Programming Sequence:
Set‐up each Daily Program entirely before moving on to the next Daily Program. Up to three
Daily Programs may be setup. All time selections are based on a 24‐hour clock.
To Program Active Days of the Week:
Turn the Input Wheel to the Days‐of‐the‐Week (Note: if you can no longer see the cursor when
turning the wheel, turn the wheel in the opposite direction). The Days‐of‐the‐Week may be
toggled Active (registers as "selected" on the display) or Inactive by pressing the Enter Knob
Each day of the week can only be assigned to one program.
To Program On/ Off Times:
Turn the Input Wheel to select the first Switch‐On time; press the Enter Knob to highlight the
time. Turn the Input Wheel to program your desired Switch‐On time (in hours and minutes) and
press the Enter Knob.
Turn the Input Wheel to select a Switch‐Off time or a Standby time, then press the Enter Knob to
highlight it. As above, turn the Input Wheel to program your desired time (in hours and
minutes), then press the Enter Knob.
In the same manner, if desired, program another Switch‐On time and/or Switch‐Off time.
To Program Additional Daily Programs:
Turn the Input Wheel to the second or third set of Days‐of‐the‐Week to program Switch‐On and
Switch‐Off times for Daily Program #2 or #3. Program in the same manner as above.
To Choose Activate, Deactivate or Sleep Mode:
Once the 7‐Day Scheduler's Daily Programs are setup, press F5 to Activate. This is indicated by
the clock symbol in the status line. To deactivate the scheduler, press F5 again.
Press F2 to put the ASU into SLEEP MODE (indicated below). In this state, the ASU will be activ‐
ated at the next programmed Switch‐On time of the scheduler or it can be manually started.
7‐Day Scheduler Examples (as shown on the illustration on the previous page):
Daily Program #1: On Mondays, Tuesdays, Wednesdays and Thursdays, the ASU will Switch‐On
at 6:00am. It will go into Standby at 12:00 noon. It will come out of Standby at 1:00pm and
Switch‐Off at 6:00pm.
Symbol for Push Enter Knob
System OFF
LCD Programming Page 5-13
Revised 10/14
.
cont.
