7.3.1

MBT-5000A Base Unit Remote Commands and Queries

Command Arguments
(Instruction
Parameter for Command
Code and
Type or Response
Qualifier) to Query
Auto Fault AFR= 1 byte
Recovery
Clear All
CAE= None
Stored
Events
Circuit CID= 24 bytes,
Identification
Set RTC DAY= 6 bytes
(Real-Time-
Clock) Date
EOD N/A 6 bytes
(Equipment
Odomter)
Serial-based Remote Product Management
Description of Arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Command or Query.
BUC/BDC output is automatically muted in event of detected fault. If auto fault recovery is enabled,
it causes output to return to pre-fault mute condition if all faults are cleared.
If disabled, the output remains muted even if all faults are cleared.
Clearing of fault condition will not cause a switchover in a redundant system unless the currently
online unit is faulted; in which case, the newly unfaulted unit is brought online.
Default Value: 1
Example: <1/AFR=1'cr'
>0001/AFR='cr''lf'
Command only.
Instructs unit to clear all Stored Events. This command takes no arguments.
Example: <1/CAE='cr'
>0001/CAE='cr''lf'
Command or Query.
Sets or queries the user-defined Circuit ID string, which is a fixed length of 24 characters.
Default value: ------------------------
Valid characters include:
Space ( ) * + – . / 0 9 and A thru Z
Command or Query.
A command in the form ddmmyy, where:
dd = day of the month (between 01 and 31);
mm = month of the year (between 01 and 12); and
yy = year (between 00 and 99; i.e., 2000 to 2099)
Example: <1/DAY=240403'cr'
>0001/DAY='cr''lf'
(date = April 24, 2003):
Command or Query. The total number of hours the Base unit has be running.
Example: <1/EOD?'cr'
>0001/EOD=000047'cr''lf'
MBT-5000A L-Band Up/Down Converter System
7–11
Revision 1
Response to Query Response to
Command (Instruction query
(Target to Code and (Target to
Controller) Qualifier) Controller)
AFR = AFR? AFR=x
AFR?
AFR* (Same format
as Command
arguments)
CAE= N/A N/A
CID= CID? CID=x...x
CID?
(See
Description of
Arguments)
DAY= DAY? DAY=xxxxxx
DAY?
DAY* (Same format
as Command
arguments)
EOD= EOD? EOD=xxxxxx
EOD?
EOD* (Same format
as Command
arguments)
MN-MBT-5000A
