5.2.3

SELECT: Monitor Menu Branch

Monitor: Faults Mask
Event-Log LPT
Use the ◄ ► arrow keys to select from the submenu choices shown, and then press ENTER.
The submenus available from the SELECT: Monitor menu branch are as follows:
Submenu
Faults
Mask
Event-Log
LPT
5.2.3.1

Monitor: Faults

Live Faults: Unit ConvA
ConvB
Use the ◄ ► arrow keys to select Unit, ConvA, or ConvB, and then press ENTER. If you select
Unit, the highest level fault for the base unit appears. If no Unit faults exist, the message "Unit
Fault: No Errors" displays.
Press ENTER to return to the previous menu.
If you select ConvA or ConvB, the highest fault for that converter appears. If no Converter faults
exist, the message "ConvX Fault: No Errors" (where ConvX means ConvA or ConvB) displays.
Press ENTER to return to the previous menu.
Front Panel Operation
Sect Function
5.2.3.1 Displays the active faults for the base unit and the converters.
Used to configure Alarm Mask (MSK) conditions.
5.2.3.2
5.2.3.3 Used to displays stored events, and to clear the events.
5.2.3.4 (Low Power Threshold) Used to configure Low Power Threshold.
(◄ ► E)
MBT-5000A L-Band Up/Down Converter System
5–15
Revision 1
MN-MBT-5000A
