UT-4500 Series C- and Ku-Band Up Converters
Ethernet Interface Operation

7.4.2.4 Action Buttons

Action buttons are important in the HTTP Interface. Click an
action button to do one of these tasks:
• Click [Refresh] to see the latest page data.
• Reset changed parameters to remove unsaved changes.
• Click [Submit] to save changes.
If you change any parameters, make sure to click the related action
button before you leave the page. If you go to another page without
first clicking the action button, your changes are not saved.

7.4.2.4.1 Page Refresh

Many of the pages feature a [Refresh] action button located
adjacent to the uppermost Page Section label. You may click
[Refresh] at any time to update the page with its latest
reported operational data and current configured settings.

7.4.2.5 Drop-down Lists

A drop-down list lets you choose from a list of selections.
Left-click the drop-down button to open the list. Then, left-
click on an item to select that choice.

7.4.2.6 Text or Data Entry

Text boxes let you type data into a field. An action button
can be associated with a single text box, or a group of text
boxes. For any text box, left-click anywhere inside the box
and type the desired data into that field. Make sure to
press ENTER when done typing.
Click the related action button to save the data.
7–10
MN/UT4500.IOM
Revision 3
