5.2.5.3

UTILITY: Display (VFD Display Brightness)

Display Brightness:
100%
To edit the display brightness: Use the ▼▲ arrow keys to select a brightness value of 25%, 50%,
75%, or 100%. Press ENTER when the brightness is suitable.
5.2.5.4

UTILITY: Firmware

THESE MENUS ARE INTENDED FOR DIAGNOSTIC PURPOSES ONLY.
DO NOT CHANGE AN IMAGE UNLESS OTHERWISE INSTRUCTED BY
COMTECH EF DATA PRODUCT SUPPORT.
This series of submenus permits you to view information about the MBT-5000A internal
firmware. The MBT-5000A can store two complete firmware images. You can select which
image loads the next time the unit reboots.
Firmware Images:
Info Select
Use the ▼▲ arrow keys to select Info or Select, and then press ENTER.
5.2.5.4.1

Firmware Images: Info

Firmware Info: Bootrom
Image#1 Image#2
Use the ▼▲ arrow keys to select Bootrom, Image#1, or Image#2, and then press ENTER to
view the information.
When you select Image#1, or Image#2, these submenus require further selection (where 'X'
denotes 1 or 2):
Image#X: Bulk APP FPGA
Use the ◄ ► arrow keys to select Bulk, App, or FPGA, and then press ENTER. If, for example,
you select Bulk, a screen formatted similar to the following example displays:
Bulk: FW-0000303
2.1.X MM/DD/YY
5.2.5.4.2

Firmware Images: Select

Current Active Image: #1
Next Reboot Image: #1 #2
The top line shows the Current Active Image. From the bottom line, use the ◄ ► arrow keys to
select the Next Reboot Image (i.e., the image that will be active the next time you reboot the
unit) as #1 or #2. Press ENTER when done..
