1.3

Features

•
Meets or exceeds IESS-308/309
•
Low phase noise
•
30 dB gain adjustment
•
Flexible configuration
•
RF Ku Band switching in minimal time without requiring tools
•
Optional 1:1 Redundancy in a 1RU chassis
•
EIA-232/485
•
Ethernet/Telnet/SNMP
•
Powerful Monitor and Control (M&C) support
•
Facilitates 188-164B system compliance
1.3.1

Block Upconverter (BUC-5000A)

The BUC-5000A field interchangeable upconverter module translates an L-Band input frequency
block up to the band specific RF output frequency block (C-Band, X-Band, Ku-Band, or Ka-Band).
Note the following:
C-Band
X-Band
Ku-Band
Ka-Band Commercial Band-1
Ka-Band Commercial Band-2
Ka-Band Commercial Band-3
Ka-Band Military Band
Introduction
MBT-5000A L-Band Up/Down Converter System
5850 to 6650 MHz
7900 to 8400 MHz
13.75 to 14.50 GHz
27.5 to 28.5 GHz
28.3 to 29.3 GHz
29.0 to 30.0 GHz
30.0 to 31.0 GHz
