Eaton Network-M2 User Manual page 69

• Name
• Location – location-position-elevation
• Temperature
• Humidity
• Dry contact #1 – Status and name
• Dry contact #2 – Status and name
• Communication – Connected/Lost with dates
3.6.1.2 Actions
3.6.1.2.1 Download sensors measures
Press the Download sensors measures button to download the sensors log file:
If available, possible measures are listed below:
• Temperature of <sensor_1> (in K, 1 decimal digit)
• Humidity of <sensor_1> (in %, 1 decimal digit)
• Temperature of <sensor_2>> (in K, 1 decimal digit)
• Humidity of <sensor_2> (in %, 1 decimal digit)
• Temperature of <sensor_3> (in K, 1 decimal digit)
• Humidity of <sensor_3> (in %RH, 1 decimal digit)
°C = K - 273.15
°F = K x 9/5 -459.67
3.6.1.2.2 Discover
At first the table is empty, press the Discover button to launch the sensor discovery process.
If sensors are discovered, the table is populated accordingly
3.6.1.2.3 Delete
Select a sensor and press the Delete button to delete the sensor.
When a sensor is deleted, all the commissioning information are deleted.
3.6.1.2.4 Define offsets
Contextual help of the web interface – 69
Environment
