ITW Dynatec DYNAMELT D15 Series Technical Documentation Manual page 201

ITW Dynatec
D15/D25/D45 V6 DCL ASU Manual #20-63
4
7
PN 111254 0.15 cc/ rev. Dual Gear Pump Assembly
Item No. Part Number
1
018X031
2
078F017
3
078I001
4
069X061
5
069X064
6
101692
7
101626
8
111251
9
100865
10
111252
11
N00198
12
109907
13
012D083
14
012D082
15
069X160
16
N00198
001U002
2
1
13
8
15
Description
Ball Bearing, 1/8 Dia.
Snap Ring, 1/2"
Key Woodruff, #404
Shaft Seal
O-ring, -041
M4-0.7 x 35mm SHC Screw
M5-0.8 x 12mm SHC Screw
Plate Front, .55 cc/ rev.
Rear Bearing Plate, .55 cc/ rev.
Plate, Middle Gear, .55 cc/ rev.
O-ring, -113
Gear .55cc/ rev.
Drive Shaft 1.5 cc/ rev. Dual
Driven Shaft, 1.5 cc/ rev. Dual
Shaft Seal Retainer
O-ring, 2-113
Dow Corning 112 Lubricant (not shown)
Component Illustrations Page 10-25
11
12
14
3
5
Revised 10/14
16
12
5 9
10
Qty.
6
4
1
1
2
2
4
1
1
1
2
4
1
1
1
2
5
6
