Command
Arguments
(Instruction
Parameter
for Command
Code and
Type
or Response
Qualifier)
to Query
Retrieve
N/A
75 bytes
Next 5
unread
stored
Events
Serial-based Remote Product Management
Description of Arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Query only.
Unit returns the oldest 5 Stored Events which have not yet been read over the remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-body, where Sub-
body= ABCddmmyyhhmmss:
A being the fault/clear indicator.
F = Fault
C = Clear
I = Info
B being the fault type where:
1 = Base Unit
2 = Converter A
3 = Converter B
C is Fault Code numbers, where
For the base unit,
0 = No faults
1 = +19V Power Supply 1
2 = +19V Power Supply 2
3 = +5V Power Supply 1
4 = +5V Power Supply 2
5 = +7.8V Power Supply
6 = Flash Checksum
7 = FPGA Done
8 = External Ref Lock Detect
9 = Converter A1 Not Inserted
A = Converter B2 Not Inserted
B = Switch Fault
C = 12V
D = 15V
H = Power On
I = Power Off
J = Log Clear
K = Redundancy Config Change
For the Converter A and B,
1 = Synthesizer Lock Detect
2 = Heat-sink Temperature
3 = Low Forward RF Power
4 = LNA Current Supply
5 = High Temperature (Alarm)
If there are less than 5 events to be retrieved, the remaining positions are padded with zeros. If
there are no new events, the response is RNE*.
MBT-5000A L-Band Up/Down Converter System
7–19
Revision 1
Response to
Query
Response to
Command
(Instruction
query
(Target to
Code and
(Target to
Controller)
Qualifier)
Controller)
N/A
RNE?
RNE={CR}AB
Cddmmyyhhm
mss{CR}ABCd
dmmyyhhmms
s{CR}ABCddm
myyhhmmss{C
R}ABCddmmy
yhhmmss{CR}
ABCddmmyyh
hmmss
(See
Description of
Arguments)
MN-MBT-5000A
