3. Disconnect the panel connector (4). 4. Remove the compressor relay (5). 5.

  • Page 773: Pressure Switch

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (9) Pressure Switch Pressure Switch 1. Remove the outer roof (1). 1) HI Pressure Side 1. Connect the manifold gauge (6) to compressor as following procedure. Close the HI and LO pressure valves (4), (5) of manifold gauge tightly, and connect the charging hoses (3), (2) (red and blue) to the respective compressor service valves.

  • Page 774: Front Wiper Switch

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (10) Front Wiper Switch Front Wiper Switch 1. Remove the outer roof, and disconnect the front wiper switch connector (1). 2. Perform the following checkings 1) and 2). (1) Front Wiper Switch 9Y1210824CAS0064US0 1) Connector Voltage 1.

  • Page 775: Rear Wiper Switch (If Equipped)

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (11) Rear Wiper Switch (If Equipped) Rear Wiper Switch 1. Remove the outer roof, and disconnect the rear wiper switch connector (1). 2. Perform the following checkings 1) and 2). (1) Rear Wiper Switch 9Y1210824CAS0066US0 1) Connector Voltage 1.

  • Page 776: Front Wiper Motor

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (12) Front Wiper Motor Front Wiper Motor 1. Raise up the front wiper arm (2). 2. Turn the main switch to "ON" position. 3. Push the front wiper switch to "ON" position. 4.
  • Page 777 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Draining Coolant WARNING To avoid personal injury or death: • Do not remove radiator cap while coolant is hot. When cool, slowly rotate cap to the first stop and allow sufficient time for excess pressure to escape before removing the cap completely.
  • Page 778 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Grill, Skirts and Bonnet 1. Pull down the knob (2) and open the bonnet (1). 2. Disconnect the battery negative cable (3). 3. Remove the front grill (4), left and right side skirts (5). 4.
  • Page 779 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Steering Joint Shaft 1. Remove the steering joint screw (1). 2. Remove the steering joint cover (2) and the steering joint support (3). 3. Remove the steering joint shaft (4). 4. Disconnect the heater hose (5) from the heater hose (6) and the heater hose (7) from the heater hose (8) inside, then reconnect the heater hose (5), (7) and heater hose (6), (8) to make the loop.
  • Page 780 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Seat and Seat Bracket 1. Disconnect the seat switch connector (1) and seat tilt switch connector (2). 2. Remove the seat (3). 3. Remove the seat suspension (4) together with seat bracket (5). (1) Seat Switch Connector (4) Seat Suspension (2) Seat Tilt Switch Connector...
  • Page 781 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wiring Harness 1. Remove the engine ECU support (2). 2. Disconnect the engine ECU connector (3). 3. Disconnect the range gear sensor connector (4). 4. Disconnect the joint connectors (5). 5. Remove the engine ECU power relay and glow relay (6) from the engine ECU support (2).
  • Page 782 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Fuel Tanks 1. Remove the right and left steps (1). 2. Remove the fuel hose cover (3). 3. Remove the brake rod L.H. (5). 4. Place the disassembling stands under the right and left fuel tanks (6), (12).
  • Page 783 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Linkage and Remote Control Valve 1. Remove the remote control valve support (1) together with the couplers. (If equipped.) 2. Remove the top link (2), right and left lift rods (3), lower links (4) and stabilizers (5).
  • Page 784 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Mat, Panel Cover and Linkage 1. Remove the step mat (1) and sound absorber (2). 2. Remove the steering post cover 1 and 2 (4). 3. Remove the panel cover (3). 4. Remove the universal joint screw (5) and disconnect the steering joint shaft (6).
  • Page 785 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Electric Wiring 1. Remove the slow blow fuse box (1). 2. Remove the defogger relay (2) and defogger slow blow fuse (3). (If equipped) 3. Disconnect the battery positive cable (4) and battery (6). 4.
  • Page 786 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Air Cleaner and Radiator Hose 1. Remove the cramps and hoses of oil separator (3), then remove the oil separator (3). 2. Remove the intake hose (1). 3. Remove the air cleaner bracket (5) together with air cleaner (4). 4.
  • Page 787 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Air Conditioner Parts and Cabin Assembly 1. Disconnect the 1P connector (1) from compressor (2). 2. Loosen the tension pulley mounting nut, the adjusting bolt (4) and remove the air conditioner belt (5). 3.

