Input measures
Voltage (V)
Current (A)
Frequency (Hz)
3.2.3.6.2 Example #2
Dual input sources with 3 phases in and 3 phases out
Input measures (main and secondary)
Phase #1 Phase #2
Voltage (V) Voltage (V)
Current (A) Current (A)
Frequency (Hz)

3.2.4 Outlet status

Provides the status of the UPS outlets (ON/OFF) by load segmentation:
• Status (ON/OFF— Protected/Not protected/Not powered)
• Load level (W) – availability depending on the UPS model
Note: Load segmentations allow non-priority equipment to automatically power down during an extended power
outage to keep battery runtime on essential equipment.
This feature is also used to remote reboot and sequential start servers to restrict inrush currents.
Note: To access Controls menu, press the icon:

3.2.5 Active Alarms

Only active alarms are displayed, the Alarms icon will also display the number of active alarms.
Alarms are sorted by date, alert level, time, and description.
Note: To see the alarm history, press the icon:

3.2.6 Environment

Sensor status and data are displayed if available, MIN-MAX shows the minimal and maximal temperature or humidity measured by
the sensor.
Note: To see detailed sensor data, press the icon:
Contextual help of the web interface – 36
Output measures
Voltage (V)
Current (A)
Frequency (Hz)
Phase #3 Phase #1
Voltage (V) Voltage (V)
Current (A) Current (A)
Frequency (Hz)
Output measures
Phase #2 Phase #3
Voltage (V) Voltage (V)
Current (A) Current (A)
Load (W)
Load (%)
