5.2.4

SELECT: Info (Information) Menu Branch

INFO:Remote ConvA ConvB
PSA PSB RefOsc EOD
The Info menu branch displays read-only information on the current configuration of the
unit. Use the ◄ ► arrow keys to select from the submenu choices shown, and then press
ENTER.
The submenus available from the SELECT: Info (Information) menu branch are as follows:
Submen
Sect
u
Remote 5.2.4.1
ConvA
5.2.4.2
ConvB
PSA
5.2.4.3
PSB
Ref 5.2.4.4
MC 5.2.4.5
EOD 5.2.4.6
5.2.4.1

INFO: Remote (Remote Control)

This screen displays when the unit is in Local or Remote mode, and gives details of the interface
type selected, etc. For example:
Remote M&C: 100BaseTx
IP Addr: 192.168.001.004
Press ENTER or CLEAR to return to the previous menu.
Front Panel Operation
Function
(Remote Control) Displays when the unit is in Local or Remote mode
and gives details of the interface type selected, etc.
Displays the temperature and RF power for Converter 'A' or Converter
Unit B.
Displays the 19V, and 5V power supplies for Power Supply 1 or 19V,
and 5V power supplies for Power Supply 1.
Displays the raw voltage of the voltage tuning monitor, and the external
reference status.
Displays the 8V, 12V and 15V Voltages generated on the M&C.
Displays the base Equipment Odometer in hours.