  • Page 788: Removing Compressor Assembly

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (2) Removing Compressor Assembly Compressor Assembly 1. Discharge the refrigerant from the system. (See page 10-S17.) 2. Disconnect the low pressure pipe (suction) (1) and high pressure pipe (discharge) (5) from the compressor, then cap the open fitting immediately to keep moisture out of the system.
  • Page 789 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Hub Plate 1. Three stopper bolts (1) are set in stopper magnet clutch (2) at the position corresponding to the shape of compressor. (See page G-72.) 2. The stopper magnet clutch (2) is hung on hub plate (3) and it is fixed that the compressor rotates.

  • Page 790: Removing Air Conditioner Unit

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Stator 1. Remove the lead wire from compressor body. 2. Remove the external circlip (1). 3. Remove the stator (2). (When reassembling) • Do not use the circlip again. • Assemble the circlip for the tapered side to become outside of front housing.
  • Page 791 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Outer Roof and Wiring Harness 1. Remove the outer roof (1). 2. Disconnect the blower motor connector (2) and pressure switch connector (3). 3. Disconnect the temperature motor connector (4). 4. Disconnect the blower resistor connector (6) and thermostat connector (5).
  • Page 792 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Recirculation / Fresh Air Motor Cable and Temperature Motor Cable 1. Disconnect the recirculation / fresh air motor cable (1). 2. Disconnect the temperature motor cable (2). (1) Recirculation / Fresh Air Motor L : 3.0 to 15 mm (0.12 to 0.59 in.) Cable (2) Temperature Motor Cable...

  • Page 793: Removing Air Conditioner Pipes

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (4) Removing Air Conditioner Pipes Discharging Refrigerant Gas • See page 10-S17. 9Y1210824CAS0079US0 Battery, Front Grill, Skirt and Bonnet • See page 10-S35. 9Y1210824CAS0083US0 High Pressure Pipe 1 1. Disconnect the high pressure pipe 1 (2) from the compressor (1) and condenser (3), then cap the open fittings immediately to keep moisture out of the system.

  • Page 794: Removing Heater Hoses

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM High Pressure and Low Pressure Pipes 1. Remove the outer roof. 2. Disconnect the high pressure pipe 2 (2), then cap the open fitting immediately to keep moisture out of the system. 3.
  • Page 795 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Heater Hoses 1. Remove the outer roof. NOTE • Before disconnecting the heater hoses (2), put the parting marks on the hoses for marking proper reconnecting. 2. Disconnect the heater hoses (2) from the hose pipes (1). 3.

  • Page 796: Cabin Windshields

    • Sika product are made by Sika Corporation. • Shin Etsu silicon KE420 is made by Shin Etsu Polymer Corporation. • These materials can't be provided by Kubota Corporation. • Therefore, please find the local made equivalent materials in your country and use them when you need.
  • Page 797 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Before Replacing Windshields (3) 1. Check that the glasses are not damaged and cracked. 2. Turn over the glass and clean this surface of the glass by Sika-Activator. 3. The cleaning area of the rear surface is indicated "A" in the figure left.
  • Page 798 CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Front Windshield NOTE • Apply the Sika Tack-Ultrafast (or equivalent) with the jig having the specified tip shape as shown in the figure left. • Apply it with a uniform speed to minimize unevenness. •...

  • Page 799: Wiper Motor

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM (7) Wiper Motor Front Wiper Motor 1. Remove the steering post covers (2) and steering post under cover. 2. Remove the meter panel (1). 3. Disconnect the front wiper motor 4P connector. 4.

  • Page 800: Servicing

    CABIN L3560, L4060, L4760, L5060, L5460, L6060, WSM Rear Wiper Motor 1. Remove the cover (1). 2. Disconnect the rear wiper motor 4P connector. 3. Remove the wiper arm mounting nut (5) and wiper arm (6). 4. Remove the wiper link cap (4). 5.
  • Page 801 : Farm and Industrial Machinery International Service Department Address 64, Ishizu-Kitamachi, Sakai-Ku, Sakai-City, Osaka, 590-0823, Japan Phone +81- 72-241-1129 +81- 72-245-2484 E-mail : ks_g.ksos-pub@kubota.com Printed in Japan 2016. 03, S, EI, EI, engusa Code No.9Y111-08242 2013. 05, S, EI, EI, engusa KUBOTA Corporation...

This manual is also suitable for:

Wsm l4060Wsm l4760Wsm l5060Wsm l5460Wsm l6060

Table of Contents
