Command
Arguments for
(Instruction
Parameter
Command or
Code and
Type
Response to
Qualifier)
Query
Retrieve
N/A
53 bytes
Equipment
(includes 'cr')
Type
Retrieve
N/A
Variable length
Maintenance
Status
Serial
N/A
9 bytes
Number
Temperature
N/A
4 bytes
Serial-based Remote Product Management
Description of arguments
(Note that all arguments are ASCII numeric codes between 48 and 57)
Query only.
Used to Query the block converter type and its start and stop frequencies.
Example:
<2/RET?'cr'
>0002/RET=5000A C-Band BUC'cr'
05850-06425'cr'
xxxxx-xxxxx'cr'
xxxxx-xxxxx'cr''lf'
Example for a tri-band converter:
<2/RET?'cr'
>0002/RET=5000A Ku-Band BDC'cr'
10950-11700'cr'
11700-12250'cr'
12250-12750'cr''lf'
Query only.
Queries the Maintenance status of the unit.
Example
<2/RMS?'cr'
>0002/RMS='cr'
SYNVT=001.2'cr'
HSTMP=+12.3'cr'
LNACS=380.2'cr'
FWPWR=004.9'cr'lf'
Notes:
1) If the converter does not support power monitor, will display FWPWR=xxx.x.
2) If the converter does not have LNS current supply, will display LNACS=xxx.x
Query only.
Queries the unit 9-digit serial number. Unit returns its S/N in the form xxxxxxxxx.
Example: SNO=176500143
Query Only.
Returns the temperatures of the heat sink in the form a sign byte followed by 3 bytes for the
temperature.
Example: TMP=+26.0
MBT-5000A L-Band Up/Down Converter System
Description
Synthesizer Voltage
Temperature
LNA Current Supply (in mA)
Forward Power
7–25
Revision 1
Response to
Query
Response to
Command
(Instruction
query
(Target to
Code and
(Target to
Controller)
Qualifier)
Controller)
N/A
RET?
RET=x....x
(See
Description of
Arguments)
N/A
RMS?
RMS=x....x
(See
Description of
Arguments)
N/A
SNO?
SNO=xxxxxxx
xx
(See
Description of
Arguments)
N/A
TMP?
TMP=sxxx
(See
Description of
Arguments)
MN-MBT-5000A
