   Configuring Modbus

Press OK.
Close Internet Explorer and re-open it.
Now you can access the address 169.254.0.1 with Internet Explorer and any other browser.

2.5 Configuring Modbus

2.5.1 Configuring the communication parameters

Access the web interface through Network or RNDIS
Navigate to
Contextual
For Modbus RTU configuration refer to the
RTU.
For Modbus TCP configuration refer to the

2.5.2 Available maps

Access the web interface through Network or RNDIS
Navigate to
Contextual help>>>Settings>>>Modbus
File is generated in real time and will take into account the device capabilities and values at the time of the
generation.
Table in the downloaded file will show all possible registers, only the one showing Available equal to True will be
supported by your system.The units used on Modbus map belong to the International System of Units,
temperatures are expressed in Kelvin for example.
2.5.2.1 Mapping table content
address (hex): register address in hexadecimal
address (1-base): register address in 1-base format
Installing the Network Management Module  –  22
help>>>Settings>>>Modbus and set the communication parameters to the desired settings.
section Contextual help>>>Settings>>>Modbus>>>Modbus
section Contextual help>>>Settings>>>Modbus>>>Modbus
and press the Supported MAPs button to download the MAPs.
TCP.
