6.3
SNMP Interface
The SNMP is an Internet-standard protocol for managing devices on IP networks. The SNMP-
managed network consists of three key components:
•
The managed device. This includes the MBT-5000A.
•
The SNMP Agent. This is the software that runs on the MBT-5000A. The MBT-5000A
SNMP Agent supports both SNMPv1 and SNMPv2c.
•
The user-supplied Network Management System (NMS). This is the software that runs
on the manager.
6.3.1
Management Information Base (MIB) Files
MIB files are used for SNMP remote management of a unique device. A MIB file consists of a tree
of nodes called Object Identifiers (OIDs). Each OID provides remote management of a particular
function. These MIB files should be compiled in a user-supplied MIB Browser or SNMP Network
Monitoring System server. The following MIB files are associated with the MBT-5000A:
MIB File/Name
(where 'x' is revision
letter)
FW-0021082x.mib
ComtechEFData Root
MIB file
MBT-5000A MIB file
FW-0021083x.mib
MBT-5000A Traps MIB
file
Ethernet-based Remote Product Management
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data
products and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFDa
ta(6247)
Module: ComtechEFData
MIB file consists of all of the OIDs for management of the amplifier
functions
Trap MIB file is provided for SNMPv1 traps common for MBT-5000A.
6–3
MBT-5000A L-Band Up/Down Converter System
Revision 1
MN-MBT-5000A
