Summary of Specifications
1.4.1
Physical & Environmental
Weight
Dimensions (excluding connectors)
Temperature
Altitude
Humidity
Non-Operating Shock
1.4.2
Prime Power
Voltage
Frequency
Dissipation
1.4.3
Monitor & Control
Serial M&C Interface
Alarm
Redundant Switch Connections
Remote Interface
Introduction
Operating
Non-operating (Storage)
Operating
Non-operating
MBT-5000A L-Band Up/Down Converter System
15 lbs. (6.80 kg) Nominal
1.75" x 19" x 15"
(See Figure 1-3)
-25.6º to 140ºF (-32º to 60ºC)
-40º to 159.8ºF (-40º to 71ºC)
-120 to 10,000 ft. above sea level
-120 to 35,000 ft. above sea level
5 to 95%, non-condensing
Sinusoidal 2.3G, 20 ms duration any axis
85 – 265 VAC, -48 VDC Optional
47 to 65 Hz
70 Watts, typical
TIA/EIA-232, TIA/EIA-485, 4-wire
9-pin D, Female
Form C
9-pin D, Female
SMA Female
2.92 mm for Ka-Band
RJ-45 Ethernet
1–5
Revision 1
MN-MBT-5000A
