DELiVEry AND DEALEr SErViCE
Checking hydraulic tank oil level
Remove the transmission cover. Undo both screws
(one on each side) and lift off the transmission
cover.
Leave off the cover for the present.
Make sure there is oil in the hydraulic tank.
Top up with SAE 10W/50 fully synthetic oil if necessary.
iMPOrTANT iNFOrMATiON
Check and top up oil also after the test
drive. if there are any air pockets in the
transmission or the hydraulic system,
the oil level will drop.

Wheels

Mount the wheels (certain markets).
Tire pressures should be 60 kPa / 0.6 bar /
9 PSI on all wheels.
Highest permitted pressure is 100 kPa /
1.0 bar / 14 PSI.
iMPOrTANT iNFOrMATiON
Different pressures in the front wheels
will make the blades cut the grass at
different heights.

underrun guard

When the front and rear underrun guards are
supplied with the machine it is the dealer's
responsibility to fit them.
24
English-
Transmission cover
Hydraulic tank
Wheels
Rear underrun guard
6021-030
6012-048
6008-030
8009-739
