V6 DCL Touch Screen Controller for Dynamelt M & D ASUs
Item Description
Use Temperature Integration
• Depending on your Temp Module this function can be activated/ deactivated.
4
• If you experience strong variations in actual temperature read-out, an integration function
can be activated to eliminate EMC influence.
5 These values are read-only.
6 Press the OK button to confirm your entered values and return to the previous screen.
7 Press the ESC button to discard any non-confirmed values and return to the previous screen.
Zone Status
Zone status is indicated.
• ALM = is highlighted if zone has an alarm.
• RTD = is highlighted if temperature sensor error occurs.
8
• WT = is highlighted if zone is in wait status because of heating priority setting.
• HT = is highlighted if zone is heating up.
• RDY = is highlighted if zone ready (setpoint temperatures are reached).
• Scale = Indication of Current Control Variable of the selected PID control zone.
Programming Page 5-27
