ITW Dynatec
D15/D25/D45 V6 DCL ASU Manual #20-63
Filter Guard
Pressure Gauge
(optional)
Hose/Head Electrical Connections are located on either side
of the Filter Outlet Manifold (8 hose/head model shown)
Hose/Head #1
Hose/Head #2
Hose/Head #3
Hose/Head #4

Rear Cover: Hose and Head Electrical and Adhesive Connections

Maintain adhesive level
13mm to 100mm (1/2" to
4") from top of hopper
Adjustable Pressure
Relief Valve
Hose / Head
Adhesive Port
Adhesive Supply
Hose
Auxiliary #1
Auxiliary #2
Auxiliary #3
Auxiliary #4
Adhesive Port Connections
#1 #2
#3
#4
Installation Page 3-9
Revised 10/14
#1 #2
#3
#4
