5.2.3.2

Monitor: Mask

Alarm Mask: Power ExtRef
ConvA ConvB LNA PS (◄ ►E)
Use the ◄ ► arrow keys to select Power (when optionally configured for Power Monitoring),
ExtRef, ConvA, ConvB, LNA, or PS, and then press ENTER.
For each menu selection, three typical options are available. Using the ExtRef menu as an
example:
Ext Ref Lock Detect:
Fault Alarm Masked (◄ ►E)
Use the ◄ ► arrow keys to select Fault, Alarm, or Masked, and then press ENTER to return to
the previous menu.
If Power Monitoring is not supported when you select Power alarm masking, the
following message displays:
5.2.3.2.1

Out-of-Range Power Supply Masking Using the PS Submenu

Power Supply 1:
Power Supply 2:
Use this submenu to configure how out-of-range power supply events are shown on the front
panel Side A and Side B SUM FAULT LEDs, and the Summary Fault Relay.
Select Power Supply 1 or Power Supply 2, and then press ENTER.
Front Panel Operation
This Converter Does NOT
Support Power Monitor.
(◄ ►E)
