Maintenance bypass Maintenance bypass closed.
(optional)
ATS device The equipment is powered
through an ATS device.
Description and Description
symbols
Wiring Electrical connection between
blocks.
3.2.3.5 Details
To access the device details, press the icon:
This view provides a summary of device identification information and nominal values:
• Name
• Model
• P/N
• S/N
• Location
• Firmware version
• Input Voltage
• Input Frequency
• Output Voltage
• Output Frequency
The COPY TO CLIPBOARD button will copy the information to your clipboard.
For example, you can copy and paste information into an email.
3.2.3.6 Show measures
Provides input and output measures on the synoptic.
3.2.3.6.1 Example #1
Single input source with 1 phase in and 1 phase out:
Maintenance
Possible states
Green
Energy flow
Orange
In overload
Out of nominal range
Contextual help of the web interface – 35
Home
Black
No energy
Unknown
