Command
Arguments
(Instruction
Parameter
for Command
Code and
Type
or Response
Qualifier)
to Query
Part Number
N/A
Various 1-96
bytes
Reboot
RBT=
1 byte
Retrieve
N/A
variable length
Configuration
Status
Reference
REF=
3 bytes
Oscillator
Tuning
Serial-based Remote Product Management
Description of Arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Query only.
Returns the Comtech EF Data part number of the unit. This part number is the unit's DOTCODE at
the time it was manufactured. The DOTCODE may be up to 96 printable ASCII characters long.
Example: <1/PNM?'cr'
>0001/PNM=MBT5003.350WRSW00'cr''lf'
Command only.
Soft Reboot
1 = Reboot System
Query only.
Used to Query the Configuration status of the unit
Example:
<1/RCS?'cr'
>0001/RCS='cr'
ESW=1'cr'
AFR=1'cr'
XRF=N/A'cr''lf'
Note: For XRF (External reference status):
N/A = no external reference;
05M = 5 MHz;
10M = 10 MHz.
XRF will always be N/A if the internal reference oscillator option is not installed.
Command or Query.
Adjusts the reference oscillator tuning voltage by sending a DAC value in the form xxx, where:
xxx is a numeric value from 0 to 255.
Default value: 087
Example: <1/REF=087'cr'
>0001/REF='cr''lf'
Note: This command sets the DAC value, but the actual Reference Oscillator tuning voltage can be
monitored using the RMS command.
MBT-5000A L-Band Up/Down Converter System
Description:
Redundancy Mode
Auto Fault Recovery
External Reference Status
7–16
Revision 1
Response to
Query
Response to
Command
(Instruction
query
(Target to
Code and
(Target to
Controller)
Qualifier)
Controller)
N/A
PNM?
PNM=x....x
(See
Description of
Arguments)
RBT =
N/A
RBT=x
RBT?
(See
Description of
RBT*
Arguments)
N/A
RCS?
RCS=x....x
(See
Description of
Arguments)
REF=
REF?
REF=xxx
REF?
REF*
(Same format
as Command
arguments)
MN-MBT-5000A
