MBT-5003 L-Band Up/Down Converter System
Front Panel Operation
5.3.4.2

UTILITY: CID (Circuit ID)

Edit Circuit ID:
24 CHARACTER TST MESSAGE
To edit the Circuit ID string: On the bottom line, first use the ◄ ► arrow keys to select the
character to edit, then change that character using the ▲ ▼ arrow keys.
A maximum of 24 characters are available, as follows:
[Space] ( ) * + - , . / 0-9 and A-Z.
Once the ID string is composed, press ENT.
5.3.4.3

UTILITY: Display (VFD Display Brightness)

Display Brightness:
To edit the display brightness: Use the ▲ ▼ arrow keys to select a brightness value of 25%,
50%, 75%, or 100%. Press ENT when the brightness is suitable.
5.3.4.4

UTILITY: Firmware

THESE MENUS ARE INTENDED FOR DIAGNOSTIC PURPOSES ONLY. DO NOT
CHANGE AN IMAGE UNLESS OTHERWISE INSTRUCTED BY COMTECH EF
DATA CUSTOMER SUPPORT.
IMPORTANT
This series of submenus permits the user to view information about the MBT-5003 internal
firmware. The converter can store two complete firmware images; either image is selectable for
loading the next time the unit reboots.
Firmware Images:
Info Select
Select either Info or Select using the
UTILITY: Firmware
If Info is selected:
Firmware Info: Bootrom
Image#1
Select Bootrom, Image#1 or Image#2 using the
information.
Each image is further broken down as follows (where Image#X denotes Image#1 or
Image#2):
Image#X: Bulk
Select Bulk, App, or FPGA using the ◄ ► arrow key, then press ENT.
100%
(◄ ► E)
◄ ►
Info
Image#2
APP FPGA
arrow keys, then press ENT.
◄ ► arrow keys, then press ENT to view the
5–15
Revision 1
MN-MBT5003
