Item Description
1 System 1 Pump 1 is selected.
Pump Name
Touch the input box and an Alphabetic Entry Keypad will appear. Enter your desired pump
2
name and confirm by pressing OK.
The entered pump name will be displayed on the Pump Overview Screen.
Current Pump Mode
3 Press Current Pump Mode to select "Linear Line Speed" or "Pressure Control". Then press the
BACK button to go to the appropriate screen.
Automatic Ramp Compensation (ARC) Button
4
Press to go to the Automatic Ramp Compensation screen.
Optional: Minimum Input Pressure
• This field appears only if the pump is configured for a minimum input pressure lock.
• The Minimum Input Pressure is a customer parametrizable value which has to be reached
for the according pumps on decentralized pump (Applicator or Metering Station) to be
5
released.
•
A plausible limit value of Input Pressure (a minimum pressure of not less than 2 bar is
recommended) has to be entered to avoid a dry run of the pumps; otherwise the pump can
be damaged.
BACK Button
6
Press to return to the previous screen.
