ITW Dynatec
D SERIES V6 DCL ASU Manuals

V6 Power Module,

Fuses
The fuses of the POWER Module are located underneath a protective cover. The cover should only
be removed after the ASU is switched Off and disconnected from the main power supply. After
checking or replacing fuses, the cover must be re-installed.
Heater and motor driver circuits are fused on both legs with a 10A fuse.
The output for the DC power supply has a 6.3A fuse.
Always replace fuses with the same type of fuse.
Voltage Configuration Connector
The appropriate voltage configuration plug must be installed for the machine to operate properly.
Two different connectors (plugs) are available:
PN 115725 - 240V three phase, Delta (violet)
PN 115726 - 400V three phase, Wye (yellow)
cont.
Troubleshooting Page 7-11
Revised 10/14
