Accessing the Network Module
Termination for four-wire networks

2.4 Accessing the Network Module

2.4.1 Accessing the web interface through Network

2.4.1.1 Connecting the network cable
Security settings in the Network Module may be in their default states.
For maximum security, configure through a USB connection before connecting the network cable.
Connect a standard gigabit compatible shielded ethernet cable (F/UTP or F/FTP) between the network connector on the Network Module and a
network jack.
2.4.1.2 Accessing the web interface
It is highly recommended that browser access to the Network Module is isolated from outside access using a
firewall or isolated network.
STEP 1 – On a network computer, launch a supported web browser. The browser window appears.
STEP 2 – In the Address/Location field, enter https:// [IP address] with the static IP address of the Network Module.
STEP 3 – The login screen appears.
STEP 4 – Enter the user name in the User Name field. The default user name is admin.
STEP 5 – Enter the password in the Password field. The default password is admin.
STEP 6 – The password must be changed at first login.
STEP 7 – Click Login. The Network Module web interface appears.

2.4.2 Finding and setting the IP address

2.4.2.1 Your network is equipped with a BOOTP/DHCP server (default)
2.4.2.1.1 Read from the device LCD
Note: some older Devices may not be able to display the IP address even if they have an LCD. Please consult the
Device manual.
Installing the Network Management Module – 14
