Description and features

6 Servicing the EMP

6.1 Description and features

The optional Environmental Monitoring Probe EMPDT1H1C2 enables you to collect temperature and humidity readings and monitor
the environmental data remotely.
You can also collect and retrieve the status of one or two dry contact devices (not included).
Up to 3 Environmental Monitoring Probe can be daisy chained on one device.
You can monitor readings remotely using SNMP or a standard Web browser through the Network module.
This provides greater power management control and flexible monitoring options.
The EMP device is delivered with a screw and screw anchor, nylon fasteners, tie wraps, and magnets. You can install the device
anywhere on the rack or on the wall near the rack.
For more information, refer to the device manual.
The EMP has the following features:
• The hot-swap feature simplifies installation by enabling you to install the probe safely without turning off power to the device
or to the loads that are connected to it.
• The EMP monitors temperature and humidity information to help you protect critical equipment.
• The EMP measures temperatures from 0°C to 70°C with an accuracy of ±2°C.
• The EMP measures relative humidity from 10% to 90% with an accuracy of ±5%.
• The EMP can be located some distance away from the device with a CAT5 network cable up to 50m (165 ft) long.
• The EMP monitors the status of the two user-provided contact devices.
• Temperature, humidity, and contact closure status can be displayed through a Web browser through the Network module or
LCD interface (if available)
• A Temperature and Humidity Offset can be set.

6.2 Unpacking the EMP

The EMPDT1H1C2 sensor will include the following:
• Dry contact terminal block
• Quickstart
• USB to RS485 converter
• RJ45 female to female connector
• Wall mounting screw and anchor
• Rack mounting screw nut and washer
• Tie wraps (x2)
• Nylon fastener
Packing materials must be disposed of in compliance with all local regulations concerning waste.
Recycling symbols are printed on the packing materials to facilitate sorting.
Servicing the EMP – 202
