Page 5-10 LCD Programming
Revised 10/14

Main Menu

Press the Main Menu button on the Overview Screen to go to the following functions:
F1: Recipe Management
F2: Standby Mode
F3: Setpoint Locking
F4: 7‐Day Scheduler
F5: Info Menu
To select a function, press its "F" button (or turn the Input Wheel to highlight the desired func‐
tion and then press the Enter Knob to select).
F1 Recipes
Recipe Management (F1)
A recipe (or "program") is a set of temperature setpoints and parameters which the user has
programmed and stored in the controller for future use. Up to four recipes may be stored in the
DynaControl controller.
F3 Setpoint Locking
F2 Standby/ Setback
D SERIES V6 DCL ASU Manuals
INFO
F5 Info
(selected)
F4 7‐Day Scheduler
Recipe # F5 = Confirm
