ITW Dynatec DYNAMELT D15 Series Technical Documentation Manual page 209

ADHESIVE SUPPLY UNIT D15/25/45
POWER SUPPLY: 3 PHASE, "4 WIRE-DELTA", PE, 50/60HZ
VOLTAGE:
MAX. WATTAGE:
MAX. CURRENT:
INDEX
SHEET PAGE REF. DESCRIPTION
1 1
COVER SHEET & INDEX
2 20
POWER HOOK-UP / DISTRIBUTION
3 30
POWER PCBs
4 40
HEATER CIRCUITS / HOSE- HEAD-AUX-ZONES
5 50
CONTROL MODULES / RTD INPUTS
6 60
MOTOR CIRCUITS
7 70
PANEL BOX LAYOUT
8 80
GROUNDING SCHEME
9 90
OPTIONS
10 100
BILL OF MATERIAL
EXAMPLE: -K20.5
COLUMN 5
ON PAGE 20 (SHEET 2)
CONTACTOR
240VAC / 50-60HZ
24.1KW
58A
DynaControl V6
3 PHASE, "5 WIRE-WYE", PE, 50/60HZ
400VAC / 50-60HZ
22.0KW
32A
COMPONENT DESIGNATORS
A
CONTROL GEAR, PLC, MODULE
B
THERMOSTAT
F
FUSE, CIRCUIT BREAKER
G
POWER SUPPLY
H
INDICATOR, LAMP
K
CONTACTOR, RELAY
KN
SAFETY RELAY, E-STOP
M
MOTOR
Q
MAIN SWITCH
R
RESISTOR, RTD
S
SWITCH, PROXIMITY SWITCH
X
TERMINAL, TERMINAL STRIP
XS
PLUG/SOCKET CONNECTION
Y
SOLENOID
D15/25/45 V6
SCHEM, D15/25/45, V6
1 C
COVER SHEET AND INDEX
