File is generated in real time and will take into account the Device capabilities and values at the time of the
generation.
Table in the downloaded file will show all possible registers, only the one showing Available equal to True will be
supported by your system.
Mapping table content:
• Address (hex): register address in hexadecimal
• Address (1-base): register address in 1-base format
• Type: Register/Discrete
• Size in bytes
• Number of Modbus registers
• Writable: True/False
• Representation: Int16/Uint16/String/Boolean/...
• Name
• Description
• Unit
• Status to 0: status when the register equal 0
• Status to 1: status when the register equal 1
• Available: True/False – Shows if the register is available on current Device
• Value: Shows current value of the register on current Device
3.7.6.4 Default settings and possible parameters - Modbus
This setting is only for the Modbus Network ModuleINDGW
Modbus RTU
Modbus TCP
Mapping configuration
Default setting
Enabled — Inactive
Baud rate (bps) — 19200
Parity — Even
Stop bits – 1
Enabled — Inactive
Port — 502
No mapping
Possible parameters
Enabled — Inactive/Active
Baud rate (bps) —
1200/2400/4800/9600/19200/38400/57600/115200
Parity — None/Even/Odd
Stop bits – 1/2
Enabled — Inactive/Active
Port — x-xxx
Name – 128 characters maximum
Map – Eaton ModbusMS compatible
Transport – RTU/TCP
Device ID – from 1 to 247
Access – None/Read only/Read/Write
Illegal read behaviour – Return exception/Return
zeros
Coil/register base address shift – No shift/Shift by
1 (JBUS)
