1.3.2

Block Downcoverter (BDC-5000A)

The BDC-5000A field-interchangeable module translates a band-specific RF input frequency
block (C-Band, X-Band, Ku-Band, or Ka-Band) from the Low Noise Amplifier (LNA) down to the
corresponding L-Band block.
Note the following:
C-Band
X-Band
Ku-Band
Ku-Band 2
Ka-Band Commercial Band-1
Ka-Band Commercial Band-2
Ka-Band Commercial Band-3
Ka-Band Military
Introduction
MBT-5000A L-Band Up/Down Converter System
3400 to 4200 MHz (Non-Invert optional)
7250 to 7750 MHz
10.95 to 11.70 GHz
11.70 to 12.20 GHz (Switched LO)
12.20 to 12.75 GHz
10.95 to 11.70 GHz
11.70 to 12.75 GHz (Switched LO)
17.7 to 18.7 GHz
18.5 to 19.5 GHz
19.2 to 20.2 GHz
20.2 to 21.2 GHz
