MBT-5000 L-Band Up/Down Converter System
Front Panel Operation
5.2.5.3
UTILITY: Display (VFD Display Brightness)
Display Brightness:
To edit the display brightness: Use the ▼▲ arrow keys to select a brightness value of 25%, 50%,
75%, or 100%. Press ENTER when the brightness is suitable.
5.2.5.4
UTILITY: Firmware
THESE MENUS ARE INTENDED FOR DIAGNOSTIC PURPOSES ONLY. DO NOT
CHANGE AN IMAGE UNLESS OTHERWISE INSTRUCTED BY COMTECH EF DATA
PRODUCT SUPPORT.
This series of submenus permits you to view information about the MBT-5000 internal
firmware. The MBT-5000 can store two complete firmware images. You can select which image
loads the next time the unit reboots.
Firmware Images:
Info Select
Use the ▼▲ arrow keys to select Info or Select, and then press ENTER.
5.2.5.4.1
Firmware Images: Info
Firmware Info: Bootrom
Image#1
Use the ▼▲ arrow keys to select Bootrom, Image#1, or Image#2, and then press ENTER to
view the information.
When you select Image#1, or Image#2, these submenus require further selection (where 'X'
denotes 1 or 2):
Image#X: Bulk
Use the ◄ ► arrow keys to select Bulk, App, or FPGA, and then press ENTER. If, for example,
you select Bulk, a screen formatted similar to the following example displays:
Bulk: FW-0000303
2.1.X MM/DD/YY
100%
(◄ ► E)
Image#2
APP FPGA
5–19
MN-MBT5000
Revision 4
