5.2.5

SELECT: Utility Menu Branch

UTILITY: Date/Time CID
Display Firmware LNA
Use the ◄ ► arrow keys to select from the submenu choices shown, and then press ENTER.
The submenus available from the SELECT: Utility menu branch are as follows:
Submenu
Date/Time
CID
Display
Firmware
LNA
5.2.5.1

UTILITY: Date/Time (Set Real-time Clock)

Edit Real-Time Clock:
12:00:00 04/24/14(◄ ►▲▼ E)
To edit the time and date settings for the real-time clock, use the ◄ ► arrow keys to first select
the digit to edit, and then use the ▼▲ arrow keys to edit the value of that digit.
The time is set in 24-hour military format (HH:MM:SS). The date is set in MM/DD/YY format.
Press ENTER when done.
5.2.5.2

UTILITY: CID (Circuit ID)

Edit Circuit ID:
24 CHARACTER TST MESSAGE
The Circuit ID is a user-configurable unit label. On the bottom line, use the ◄ ► arrow keys to
first select the character to edit, and then use the ▼▲ arrow keys to edit that character. Press
ENTER when done.
A maximum of 24 characters are available, as follows:
Press ENTER once you compose the string – the MBT-5000A removes all trailing spaces from the
string upon entry.
Front Panel Operation
Sect Function
5.2.5.1 Edits the Real-Time Clock time and date settings
Edits the 24-character Circuit ID string.
5.2.5.2
5.2.5.3 Adjusts the brightness level of the VFD.
Displays the installed internal firmware and permits user the boot
5.2.5.4
using a selected firmware image.
5.2.5.5 Permits control of any LNAs configured for use with the MBT-5000A.
[Space] ( ) * + - , . / 0-9 and A-Z.
MBT-5000A L-Band Up/Down Converter System
5–22
Revision 1
MN-MBT-5000A
