Summary Of Specifications - Comtech EF Data CIC-50 Installation And Operation Manual

.
Equipment Type
Modems Supported
Operating Modes
Jitter and Wander
Power requirements
Approvals
6
SPECIFICATIONS
T1/E1 G.703 Interface Converter
Comtech EFData CDM-550 and
CDM-550T Digital Satellite Modems
E1 (2048 kbps) balanced (120 ohms) and unbalanced (75 ohms)
T1 (1544 kbps) unbalanced (100 ohms)
Per ITU Recommendation G.703
Per ITU Recommendations G.823 and G.824
2.0 Watts maximum
+12 volts DC
-12 volts DC
(Power is supplied by the Modem. These power supplies are
electronically fused and protected.)
'CE' as follows:
EN 55022 Class B (Emissions)
EN 50082-1 (Immunity)
EN 60950 (Safety)
FCC Part 15 Class B
CIC-50 T1/E1 G.703 Interface Converter
5
Chapter 5.
SUMMARY OF
Rev. 1
