6.5.3.5

Text or Data Entry

Text boxes let you type data into a field. An action button may be
associated with a single text box, or a group of text boxes. For any
text box, left-click anywhere inside the box, type the desired
information into that field, and be sure to press [ENTER] when done.
Click the related action button to save the data.
If you edit any field, make sure to click the action button before you leave the
page. If you go to another page without first clicking the action button, your
changes are not saved.
6.5.4 Web Server Interface – Menu Tree
Navigation of the MBT-5000A HTTP Interface is illustrated with this menu tree:
Home
Home
Contact
Support
This interface provides access to four navigation tabs (shown in blue):
•
Home
Beyond the top-level row of navigation tabs, the diagram illustrates the available nested
hyperlinks (shown in grey) that allow more specific functionality.
Click any tab or hyperlink to continue.
Ethernet-based Remote Product Management
Admin
Access
SNMP
•
Admin
(Administration)
MBT-5000A L-Band Up/Down Converter System
Config Status
MBT Events
Utility Status
Redundancy
•
Config
(Unit Configuration)
6–10
Revision 1
•
Stats
(Status)
MN-MBT-5000A
