DynaControl V6 Options
HMI Selection
LCD Controller PN 115719
The LCD (liquid crystal display) controller is available with the complete line of DynaControl fea-
tures. It features an intuitive, multi-line, graphic display and operates via an input wheel
Touch Screen Controller PN 118135
The V6 color touch screen controller is available with an expanded line of DynaControl features. A
variety of customer-selected devices may be integrated into the HMI utilizing VNC desktop shar-
ing. An optional XIO module allows programmable I/O for custom applications. Up to ten units
may be controlled remotely by each touch panel.
LCD Pendant Control Assembly PN 680520
The Pendant Control option gives the DynaControl keypad mobility via an up to 30 meter (100 ft)
cable. The Pendant Control Panel Kit replaces the standard built-in keypad. An optional re-set
switch and on/off light can be mounted on the front panel.
V6 Communications Adapters
V6 EtherNet Assembly PN 680619
V6 Profibus Kit PN 680618
V6 EtherCAT Kit PN 680620
The V6 communications bus module adapts the ASU to full remote operation so that all system pa-
rameters can be transmitted and received.
Signal Isolator PN 680617
A signal isolator conditions a parent machine's production line's DC speed voltage or current refer-
ence to allow the ASU's gear pump to track the application's line speed. It accepts 0-10V, 0-5V,
4-20mA inputs and outputs a proportional 0-10V signal to DynaControl's electronics.
