5.2.2

SELECT: Config (Configuration) Menu Branches

CONFIG: Remote FltRec
ConvA ConvB RefAdj Redun
Use the ◄ ► arrow keys to select from the submenu choices shown, and then press ENTER.
The submenus available from the SELECT: Config (Configuration) menu branch are as
follows:
Submenu
Remote
FltRec
ConvA
ConvB
RefAdj
Redun
Front Panel Operation
Function
Sect
(Remote Control) Used to define whether you control the unit locally
0 or remotely, and identifies the unit address, interface type, and rate
and format of the baud parameters.
(Fault Recovery) Used to configure Fault Recovery in Auto (AFR) or
5.2.2.2
Manual mode.
(Converter 'A' or 'B') Displays the current configuration of the
5.2.2.3
selected converter, including the frequency, attenuation, and slope.
(Reference Oscillator Adjustment) Used to adjust the reference
5.2.2.4
oscillator.
(Redundancy) Used to identify the redundancy state and mode (see
5.2.2.5 Appendix B. MBT-5000A REDUNDANCY OPERATION for further
information).
