Location Of Components - ITW Dynatec DYNAMELT D15 Series Technical Documentation Manual

Adhesive supply unit
Table of Contents

Advertisement

Page 7-2 Troubleshooting
Revised 10/14
HMI Assembly
(Operator's Panel)
V6 Base
Module
V6 Temp
Module
V6 AUX
Power Board
V6 Motor
Module
Fan
#2 Motor
Speed Control
Signal Isolator
#1 Motor
PCB
Speed Control
Main Circuit Breaker, On-Off, 30A (standard)
Main Circuit Breaker, On-Off, 60A (option)

Location of Components

ITW Dynatec
D SERIES V6 DCL ASU Manuals
High Temp (OverTemp)
Thermostat
(located
within
cabinet)
Power
Connects:
L1 L2 L3 N
V6 AUX
Power Board
V6 Power
Module
