D15/D25/D45 V6 DCL ASU Manual #20-63
Dynamelt D XX V6X X X X X X X X X X DX FX - X X X X X . . .
HOPPER SIZE:
15 = 15kg (33 lb)
25 = 25kg (50 lb)
45 = 45kg (90 lb)
CONTROLLER:
V6L = LCD controls (standard)
V6T = Touch screen controls
DROP-IN GRID = G
NO DROP-IN GRID = N
NUMBER OF HOSES:
2 or 4
PUMP(s):
GAS = Gear pump 1.5cc sngl
GBS = Gear pump 3.2cc sngl
GCS = Gear pump 4.5cc sngl
GAD = Gear pump 1.5cc dual
GBD = Gear pump 3.2cc dual
GDD = Gear pump 0.55cc dual
GGD = Gear pump 0.15cc dual
GGS = Gear pump 0.15cc sngl
GDS = Gear pump 0.55cc sngl
GES = Gear pump 10cc sngl
VOLTAGE:
2 = 200 - 240v/ 3 phase/ 50-60 HZ
3 = 380 - 400v/ 3 phase/ 50-60 HZ with neutral
MOTOR/ DRIVE GROUP:
D1 = 1 Drive (1 pump/ 2 or 4 hoses)
D2 = 2 Drives (2 pumps/ 4 hoses)
FILTRATION:
F1 = 150-mesh filter
F2 = 100-mesh filter
OPTIONAL ACCESSORIES:
C = Pendant controller
D = Digital pressure control
F = Profibus communication
G = Analog pressure gauge
H = Hi-temperature kit
K = KBSI signal isolator
L = Adhesive level control sensor
M = EtherCat communication
N = Nordson hose connector
O = EtherNet IP communication
EXAMPLE:
D25V6LN2GBS2D1F2-GL = D25 ASU with 25 kg hopper, LCD controller, without drop-in grid, 2 hoses, a
3.22cc single gear pump, 240 volts/ 3 phase, one drive, 100-mesh filters with optional analog pressure
gauge and level control.
ZLS = Precision gear pump 0.160cc sngl
ZES = Precision gear pump 0.584cc sngl
ZFS = Precision gear pump 1.168cc sngl
ZGS = Precision gear pump 2.92cc sngl
SHS = Precision gear pump 8.5cc sngl
ZED = Precision gear pump 0.584cc dual
ZDD = Precision gear pump 0.297cc dual
ZFD = Precision gear pump 1.168cc dual
ZDS = Precision gear pump 0.297cc sngl
SGD = Precision gear pump 2.92cc dual
ZLD = Precision gear pump 0.160cc dual
P = Pneumatic pressure relief valve
Q = Harting connector
R = Digital rpm readout
S = Multi-system HMI software license
T = Aux/ Temperature zones (2)
U = Multi-system client
X = Extra drop-in grid (D45 only)
Y = Rotary head connection

Model Designation Matrix (SDS)

Description Page 2-7
(Touch screen models only)
(Touch screen models only)
(Touch screen models only)
Revised 11/14
