3.1.3
RJ-45, RJ-48 Cable Connections
The plug for an RJ-45 or RJ-48 cable features a flexible tab. The RJ-45 or RJ-
48 jack features a mating slot. This design configuration assures proper
installation and pin orientation.
Connection Instructions: Press down the tab on the cable plug, and then
insert the plug into the RJ-4x jack. The connection is complete when the tab
'clicks' into position inside the jack.
Rear Panel Connections
MBT-5000A L-Band Up/Down Converter System
3–4
Revision 1
MN-MBT-5000A
