Command
Arguments
(Instruction
Parameter for Command
Code and
Type or Response
Qualifier) to Query
IP Address IPA= 18 bytes
Gateway IPG= 15 bytes
Address
Initialize ISP= None
Statistics
Pointer
Local/ LRS= 1 byte
Remote
State
Unit MAC N/A 17 bytes
Address
Serial-based Remote Product Management
Description of Arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Command or Query.
Sets the IP address and network prefix for the 10/100 BaseT Ethernet management port, in the
form xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (8-30)
Default Value: 192.168.001.004.24
Example: IPA=192.168.001.004.24
Command or Query.
Sets the Gateway IP address for the 10/100 Base Tx Ethernet management port, in the form:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Default Value: 192.168.001.005
Example: IPG = 192.168.001.005
Command only.
Resets internal pointer to allow RNS? Queries to start at the beginning of the stored statistics log.
Example: ISP=
Command or Query.
Set Local or Remote
0 = Local,
1=Serial,
2=Etherne
Default value: 0
Example: LRS=1
Note: The customer will always have query access in either mode. Also, the LRS command is
available in all modes as a means of acquiring control. The intent of this command is to limit
changes from being made on multiple interfaces at the same time.
Query only.
MAC address of the unit, reported in hexadecimal.
Example: MAC=00-06-B0-00-D2-A7
MBT-5000A L-Band Up/Down Converter System
7–14
Revision 1
Response to Query Response to
Command (Instruction query
(Target to Code and (Target to
Controller) Qualifier) Controller)
IPA= IPA? IPA=
xx.xxx.xxx.xxx.
IPA?
yy
IPA*
IPA#
(See
Description of
Arguments)
IPG= IPG? IPG =
xxx.xxx.xxx.xx
IPG?
x
IPG*
ISP= N/A N/A
ISP?
ISP*
LRS= LRS? LRS=x
LRS?
(Same format
as Command
arguments)
N/A MAC? MAC=xx-xx-
xx-xx-xx-xx
(See
Description of
Arguments)
