Command
Arguments
(Instruction
Parameter
for Command
Code and
Type
or Response
Qualifier)
to Query
Remote
SBR=
4 bytes
Baud Rate
Serial
N/A
9 bytes
Number
Remote
SPA=
4 bytes
Address
Set Statistics
SSI=
2 bytes
Interval
Software
N/A
variable length
Revision
Serial-based Remote Product Management
Description of Arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Command or Query.
Set remote baud rate as follows:
2400 = 2400 baud
4800 = 4800 baud
9600 = 9600 baud
19K2 = 19200 baud
38K4 = 38400 baud
Default Value: 9600
Example: <1/SBR=9600'cr'
>0001/SBR=9600'cr''lf'
Note: When changing baud rates remotely the response to the command will be returned using the
same baud rate as that used to send the command.
Query only.
Queries the unit 9-digit serial number. Unit returns its S/N in the form xxxxxxxxx.
Example: SNO=176500143
Command or Query.
Sets Physical Address - between 0001 to 9997. Resolution = 0001.
Example: <1/SPA=0412'cr'
>0001/SPA='cr''lf'
Default Value: 0001
Note: 9998 and 9999 are reserved for the block converter A and B if the base address is 9997.
Command or Query.
Sets interval at which statistics are logged. Minimum resolution is 10 minutes, maximum is 90
minutes in 10 minute intervals.
Default Value: 90
Example: <1/SSI=90'cr'
>0001/SSI='cr''lf'
Query only.
Unit returns the value of the internal software revision installed in the unit, in the form :
Boot:x.y.z Bulk1:x.y.z Bulk2:x.y.z
-or-
Boot:x.y.zz Bulk1:x.y.zz Bulk2:x.y.zz
MBT-5000A L-Band Up/Down Converter System
7–20
Revision 1
Response to
Query
Response to
Command
(Instruction
query
(Target to
Code and
(Target to
Controller)
Qualifier)
Controller)
SBR=
SBR?
SBR=xxxx
SBR?
(Same format
as Command
arguments)
N/A
SNO?
SNO=xxxxxxx
xx
(See
Description of
Arguments)
SPA=
SPA?
SPA=xxxx
SPA?
(Same format
as Command
arguments)
SSI=
SSI?
SSI=xx
SSI?
(Same format
as Command
arguments)
N/A
SWR?
SWR=Boot:x.y
.zz
Bulk1:x.y.zz
Bulk2:x.y.zz
(See
Description
of Arguments)
MN-MBT-5000A
